Intended use

Only use the product described in this manual as follows:
• For cleaning garden ponds.
• While adhering to the technical specifications. (→ Unit data)
• Adherence to the permissible water quality. (→ Permissible water quality)
The following restrictions apply to the unit:
• Never operate the UVC lamp outside the casing or use it for any other purposes. The UVC radi-
ation is harmful to the eyes and skin even in small doses.
• Never run the unit without water.
• Not to be used for sterilising drinking water or other fluids.
• Do not use the unit together with chemicals, food, flammable, explosive substances or other
liquids aside from water.
• Do not use for industrial purposes.

Product Description

Overview
1 Casing
2 Unit head
2× stepped hose adapter for the outlet, ∅ 25 ... 38 mm
3
1× stepped hose adapter for the inlet, ∅ 19 ... 50 mm
4 3× gasket for stepped hose adapter (3)
5 3× union nut for fastening the stepped hose adapters (3)
6 1× inlet nozzle for driving the cleaning rotor
• Has to be inserted into the inlet for flow rates < 10,000 l/h
7 1× cover cap G½ for closing an outlet
2× hose clip, ∅ 20 ... 32 mm
8
2× hose clip, ∅ 35 ... 50 mm
1× hose clip, ∅ 40 ... 60 mm
