Instruction Manual / Inspection Manual
AW5 Series (Forward Facing Type)
This manual describes the information required to use the Combi ANGEL WAGON AW5/6
Series safely and easily. Before use, carefully read this manual to correctly use and inspect
the cart. After reading, keep this manual for future reference.
Table of Contents
■
Instruction Manual
■
Inspection Manual
AW6 Series (Rear Facing Type)
■
Part Replacement Procedures
Page 2 to 6
Page 2
Page 2
Page 2
Page 3
Page 3 to 4
Page 5 to 6
Page 7 to 15
Page 9 to 11
Page 12
Page 13
Page 14 to 15
1
Shopping Cart for Babies
Please save this manual for future.
AW5/6 Series
Page 16 to 27
Page 16 to 18
Page 19
Page 19 to 21
Page 22
Page 23
Page 24 to 27
Advertisement
Related Manuals for Combi ANGEL WAGON AW5 Series
Summary of Contents for Combi ANGEL WAGON AW5 Series
-
Page 1: Table Of Contents
AW5 Series (Forward Facing Type) AW6 Series (Rear Facing Type) This manual describes the information required to use the Combi ANGEL WAGON AW5/6 Series safely and easily. Before use, carefully read this manual to correctly use and inspect the cart. After reading, keep this manual for future reference. -
Page 2: Combi Angel Wagon
*The illustrations used in this manual may differ slightly from the product. Illustrations were drawn in an east-to understand manner. Combi ANGEL WAGON AW5/6 Series Instruction Manual Product Application ● The Combi ANGEL WAGON AW5/6 Series (hereinafter, this product) is a single-seat shopping cart to seat a child while, shopping at retailers. Safety Guidelines for Using the Product ●... -
Page 3: Product Specifications
Product Specifications AW5 Series (Forward Facing Type) AW6 Series (Rear Facing Type) Product Type *The child faces the same direction. *The child faces the customer caregiver. Combi ANGEL WAGON Combi ANGEL WAGON AW51CC2 AW61CC2 AW51CC2 Antistatic AW61CC2 Antistatic Combi ANGEL WAGON... - Page 4 AW6 Series (Rear Facing Type) Type Low-noise casters; front-wheel assembly Low-noise casters; front-wheel assembly / / Antistatic casters; Antistatic casters; rear-wheel assembly Combi ANGEL WAGON Combi ANGEL WAGON rear-wheel assembly (Hereinafter, CC2 Antistatic casters AW51CC2 Antistatic AW61CC2 Antistatic (Hereinafter, CC2 Antistatic (dia.
-
Page 5: How To Use
How to Use Use the product correctly by following the warning instructions below. Warning ● Never leave the cart with the child seated in it. ● Use the seat in the lowest position until your child can sit unassisted (until about 7 months old). Otherwise, your child may fall or result in an accident. - Page 6 How to adjust *There are three reclining positions. Use the seat in the most reclined position until your child can sit unassisted Warning (until about 7 months old). When reclining the seat When raising the seat Hold the reclining lever Seat Push the seat upward.
-
Page 7: Required Tools
Combi ANGEL WAGON AW5/6 Series Inspection Manual This manual describes the necessary daily and periodic inspection procedures required to use the Combi ANGEL WAGON AW5/6 Series safely and comfortably. Be sure to carry out the inspection daily or weekly and the periodic inspection once every 6 months correctly by following the procedures in the manual. - Page 8 *Other than for auto slope, the AW5 series and AW6 Series tools are the same. Do not use any object or tool other than the parts already installed to the product at the time of Warning delivery, and the parts and tools specified by Combi. Otherwise, it may cause damage, malfunction, or unexpected accidents.
-
Page 9: Daily Inspections
Daily Inspections During inspections, use the "Check sheet for daily inspections" on page 12. Daily inspections are carried out by operating, visual, and touching the product daily or weekly. If a problem was found by an inspection, use the tools and perform inspection in accordance with the item. - Page 10 ● Seat fixing screws (x4 on left and right) ● Belt cover fixing screw (x1) ● Hex cap nut of back cover (x1) B. Inspection of operation Measure in Inspection Item Inspection Method Inspection Criterion Case of Defect ⑲ Locking and releasing of the guard belt Operation, visual, and touch Can be locked and released Replace...
- Page 11 C. Inspection of stickers Measure in Inspection Item Inspection Method Inspection Criterion Case of Defect ㉔ Anti bacterial/Virus Right Handle Warning Sticker AW56 ㉕ Anti bacterial/Virus Handle Warning Sticker AW4 ㉖ Seat Warning Sticker AW56 ㉗ Seat-side Warning Caution Sticker Japanese AW56 Stickers are legible and free Visual Replace...
-
Page 12: Check Sheet For Daily Inspections
Make copies of this page for use during inspections. Check sheet for daily inspections Daily or weekly Keep this check sheet after filling it out. Date Date Date Date Date Date Date (year) (year) (year) (year) (year) (year) (year) Inspection Inspection Item Method carts... -
Page 13: Periodic Inspections
Periodic Inspections During inspections, use the "Check sheet for periodic inspections" on page 14. Periodic inspections are to be performed every six months. ● If a problem was found during an inspection, immediately stop using the product and contact the sales agent and request a repair. A. -
Page 14: Check Sheet For Periodic Inspections
C. Recording of inspection date Inspection sticker After a periodic inspection, in addition to filling Inspection out the following check sheet, write the date of Sticker is affixed below sticker the inspection on the inspection sticker affixed the reclining lever. below the reclining lever. - Page 15 Date Date Date Date Date Date Date (year) (year) (year) (year) (year) (year) (year) Inspection Item Inspection Method carts carts carts carts carts carts carts Inspection of external appearance ⑩ Damage or loss of handle Visual and touch ⑪ Damage of seat Visual and touch ⑫...
-
Page 16: Caster Replacement Procedure
Combi ANGEL WAGON AW5/6 Series Part Replacement Procedures If a problem is found during a daily or periodic inspection, and a new replacement part must be installed, carefully read these replacement procedures, and then replace the part correctly. Caster replacement procedure The tools required for the caster replacement ●... - Page 17 Replacement procedure for Warning Always inspect the new part after replacement by casters with stoppers (dia. 100) following the periodic inspection instructions (page 13). *The illustration shows the AW5 Series (Forward facing type). The replacement procedure for the AW6 Series (Rear facing type) is the same. Required tools ●...
- Page 18 Replacement procedure for casters Always inspect the new part after replacement by Warning for auto slope (dia. 125) following the periodic inspection instructions (page 13). *AW5 Series (Rear Facing Type) only. Required tools ● Wrench (nominal size: ● Hex key (short arm: 18 mm) The tools on the right are 19 mm) (x1) (width: 10 mm)(x1)
-
Page 19: Headrest Replacement Procedure
Headrest replacement procedure In case you find a problem with the headrest during a daily Always inspect the new part after replacement by Warning inspection, purchase a headrest replacement kit and carry out following the daily inspection instructions (page 9). the replacement by following the procedure below. - Page 20 Remove the guard front cover forward, Guard front cover and then pull out the belt without a tab from the guard. Belt tip Next, fold the belt at the position of the tab, pass the tip of the belt through the Guard hole of the guard, and then pull the belt.
- Page 21 Install the lock base to the Pass each belt through the holes on the Screw the five (5) screws at the guard front cover. guard and install the guard front cover to the back of the guard (reusing the guard. With the belt with tab folded at the same screws).
-
Page 22: Handle Replacement Procedure
Handle replacement procedure Required tools In case you find a problem with the handle during a daily inspection, purchase handle parts and carry out the replacement by following the procedure below. The tools below are required for this procedure. ● Handle parts ●... -
Page 23: Bumper Replacement Procedure
Bumper replacement procedure Required tools In case you find a problem with the bumper during a daily inspection, purchase a bumper replacement kit and carry out the replacement by following the The tools below are required for this procedure. procedure below. ●... -
Page 24: Umbrella Holder Replacement Procedure
Umbrella holder replacement procedure In case you find a problem with the umbrella holder during a daily inspection, purchase an umbrella holder set and carry out the replacement by following the procedure below. *The umbrella holder is the same for the AW5 Series (Forward facing type) and AW6 Series (Rear facing type). Required tools Always inspect the new part after replacement by Warning... - Page 25 AW5 Series (Forward Facing Type): Installation Install ① the Umbrella support, and then ② the Umbrella ring. ① Install the Umbrella support. Fix the Umbrella support to the frame connected to the handle. Install while following Step (1) through (5) below. Reclining angle Frame Holder...
- Page 26 ② Install the Umbrella ring. 400 mm Install the Umbrella ring 400 mm from the Umbrella support. Install the screw so that the umbrella ring is directly below the frame. Screw M6 x 25 mm (with flat washer and spring washer) Frame Phillips screwdriver...
- Page 27 Screw M6 x 25 mm (with flat washer and spring washer) Holder (3) Use the screw (1) to fix the umbrella ring to Phillips screwdriver the holder. Cap nut Umbrella ring Umbrella ring should locate directly below the frame ② Install the Umbrella support. Install the Umbrella support 370 mm from the Umbrella ring.
- Page 28 ● Inquiries about products This manual is available on the CombiWith website. It can also be downloaded (PDF) from (www.combiwith.co.jp/english/). Head Office/2-6-7 Motoasakusa, Taito-ku, Tokyo 111-0041 URL/www.combiwith.co.jp/english/ � Unauthorized reproduction of chapters, illustrations, etc., in this manual is prohibited. （B5） 175516060 231207 （1）...
