- Page 1 SC230E (AS05880-AS05885) Electronic control unit ELECTRICAL DIAGRAM AND CONNECTIONS...
-
Page 2: Electrical Connections
SC230E ELECTRICAL CONNECTIONS DIP2 DIP1 F0.5A F0.5A STOP LED SAF LED PHOTO LED START LED PED LED FCA LED LEARN LED FCC LED CLOSE LIMIT MAGNET SENSOR OPEN LIMIT MAGNET SENSOR EXTERNAL CAPACITOR 14 15 16 17 18 19 14 15 16 17 18 19... -
Page 3: Power Supply Connection
SC230E POWER SUPPLY CONNECTION NEUTRAL PHASE 230Vac OVERCURRENT CIRCUIT BREAKER RESIDUAL-CURRENT DEVICE NEUTRAL PHASE EARTH CONNECTION MOTOR CONNECTION SELF-LEARNING OF THE MOVEMENT DIRECTION PLACE THE LIMIT MAGNETS CORRECTLY 3 4 5 6 7 3 4 5 6 7... - Page 4 SC230E LIMIT MAGNETS INSTALLATION STOP STOP CLOSING OPENING CAPACITOR CONNECTION EXTERNAL EXTERNAL CAPACITOR CAPACITOR 14 15 16 17 18 19 5 6 7 8 9 10 11 12 13 5 6 7 8 9 10 11 12 13 230Vac 230Vac...
- Page 5 SC230E FLASHING LIGHT CONNECTION DIP1_3 230 Vac 40W max 5 6 7 CONTROL DEVICES CONNECTION 8 9 10 11 12 13 PHOTOCELLS CONNECTION DCF180 8 9 10 11 12 13 14 15 16 17 18 19 REFER TO THE PHOTOCELLS MANUAL FOR...
- Page 6 SC230E PHOTOCELLS CONNECTION DGF100-200 8 9 10 11 12 13 14 15 16 17 18 19 CONSULTARE IL MANUALE 3 4 5 3 4 5 DELLE FOTOCELLULE PER MAGGIORI DETTAGLI REFER TO THE PHOTOCELLS MANUAL FOR DETAILED CONNECTION DIAGRAMS PHOTOCELLS CONNECTION WITH TEST...
- Page 7 SC230E CONNECTION OF NC “SAFETY DEVICE” ACTIVE ONLY DURING OPEN DIP1_10 = ON SW4 = 8 9 10 11 12 13 CONNECTION OF 8K2 “SAFETY DEVICE” ACTIVE ONLY DURING OPEN DIP1_10 = ON SW4 = 8 9 10 11 12 13...
-
Page 8: Encoder Connection
SC230E WARNING LIGHT CONNECTION DIP2_8 = OFF 24Vac 3W MAX 14 15 16 17 18 19 ELECTRICAL LOCK CONNECTION DIP2_8 = ON 14 15 16 17 18 19 24Vac ENCODER CONNECTION DIP2_3 = ON NERO - BLACK 14 15 16 17 18 19... - Page 9 SC230E DIP1 DEFAULT SETTINGS DIP1 TERMINAL 12 AS SAFETY EDGE ACTIVE ONLY IN OPEN TERMINAL 12 AS STOP ANTI CRUSHING ENABLED ANTI CRUSHING DISABLED FAST CLOSING ENABLED FAST CLOSING DISABLED DECELERATION ENABLED DECELERATION DISABLED AUTOMATIC CLOSING ENABLED AUTOMATIC CLOSING DISABLED...
- Page 10 SC230E TRIMMER “FORCE” DIP1_7 = OFF SLOW DOWNS DISABLED DIP1_7 = O SLOW DOWNS ENABLED FORCE DURING CLOSE FORCE DURING OPEN-CLOSE FORCE DURING OPEN MOVEMENT SPEED : 100% - THRUST FORCE: 10%-100% TRIMMER “SLOW” DIP1_7 = ON SLOW DOWNS ENABLED...
-
Page 11: High Sensitivity
SC230E TRIMMER “SENS” INTERVENTION SENSITIVITY OF ANTICRUSHING SENSOR HIGH SENSITIVITY MEDIUM SENSITIVITY LOW SENSITIVITY TRIMMER “PAUSE” PAUSE 2 SECONDS PAUSE 220 SECONDS... -
Page 12: Technical Characteristics
SC230E 1 - TECHNICAL CHARACTERISTICS Control unit SC230E / AS05880-AS05885 Electronic control unit for the automation of a Type sliding gate with 230Vac motor Power supply 230 Vac single-phase 50/60 Hz No. of motors Motor power supply 230 Vac Flashing light... -
Page 13: Installation Warnings
SC230E 3 - INSTALLATION WARNINGS • Before proceeding with the installation, it is necessary to fit a magnetohtermal and differential switch of 10A max. upstream of the system. The switch must guarantee an omnipolar separation of the contacts with an opening distance of at least 3 mm. - Page 14 SC230E 5 - ELECTRICAL CONNECTIONS: TERMINAL BOARDS Terminal Position Signal Description PHASE 230 Vac power supply NEUTR 230 Vac power supply Flashing light output 230Vac 40W. LAMP Slow flashing in opening, turned off in pause, fast flashing in closing. Motor phase 1 connection (black cable)
-
Page 15: Protection Fuses
SC230E 7 - PROTECTION FUSES Position Value Type Description Protects the electronic card 500 mA FAST Protects the control unit at 230 Vac power supply input FAST Protects the ACCESSORIES and SAFETY DEVICES power supply outputs 500 mA FAST 8 - SIGNALLING LED... - Page 16 SC230E 9 - JUMPER SW3-SW4 The DEFAULT settings are coloured in grey Descrizione JUMPER Function Status N.C. devices are connected to terminal 11 (SAFETY) TERMINAL 11 OPERATION Resistive devices 8,2 KOhm (8K2) are connected to terminal 11 (SAFETY) N.C. devices are connected to terminal 12 (STOP/SAFETY).
- Page 17 SC230E 10 - DIP SWITCHES DIP1 Function Status Description Enables the pre-flashing of 3 s before the activation of the motor in opening and closing. DIP 3 PRE-FLASHING Disables the pre-flashing. Enables the TEST of the devices connected to the terminals (10)-(11)-(12): if the devices are working properly, the cycle can start, otherwise some prolonged flashing will indicate the anomaly.
- Page 18 SC230E 10 - DIP SWITCHES DIP1 Function Status Description Terminal 12 (SAFETY-STOP) works as SAFETY EDGE ENABLED ONLY DURING OPENING. After the intervention of the safety device, the control unit stops the motion, TERMINAL 12 inverts it for 1 s and waits for a command.
- Page 19 SC230E 11 - DIP SWITCHES DIP2 Function Status Description The decelerated manoeuvre starts 120cm before the total opening/closing. DECELERATION DIP 4 DISTANCE The decelerated manoeuvre starts 60cm before the total opening/closing. Soft start ENABLED. DIP 5 SOFT START Soft start DISABLED.
- Page 20 SC230E 11 - DIP SWITCHES DIP2 Function Status Description Terminal 17 (WARNING LIGHT) works as Output ELECTRIC LOCK 24Vac 3W max. It is not possible to power the electric lock directly from terminal 17, it is necessary to TERMINAL 17 use a relay and an external transformer.
-
Page 21: Trimmer Adjustment
SC230E 12 - TRAVEL LEARNING Procedure for pedestrian travel learning • Unlock the operator and position the gate between the two limit switches FCC-FCA, LED FCC-FCA on. • Position DIP2_10 in OFF. • Position DIP2_10 in ON . • LEARN led turns on fixed •... -
Page 22: Final Checks
SC230E 14 - FINAL CHECKS DESRCIZIONE MENU ( A ) • Check the electrical connections: an improper connection may be harmful to both the control unit and the operator. • Check the correct position of the limit switches. • Always preset the mechanical stops in opening and closing. - Page 23 CE Declaration of conformity The manufacturer: GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) - ITALY declares that the products: ELECTRONIC CONTROL UNIT SC230E are in conformity with the following CEE Directives: Directive 2006/95/CE and subsequent amendments; • •...
- Page 24 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
