- Page 1 https://muzcentre.ru User's Manual SPEAKER MODELLER www.altoproaudio.com Version 1.0 March 2006 English...
-
Page 2: Safety Related Symbols
SAFETY RELATED SYMBOLS Unplug the product before electrical storms occur and when unused for long periods of time to reduce the risk of electric shock or CAUTION fire. RISK OF ELECTRIC SHOCK DO NOT OPEN External Connection This symbol, wherever used, alerts Always use proper ready-made insulated you to the presence of un-insulated mains cabling (power cord). -
Page 3: Important Safety Instructions
To avoid the risk of electric shock and Servicing damage, do not subject this product to Refer all servicing to qualified service any liquid/rain or moisture. Do not use this personnel only. product when in close proximity to water. Do not perform any servicing other than those instructions contained within the Do not install this product near any direct User's Manual. - Page 4 Our MS1 Processor is the result of many hours of listening and tests involving Common People, area experts, musicians and technicians.
-
Page 5: Table Of Contents
TABLE OF CONTENT 1. INTRODUCTION ....................5 2. FEATURES ....................3. CONTROL ELEMENTS .................5 3.1 Front Panel 3.2 Rear Panel 4. INSTALLATION AND CONNECTION ............6 TECHNICAL SPECIFICATION ..............6. WARRANTY....................7... -
Page 6: Introduction
Thank you very much for expressing your confidence in LTO products by purchasing LTO MS1. The MS1 is a professional processor, which provides you an excellent electric performance. The MS1 is 2-Channel analog sound processor with 16 effects, and all input and output connectors are compatible with balanced jack. Thanks to the use of selected and expensive components, the performance of MS1 is worth much more than its price. -
Page 7: Rear Panel
4. Power LED This LED lights up when the unit is powered on. Rear Panel OUTPUT INPUT TIP/PIN 2 TIP/PIN 2 RING/PIN 3 RING/PIN 3 SLEEVE/PIN 1 SLEEVE/PIN 1 15VAC~ POWER RIGHT LEFT RIGHT LEFT(MONO) 5. AC Inlet This jack is used to connect the AC power supply with the supplied 15V AC adapter. -
Page 8: Technical Specification
5. TECHNICAL SPECIFICATION AUDIO INPUT Connectors 1/4" jack Type R filtered, servo balanced input Impedance 30 Kohm balanced, 22 Kohm unbalanced Max. input level +26 dBu balanced and Unbalanced CMRR Typ.40db,>55db@1khz AUDIO OUTPUT Connectors 1/4" jack Type Balanced Min. output impedance 100 Ohm Max. -
Page 9: Terms And Conditions
2.2 Please provide a copy of your sales receipt or other proof of purchase with the returned machine, and give detail information about your return address and con- tact telephone number. 2.3 A brief description of the defect will be appreciated. 2.4 Please prepay all the costs involved in the return shipping, handling and insu- rance. - Page 10 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright 2006 SEIKAKU GROUP NF02530-1.0...
