- Page 1 WWW.TAICHUAN.COM INDOOR MONITOR ADMIN GUIDE Applicable Models: TC-5000MH-18F Version: 1.0 | Date: September.2021...
-
Page 2: About This Manual
About This Manual Thank you for choosing Taichuan TC-5000MH-18F indoor monitor. This manual is intended for the administrators who need to properly configure the indoor monitor. This manual provides all the configurations for the functions and features of the TC-5000MH-18F indoor monitor. Please visit the Taichuan website or consult... -
Page 3: Related Documentation
Related Documentation You are advised to refer to the related documents for more technical information via the link below: http://Support-Zhuhai Taichuan Cloud Technology Co., LTD. -
Page 4: Table Of Contents
Table of Contents 1. Product Overview....................5 2. Model Difference....................6 3. Access the Device....................7 4. Basic Settings......................8 4.1. WiFi Network Setting...................9 4.2. Ethernet Setting..................10 4.3. Safety Password Setting................11 4.4. Volume and Ringtone Setting..............12 4.5. QR Code..................... 13 4.6. -
Page 5: Product Overview
___________________________________________________________________________ 1. Product Overview TC-5000MH-18F is an Android based with a smooth touch-screen indoor monitor. It can be connected with Taichuan outdoor unit for audio/video communication, unlocking, and monitoring. Residents can communicate with visitors via audio/video call, and it supports unlocking the door remotely. -
Page 6: Model Difference
___________________________________________________________________________ 2. Model Difference Model TC-5000MH-20H TC-5000MH-18B TC-5000MH-20G TC-5000MH-20I Image Housing Alu.+ABS Alu.+ABS Alu.+ABS Material Android 6.0 Android 6.0 Android 6.0 Android 6.0 7 Inch IPS LCD 10 Inch IPS LCD 10 Inch IPS LCD 10 Inch IPS LCD Display Resolution 1280*800 1280*800... -
Page 7: Access The Device
___________________________________________________________________________ 3. Access the Device When you plug on power the device will boot up automatically . -
Page 8: Basic Settings
___________________________________________________________________________ 4. Basic Settings You can access the device's basic setting where you can configure different types of functions as needed. To access the device basic setting by pressing Basic Settings. -
Page 9: Wifi Network Setting
___________________________________________________________________________ 4.1. WiFi Network Setting Taichuan indoor monitor can connect to WiFi network for mobile app remote control, cloud talk and home automation.To access WiFi connection,open WLAN switch,choose available WiFi network,enter password and access. -
Page 10: Ethernet Setting
___________________________________________________________________________ 4.2. Ethernet Setting Ethernet is for intercom network only.When you access to Ethernet,the IP data will show here. Parameter Set-up: Static IP: select the static IP mode by ticking the static check box. When static IP mode is selected, then the IP address, subnet mask, default gateway, and DNS servers address have to be manually configured according to your actual network environment. -
Page 11: Safety Password Setting
___________________________________________________________________________ 4.3. Safety Password Setting. You can modify outdoor panel unlock password and disarm password on safety setting. -
Page 12: Volume And Ringtone Setting
___________________________________________________________________________ 4.4. Volume and Ringtone Setting Taichuan indoor monitors provide you with various types of ringtone and volume configuration ranging from ring volume,media volume and call volume. Parameter Set-up: Ring Volume: adjust the incoming call ringtone volume. Media Volume:adjust the media volume. -
Page 13: Qr Code
__________________________________________________________________________ 4.5. QR Code App: scan to download Tuya Smart Life App. Blinding: to bind the device to Tuya app for cloud talk and remote control. Device: is the code for the device. -
Page 14: Dormant Setting
__________________________________________________________________________ 4.6. Dormant Setting You can set the sleep time from 15 seconds to 30 minutes or never sleep . -
Page 15: Language Setting
__________________________________________________________________________ 4.7. Language Setting You can set or change the language for screen display from Basic Settings > Language set. -
Page 16: Equipment Information
__________________________________________________________________________ 4.8. Equipment Information Find out more equipment information on About equipment. -
Page 17: System Setting
__________________________________________________________________________ 5. System Setting Here is the settings of Android Operation System,it’s the universal settings of Android tablet,not means all the functions can work on the device.For the setting of intercom,please go to Basic Settings. -
Page 18: Application List
__________________________________________________________________________ 6. Application List The apps you installed will show on the Application List. -
Page 19: Video Intercom
__________________________________________________________________________ 7. Video Intercom You can access to intercom functions from Video intercom. Parameter : Call elevator: you can summon lift at home via call elevator. Call property: call lobby man or management center. Monitor door phone: monitor building outdoor panel. ... -
Page 20: Smart Home
__________________________________________________________________________ 8. Smart Home Taichuan monitors inbuilt Tuya smart home app to manage your smart home devices. The Smart Home icon can be customized to your own app. -
Page 21: Smart Security
__________________________________________________________________________ 9. Smart Security Taichuan monitors support smart home leakage, you can set different scenarios per your need. Parameter : Back home: when trigger back home mode, the preset devices will open. Out home: when trigger out home mode, the preset devices will close. -
Page 22: Call Records And Messages
__________________________________________________________________________ 10. Call Records and Messages To view call record & message ,community announcement and security records, please go to Announcement. Parameter : Community announcement: shows the pushed announcement from management center. Security records: shows the relevant security events. ... -
Page 23: Do Not Disturb
__________________________________________________________________________ 11. Do Not Disturb Set Do Not Disturb on the moon icon from the top right corner. -
Page 24: Contact Setting
__________________________________________________________________________ 12. Contact Setting You can configure the contacts list in terms of adding and modifying contacts on the device Application List > Contacts>Create a new contact. -
Page 25: Time And Date Setting
__________________________________________________________________________ 13. Time and Date Setting To set up time setting on the device System Settings > System> Date & time... -
Page 26: Install Third-Party App
__________________________________________________________________________ 14. Install Third-Party App You can install the third-party App to your device on management center System tools > Upgrade management interface. Click +Add, choose a suitable .apk file from PC to upload, push upgrade for the right device. Find setting on device,click “check for updates”,select “DOWNLOAD”,apk will automatically install. -
Page 27: Enigeering Settings
__________________________________________________________________________ 15. Firmware Upgrade To upgrade firmware, download software “PhoenixCard” to your PC, insert empty SD card, unpack the firmware package, choose the firmware image and burn, when the loading bar turns green, means burn card successfully. After you burn the card, open the back cover of the device,insert the card,when power in it will automatically upgrade, when the loading bar turns green, it's successfully upgraded, after all the process must take out the card or it will upgrade again next time you turn on the device. -
Page 28: Engineering Settings
__________________________________________________________________________ 16. Engineering Settings You can access to advanced settings for more configuration of video intercom settings, smart home settings and other settings on device Basic settings > About equipment, quick tap Kernel version 3 times, enter password, the default password is 123456. -
Page 29: Reboot
__________________________________________________________________________ 17. Reboot If you want to reboot the device, you can operate it directly on the device setting. To reboot to the system setting on device Basics Settings >Restart. -
Page 30: Reset
__________________________________________________________________________ 18. Reset If you want to reset the whole device system to the factory setting, you can operate it directly on the device, go to Engineering Settings > Other Settings > Restore Factory. -
Page 31: Abbreviations
__________________________________________________________________________ 19. Abbreviations ACS: Auto Configuration Server Auto: Automatically AEC: Configurable Acoustic and Line Echo Cancelers ACD: Automatic Call Distribution Autop: Automatical Provisioning AES: Advanced Encryption Standard BLF: Busy Lamp Field COM: Common CPE: Customer Premise Equipment CWMR: CPE WAN Management Protocol DTMF: Dual Tone Multi-Frequency DHCP: Dynamic Host Configuration Protocol DNS: Domain Name System... -
Page 32: Faq
A6:No, but you can connect electrical lock to outdoor panel, Taichuan outdoor panels have relay component. Q7:Can I communicate other indoor monitor with indoor monitor? A7:Taichuan device can communicate with each other, no matter it is indoor monitor or door phone. Of course indoor monitor can call to other indoor monitor. -
Page 33: Contact Us
__________________________________________________________________________ 21. Contact US For more information about the product, please visit us at www.taichuan.com or feel free to contact us Sales email: globalmarket@taichuan.com Technical support email: xuwenwang@taichuan.com Telephone: +86-756-8665853 We highly appreciate your feedback about our products...
