Ｔ Ｃ－３０００ＤＡ－Ｘ１／Ｘ２
Video
Doorbell
Ｐｒｏｄｕｃｔ Ｏｖｅｒｖｉｅｗ
Ａｃｃｅｓｓｏｒｉｅｓ
2-Pin cable x 1
2-Pin power cable x 1
3-Pin cable x 1
Cover pad x 1
Screw x 5
Hexahedral driver x 1
Wall Mｏｕｎｔｉｎｇ Ｉｎｓｔａｌｌａｔｉｏｎ
Mic
Camera
Led Light
Speaker
Card Reader
Call Button
92
1
Ｑｕｉｃｋ Ｇｕｉｄｅ
63
Ｒａｉｎ ｃｏｖｅｒ
33
Advertisement
Related Manuals for Taichuan TC-3000DA-X1
Summary of Contents for Taichuan TC-3000DA-X1
- Page 1 Ｔ Ｃ－３０００ＤＡ－Ｘ１／Ｘ２ Wall Mｏｕｎｔｉｎｇ Ｉｎｓｔａｌｌａｔｉｏｎ Video Doorbell Ｑｕｉｃｋ Ｇｕｉｄｅ Ｐｒｏｄｕｃｔ Ｏｖｅｒｖｉｅｗ Camera Led Light Speaker Card Reader Call Button Ａｃｃｅｓｓｏｒｉｅｓ 2-Pin cable x 1 2-Pin power cable x 1 3-Pin cable x 1 Ｒａｉｎ ｃｏｖｅｒ Hexahedral driver x 1 Cover pad x 1 Screw x 5...
- Page 2 Ｔ Ｃ－３０００ＤＡ－Ｘ１／Ｘ２ Wall Mｏｕｎｔｉｎｇ Ｉｎｓｔａｌｌａｔｉｏｎ Ｑｕｉｃｋ Ｇｕｉｄｅ Ｉｎｓｔａｌｌａｔｉｏｎ Use screws to fix the rain cover on the wall. Connect cables to the doorbell, fix the cover pad by screws. Mount the doorbell to the rain cover, use screw to fix it at the bottom side. Ｎｅｔｗｏｒｋ Ｔｏｐｏｌｏｇｙ...
- Page 3 Ｔ Ｃ－３０００ＤＡ－Ｘ１／Ｘ２ Wall Mｏｕｎｔｉｎｇ Ｉｎｓｔａｌｌａｔｉｏｎ Ｑｕｉｃｋ Ｇｕｉｄｅ Ｄｅｖｉｃｅ Ｗｉｒｉｎｇ Ｍｉｎｉ ＵＳＢ １０／１００Ｍ Ｎｅｔｗｏｒｋ Ｐｏｒｔ Ｄｏｏｒ Ｔａｍｐｅｒ Ｉｎｓｐｅｃｔｉｏｎ Ｄｅｔｅｃｔｉｏｎ Ｕｎｌｏｃｋ Ｗｉｒｉｎｇ ＧＮＤ ＋１２Ｖ Power 12V/2A ＮＣ Ｔａｐｅ ＣＯＭ Ｔａｍｐｅｒ ＮＯ Ｄｅｔｅｃｔｉｏｎ ＧＮＤ ＋１２Ｖ Magnetic Lock 12V/0.5A ＧＮＤ ＋１２Ｖ Power ＮＣ 12V/2A ＣＯＭ Ｄｏｏｒ ＮＯ ＋１２Ｖ Ｉｎｓｐｅｃｔｉｏｎ ＧＮＤ Ｗｉｒｅｄ ｍａｇｎｅｔｉｃ ａｌａｒｍ...
