- Page 1 Tumble Dryer EN User Manual EDH90******...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooter, service information, buy accessories & spare parts, online product registration : www.electrolux.com CUSTOMER CARE AND SERVICE We recommend the use of original spare parts. When contacting Service, ensure that you have the following data available. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage. Always keep the instructions with the appliance for future reference. Read the instructions. - Page 4 • Keep all packaging away from children and dispose of it appropriately. • Keep detergents away from children. • Keep children and pets away from the appliance when the door is open. • If the appliance has a child safety device, it should be activated.
- Page 5 • Do not exceed the maximum load (refer to the "Programme chart" chapter in User manual). • Do not use the appliance if items have been soiled with industrial chemicals. • Wipe away lint or packaging debris that has accumulated around the appliance. •...
-
Page 6: Conditions Of Use
• If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent. This will reduce, but not eliminate, the hazard. •... -
Page 7: Safety Instructions
SAFETY INSTRUCTIONS 2.1 Installation • Make sure that the parameters on the rating plate are compatible with the • Remove all the packaging. electrical ratings of the mains power supply. • Do not install or use a damaged appliance. • Always use a correctly installed shockproof socket. - Page 8 2.4 Internal lighting (Available for • For more detailed information about recycling this product, Please contact model EDH***R7**, EDH***R9**) your local city office, your household waste disposal service, or the shop WARNING! where you purchased the product. Risk of injury. 2.7 Care and cleaning •...
-
Page 9: Product Description
PRODUCT DESCRIPTION Water Container Control Panel Door Lock Filter Heat Exchanger lid Heat Exchanger cover Adjustable Feet Appliance Door ENGLISH... -
Page 10: Installation
INSTALLATION Unpacking Installation *Available for model EDH***J5** WARNING! Before proceeding with installation, read the safety information, and dimension preferred. 596 mm *Available for model EDH***P5**, EDH***R7**, EDH***R9** For model EDH***J5**, Use the DRUM UNLOCKED KEY to unlock Rear Drum locks, before using the appliance. For other models, the rear drum locks are removed automatically when the dryer is activated for the first time. - Page 11 662 mm 810 mm 1250 mm 10 mm 10 mm 155° 958 mm wall 30 mm WARNING! The tumble dryer cannot be placed on top of a washing machine. For more information, please contact authorized dealer. 15 mm ENGLISH...
-
Page 12: Control Panel
CONTROL PANEL 5.1 Control Panel Description K L M Programme knob Time Dry touch key Dryness Level touch key On/Off button Extra Anticrease touch key • Iron Dry End Alert touch key • Cupboard Dry Finish In Adjustment touch key •... - Page 13 5.2 Display Indicator : Anticrease phase Notifications icon Time Dry icon Remote Start icon Extra Anticrease icon SmartLeaf icon End alert icon Extra Silent icon Finish In icon Child lock icon Decrease finish in time Indicator : Clean filter Increase finish in time Indicator : Check heat exchanger Programme duration...
-
Page 14: Programme Table
PROGRAMME TABLE 6.1 Programme Chart Programme Load Properties / Fabric type Cottons White and colored cotton fabrics program. The default setting Đồ Cottons is for ready-to-store dryness level. Eco Cottons Cotton fabrics programme designed for maximum energy Tiết kiệm (đồ saving. - Page 15 Woolmark Apparel Care - Blue The wool drying cycle of this machine has been tested and approved by The Woolmark Company. The cycle is suitable to dry wool garments which are labelled "hand wash" provided that the garments are washed in a Woolmark endorsed hand washing cycle and dried according to the instructions issued by the manufacturer.
-
Page 16: Options And Settings
Wi-Fi to the Electrolux Cloud, as well as to your tumble dryer. TIME DRYING RECOMMENDATION In order to use the SyncDry function,... -
Page 17: On/Off Button
Reverse Plus 7.2 Settings Increase drum reversing frequency to Child lock function reduce items twisting and entanglement. This function prevents children playing To increase uniformity of drying result with the appliance while a programme is and help reduce creases. Recommended operating. -
Page 18: Water Container Indicator
Water container indicator One of these indicators comes on: • The maximum dryness By default, the water container indicator • The more dry laundry is on. It comes on when the programme is completed or when it is necessary to •... -
Page 19: Wi-Fi Connectivity Setup
Terms and Conditions Electrolux gratefully acknowledges and Electrolux’s Privacy Policy in the the contributions of the open software app to use the connected features of and robotics communities to the the laundry appliance. -
Page 20: Over-The-Air Update
Wait for confirmation of connection 8.2 Remote Start which may take up to a minute before When the app is installed and the proceeding to the next step. wireless connection is complete, you can start and stop a programme remotely by For iOS devices, you will then be activate remote start. -
Page 21: Daily Use
DAILY USE 9.1 Start a programme without Finish You can delay the start of a programme " Finish In (-) and (+)" (Minimum is 1hr (depend on cycle) and Before you use the appliance to dry maximum is 24hr.) items: 1. -
Page 22: Hints And Tips Care
9.5 Stand-by function • Inadequate default dryness level settings. See chapter "Dryness level" To reduce energy consumption, this • Room temperature is too low or too function automatically deactivates the high. Optimal room temperature is appliance: between 18°-25°C. • After 5 minutes if you do not start the programme. -
Page 23: Care And Cleaning
CARE AND CLEANING 11.1 Cleaning the filter WARNING! Avoid the use of water to clean the filter. Instead throw away lint in the dustbin (avoid dispersion of plastic fibre in ambient water). To achieve the best drying performances, clean the filter regularly. Clogged filters lead to longer cycles and increase in energy consumption. - Page 24 You can use the water from the water container as an alternative to distilled water (e.g. for steam ironing). Before you use the water, remove dirt residues with a filter. 11.3 Cleaning the Heat Exchange CAUTION! Do not touch the metal surface with bare hands.
- Page 25 11.4 Cleaning the drum CAUTION! Do not use furniture cleaning agents WARNING! or cleaning agents which can cause Disconnect the appliance before you corrosion. clean it. 11.6 Cleaning the airflow slots Use a standard neutral soap detergent to clean the inner surface of the drum and Use a vacuum cleaner to remove fluff drum lifters.
-
Page 26: Troubleshooting
TROUBLESHOOTING WARNING! Deactivate the appliance before you do the checks. Alarm Malfunction Possible cause Solution Code • • • The programme Appliance motor The programme was not was not overloaded. Too much completed. Remove the laundry complete laundry or entrap in the from the drum, set the programme drum. - Page 27 Problem Possible solution The cycle time is too long or unsatisfactory Make sure that the weight of the laundry is drying result. suitable for the duration of the programme. Make sure that the filter is clean. The laundry is too wet. Spin the laundry in the washing machine again.
-
Page 28: Technical Data
TECHNICAL DATA Model Name EDH903R7WC, EDH903R7SC Height x Width x Depth 850 x 596 x 662 mm Max. depth with the appliance door open 1107 mm Max. width with the appliance door open 958 mm Adjustable height 850 mm (+ 15 mm - feet adjustment) Drum volume 113 l Maximum load... -
Page 29: Environment Concerns
ENVIRONMENT CONCERNS 14.1 Packaging Materials The materials marked with the symbol are recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene. This means that they can be recycled by disposing them properly in appropriate collection containers. 14.2 Old Machine Use authorized disposal sites for your old appliance. Help to keep your country tidy! The symbol on the product or on its packaging indicates that this product may not be treated as household waste. - Page 30 ENGLISH...
- Page 31 ENGLISH...
- Page 32 G0043781-002-A28646601...
