Summary of Contents for Diamond WCB/38-XS
- Page 1 03/2022 Mod: WCB/38-XS Production code: TFW400-S...
- Page 2 Model: WCB/38-XS Instruction manual 700-110103...
-
Page 3: Table Of Contents
Contents Important safety instructions Unpacking and installation Electrical connections Start-up of the cabinet Lock Operation TFW 365-2 Operation TFW 375 Internal light Water tray Carbon filter Changing position of shelves Door reversal Maintenance and cleaning Service Disposal... -
Page 4: Important Safety Instructions
Important safety instructions 1. To obtain full use of the cabinet, we recommend reading this instruction manual. 2. It is the user’s responsibility to operate the appliance in accordance with the instructions given. 3. Contact your dealer immediately in case of any malfunctions. 4. -
Page 5: Electrical Connections
Electrical connecting The cabinet operates on 230 V/50 Hz. The wall socket should be easily accessible. All earthing requirements stipulated by the local electricity authorities must be observed. The cabinet plug and wall socket should then give correct earthing. If in doubt, contact your local supplier or authorized electrician. -
Page 6: Operation Tfw 365-2
Operation model TFW 365-2 Connect the cabinet to a socket and turn on the switch on the control panel (POWER), see fig. 1.9. Fig. 1.9 When the cabinet is turned on, the display will show the current temperatures in the cabinet’s two chambers. -
Page 7: Operation Tfw 375
Operation model TFW 375 Connect the cabinet to a socket and turn on the switch on the control panel (POWER), see fig. 2.0. Fig. 2.0 When the cabinet is turned on, the display will show the current temperature in the cabinet. Set new temperature: Press this key and the set temperature will increase by 1°C for each pressure. -
Page 8: Water Tray
Water tray In order to prevent drying up of the wine corks due to low humidity the cabinet is supplied with a water tray, which should be placed at the top shelf, see fig. 1.3. Fig. 1.3 Carbon filter The cabinet is supplied with a carbon filter to prevent bad smell. This is placed at the rear wall inside the cabinet, see fig. -
Page 9: Door Reversal
Door reversal Open the door, remove the two screws in the bottom hinge and lift out the door, see fig. 2.4. Fig. 2.4 Move the the top hinge to the opposite side, see fig. 2.5. Fig. 2.5 Move the bottom hinge to the opposite side, see fig. 2.6. Fig. -
Page 10: Maintenance And Cleaning
Maintenance and cleaning Switch the cooler off at the socket. The cabinet must be periodically cleaned. Clean the external and internal surfaces of the cabinet with a light soap solution and subsequently wipe dry. External surfaces can be maintained using steel oil.
