Summary of Contents for Diamond Diverso WR-GP60-SS
- Page 1 10/2017 Mod: WR-GP60-SS Production code: PSF 600 G...
- Page 2 INSTRUCTIONS FOR USE AND INSTALLATION CAST IRON GRIDDLE PLATES PSF 400 G / PSF 600 G Made in France April 2013...
-
Page 3: Security Instructions
CAST IRON GRIDDLE PLATES PSF 400 G / PSF 600 G Congratulations for the acquisition of this upmarket appliance made in France. You chose an appliance which alloys the best technical qualities with a big user-friendliness. We wish you the biggest contentment 1. -
Page 4: Conformity Of Use
Power control knob Outlet for juices and fat Piezo power-on knob Juice collector tray Opening for lighting with a matchstick 3. CONFORMITY OF USE Use the device only to cook meat, bacon, fish, hamburgers, sausages, onions, shell- fishes, vegetables..., and also for fried eggs and omelettes… 4. - Page 5 While cooking, the temperature can be regulated using the control knob (n°1 on picture) from high flame to low flame in order to avoid over-cooking. A safety thermocouple cuts the gas supply if the burner is extinguished. The low flame of the appliance is pre-adjusted in the factory, it must not be changed.
- Page 6 The heat release rate of the appliance is PSF 400 G 3.2 kW PSF 600 G 6.4 kW For a use in natural gas, change the injectors. They are delivered in a small plastic bag placed in the package. Connect the appliance to the gas supply pipe, interposing a stop valve which enables the appliance to be insulated from the rest of the installation.
- Page 7 Gas category table, according to the country of destination of the appliance. Country of destination Category Pressures Diameter of injector France/Luxembourg II2E+3+ G20/G25 20/25 G30/G31 28-30/37 II2E+3B/P G20/G25 20/25 G30/G31 Germany II2E3B/P G30/G31 Austria II2H3B/P G30/G31 Belgium G30/G31 28-30/37 G20/G25 20/25 Sweden, Denmark, II2H3B/P...
- Page 8 Air adjustment Injectors were conceived to avoid any air adjustments and that whatever the gas you use. c) Use of device : Elements of command and display Command/Display Function Piezo Switches on the appliance (simultaneously with the set knob) (n°2 on picture) Set knob Switches on the appliance (knob pressed simultaneously with piezo) (n°1 on picture)
-
Page 9: Cleaning And Maintenance
d) Breakdown / repair: In case of breakdown or of damaged part, please call your after-sales service and confide any technical operation to qualified person. When you contact the after-sales service of your distributor or your store, give him the complete reference of your device (commercial name, type and serial number). This information appears on the visible descriptive plate behind the device. - Page 10 8. GUARANTEE Conditions of guarantee The guarantee applicable to any device is the commercial guarantee of the dis- tributor or the retailer. Please contact the store where you bought your device to know the precise conditions. The guarantee grants no right for damages. The dispositions which follow are not exclusive of the profit of the legal guarantee planned by articles 1641 and following ones of the Civil code relative to the defects and the latent defects.
- Page 11 Nomenclature PSF 400 G Spare parts PSF 400 G Code Pièce Spare part B02027+PTR Plaque fonte Cast iron plate 53125 Support brûleur Burner holder 53183SE Bac à jus Juice tray 53167 Ceinture Casing 53124 Bandeau Front panel A14077 Bouton Knob E02215 Piezo complet Piezo assembly...
- Page 13 Nomenclature PSF 600 G Spare parts PSF 600 G Code Pièce Spare part B02026+PTR Plaque fonte Cast iron plate 53126 Support brûleur Burner holder 53186SE Bac à jus Juice tray 53165 Ceinture Casing 53119 Bandeau Front panel A14077 Bouton Knob E02215 Piezo complet Piezo assembly...
