Replacing Modules
Replacing the Uplink Module
You must shut down the switch before replacing the M6PQ, M6PQ-E, or M12PQ uplink module.
Step 1
Power off the switch by removing the power cables from both of the power supplies installed in the switch.
Step 2
Verify that both LEDs on each power supply are off and that all of the other switch LEDs are off.
If any LEDs are on, look for a power supply that is still powered on and remove its power cable.
Step 3
Remove the cables from each of the ports on the uplink module. Be sure to label each cable for future refernce.
Step 4
Unscrew both captive screws on the front of the module.
Step 5
Holding both handles on the front of the module, slide the module out of the slot.
To prevent electrostatic discharge (ESD) damage to the module electronics, do not touch the electrical
Caution
connectors on the back side of the module. Also, to prevent any damage to the electrical connectors, prevent
them touching anything that can bend or break them.
Step 6
Place the module on an antistatic surface or inside an antistatic bag. If possible, repack the module in its shipping
materials for safe shipping or storage.
Step 7
Remove the replacement module from its packing materials and place it on an antistatic surface.
Hold the module by its two handles and do not touch the electrical connectors on its backside. Also, to protect the
electrical connectors, avoid letting them come in contact with anything other than the electrical connectors inside the
chassis.
Step 8
Holding the replacement module by its two handles, position the module with the electrical components on its backside
facing the open uplink-module slot.
Step 9
Slide the module all the way into the chassis until its front side comes in contact with the chassis. For the last 0.2 inches
(0.5 cm),carefully mount the module onto the chassis connectors by pushing more firmly, but do not force the module
if it does not move further (excessive force can damage the connectors).
Replacing the Uplink Module, on page 1
Replacing a Fan Module During Operations, on page 2
Replacing a Power Supply Module, on page 4
Replacing Modules
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the M6PQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cisco M6PQ

  • Page 1 Replacing a Power Supply Module, on page 4 Replacing the Uplink Module You must shut down the switch before replacing the M6PQ, M6PQ-E, or M12PQ uplink module. Step 1 Power off the switch by removing the power cables from both of the power supplies installed in the switch.
  • Page 2 If you are not able to push the module all the way into the slot, carefully slide the module out of the slot Note and check its electrical connectors for damage. If damaged, contact Cisco Technical Assistance for help. If undamaged, repeat Step 6 to reinstall the module.
  • Page 3 Replacing Modules Replacing a Fan Module During Operations If you are replacing the fan module while the chassis is not operating, you can skip this step. Note Captive screw Colored stripe specifying the airflow direction (burgundy for the port-side intake direction or blue for the port-side exhaust direction) Status (STS) LED Electrical connectors on the backside.
  • Page 4: Replacing A Power Supply Module

    If the STS LED does not turn on, slide the module out of the chassis, and visually check the electrical connectors on the back side of the chassis for damage. If damaged, contact Cisco Technical Assistance for help. If undamaged, repeat the previous step to reinstall the module.
  • Page 5: Removing A Dc Power Supply

    Replacing Modules Removing a DC Power Supply Step 4 If the power supply slot is to remain empty, install a blank power supply filler panel (part number N2200-P-BLNK). What to do next You are ready to install the replacement power supply. Removing a DC Power Supply You can remove one power supply while the other one provides power to the switch.
  • Page 6: Installing A Dc Power Supply

    Replacing Modules Installing a DC Power Supply • There must be an earth ground connection to the chassis that you are installing the replacement module. Typically, the chassis is grounded by its metal-to-metal connection with a grounded rack. If you need to ground the chassis, see Grounding the Chassis.
  • Page 7 Replacing Modules Wiring a 48 V DC Electrical Connector Block • All DC power supplies have reverse polarity protection. When you inadvertently connect the input power (+) to the DC PSU’s – terminal and the input power – to the DC PSU’s (+) terminal, the PSU will not be damaged and will operate fine after the input power feeds are correctly wired.
  • Page 8 Replacing Modules Wiring a 48 V DC Electrical Connector Block a) Push the orange plastic button on the top of the connector block inward toward the power supply. b) Pull the connector block out of the power supply. Step 3 Strip 0.6 inches (15 mm) of insulation off the DC wires that you are using.
