Table of contents SAFETY AND PRECAUTIONS 1. INTRODUCTION 2. PREPARATIONS 2.1 RECORD THE SERIAL NUMBERS 2.2 FIREWALL AND ROUTER SETTINGS 3. CONNECTING THE DEVICES 3.1 CONNECT THE INTERNET GATEWAY 3.2 CONNECTING OTHER DEVICE(S) 4. CONFIGURATION 4.1 CREATE SENTERAWEB INSTALLATION 4.2 ADD DEVICES TO A SENTERAWEB INSTALLATION 4.3 CONFIGURE EACH DEVICE MANUALLY 4.4 CONFIGURE ALL CONNECTED DEVICES AUTOMATICALLY TROUBLESHOOTING...
In case there are any questions that are not answered, please contact your technical support or consult a professional. UG-SIG-M-2-EN-000 - 01 / 10 / 2024 3 - 14 www.sentera.eu...
This document describes how to connect this offline network to the online SenteraWeb cloud by means of a Sentera internet gateway, model SIG-M-2. SenteraWeb is used primarily for easy configuration of Sentera products, but it can also be used as a cloud platform with many additional features: ■...
Sentera power supplies feature RJ45 sockets that simplify the wiring. On top of that they also offer protection against overvoltage and overload. This increases the safety of your installation. UG-SIG-M-2-EN-000 - 01 / 10 / 2024 5 - 14 www.sentera.eu...
Page 6
Do NOT connect 24 VDC to the Ethernet connector. This may destroy the unit! Fig. 4 Internet gateway and power supply 8 mm 24 VCC SEPS8 SIG-M-2 8 mm 8 mm 8 mm 24 VDC UG-SIG-M-2-EN-000 - 01 / 10 / 2024 6 - 14 www.sentera.eu back to the table of contents...
Page 7
85—264 VAC / 50—60 Hz Verify if the top green led (farthest from the red led) lights up. This indicates that the gateway is connected to SenteraWeb. UG-SIG-M-2-EN-000 - 01 / 10 / 2024 7 - 14 www.sentera.eu back to the table of contents...
Master Slave socket socket 24 VDC 8 mm Supply voltage 85—264 VAC / 50—60 Hz 8 mm 8 mm 8 mm 24 VDC UG-SIG-M-2-EN-000 - 01 / 10 / 2024 8 - 14 www.sentera.eu back to the table of contents...
SenteraWeb. 4.1 CREATE SENTERAWEB INSTALLATION ■ Register or log in at: https://www.senteraweb.eu/en/Account/Login - see Fig. 9. Fig. 9 Register or log in UG-SIG-M-2-EN-000 - 01 / 10 / 2024 9 - 14 www.sentera.eu back to the table of contents...
Page 10
Fig. 9.2 Serial number ■ Complete all of the obligatory (*) fields in the installation form – see Fig 9.3. Fig. 9.3 Installation form UG-SIG-M-2-EN-000 - 01 / 10 / 2024 10 - 14 www.sentera.eu back to the table of contents...
(A new Sentera device should have Modbus address 1 and default firmware settings.) – see Fig. 10.2. Fig. 10.2 Serial number and location UG-SIG-M-2-EN-000 - 01 / 10 / 2024 11 - 14 www.sentera.eu back to the table of contents...
– this is in detail explained in the next chapter. If you do not want application specific firmware, it is possible to manually configure the connected device(s). UG-SIG-M-2-EN-000 - 01 / 10 / 2024 12 - 14 www.sentera.eu...
Sentera provides different solutions for a variety of applications. Select your solution on the website and link your installation to the solution ID. UG-SIG-M-2-EN-000 - 01 / 10 / 2024 13 - 14 www.sentera.eu...
Verify that the Ethernet cable has connection to the internet ► ► Verify that all firewall and router settings are configured properly (see chapter 2.2) UG-SIG-M-2-EN-000 - 01 / 10 / 2024 14 - 14 www.sentera.eu back to the table of contents...
