- Page 1 DIG-M SENTERA INTERNET GATEWAY Mounting and operating instructions...
- Page 2 PRODUCT DESCRIPTION ARTICLE CODES INTENDED AREA OF USE TECHNICAL DATA STANDARDS WIRING AND CONNECTIONS MOUNTING INSTRUCTIONS IN STEPS VERIFICATION OF THE INSTALLATION INSTRUCTIONS TRANSPORT AND STORAGE WARRANTY AND RESTRICTIONS MAINTENANCE MIW-DIG-M-EN-000 - 22 / 04 / 2019 2 - 8 www.sentera.eu...
- Page 3 In case there are any questions that are not answered, please contact our technical support or consult a professional. MIW-DIG-M-EN-000 - 22 / 04 / 2019 3 - 8 www.sentera.eu...
- Page 4 DIN RAIL MOUNTED SENTERA INTERNET GATEWAY PRODUCT DESCRIPTION DIG-M is a Modbus RTU - Internet gateway intended for connecting Sentera devices to the Internet in order to monitor and configure them via the Sentera Web Server interface. ARTICLE CODES Code...
- Page 5 8 mm MOUNTING INSTRUCTIONS IN STEPS Before you start mounting the DIG-M, read carefully “Safety and Precautions” and follow these steps: Slide the unit along the guides of a standard 35 mm DIN rail and fix it to the rail by means of the black locking clip on the enclosure.
- Page 6 Connect the Sentera slave devices via Modbus RTU on the left RJ45 socket. If applicable, the BMS or external Modbus RTU master can be connected via the right RJ45 socket. The DIG-M unit needs PoM (24 VDC). So either, the Slave or Master channel must be powered with 24 VDC. ATTENTION Do not connect both circuits with PoM 24 VDC power supply simultaneously! Fig.
- Page 7 1 2 3 4 5 Reset button Press and hold the button for 2 seconds to reset the DIG-M device to its default values (Default Static-IP: 192.168.1.123, Default Connection Type: Ethernet, Default Connection Mode: DHCP).
- Page 8 Green LED1 indicates that the unit is supplied and that the Modbus RTU communication with slave devices is active. ■ Green LED2 indicates active communication with the Internet. i.e. DIG-M successfully communicates with the Sentera Web-Server sending parameters to the Cloud.
