- Page 1 Eastron SDM530Y User manual 2018 V1.2 Three Phase Multifunction Din Rail Meter SDM530Y User Manual V1.1 2018 EASTRON ELECTRONIC. ALL RIGHTS RESERVED. www.eastrongroup.com...
- Page 2 Eastron SDM530Y User manual 2018 V1.2 Statement All rights reserved. Without the written permission of the company, no paragraphs or chapters in this manual can be extracted, copied or reproduced in any form. Otherwise, the violator shall bear all consequences.
-
Page 3: Table Of Contents
Eastron SDM530Y User manual 2018 V1.2 Contents Chapter One. Product Overview 1.1 Product Introduction -----------------------------------------------------------------------------3 1.2 Product Feature -----------------------------------------------------------------------------------3 1.3 Application Scenarios ----------------------------------------------------------------------------3 Chapter Two. Technical Specification Parameters 2.1 Technical Parameters -----------------------------------------------------------------------------3 2.2 Measurement Accuracy --------------------------------------------------------------------------4 2.3 RS485 Communication ---------------------------------------------------------------------------4 2.4 Performance Standard ----------------------------------------------------------------------------5... -
Page 4: Chapter One. Product Overview
The reactive power, apparent power can be read by Modbus. SDM530Y is easy to install. With battery installed inside, the value on the meter still can be read when grid power is off. SDM530Y is suitable for real-time power monitoring system and has the characteristics of multi-function, multi-purpose, high stability and long life. -
Page 5: Chapter Two. Technical Specification Parameters
Eastron SDM530Y User manual 2018 V1.2 Chapter Two. Technical Specification Parameters 2.1 Technical Parameters Input Voltage: Basic Value: 230V AC Operating Voltage Range: 80-120% Basic Value Input Current: Basic Value: 5A Max.Current: 100A Over Current Withstand: 20 Imax for 0.5s ... -
Page 6: Performance Standard
Eastron SDM530Y User manual 2018 V1.2 2.4 performance standard Operating Humidity ： ≤90% Storage Humidity ： ≤95% Operating Temperature ： -25℃~+55℃ Storage Temperature ： -40℃~+70℃ International Standard ： GB-T 17215/ IEC62053-22/ EN50470-1/3 Accuracy Class ： Class 0.5S ... -
Page 7: Chapter Three. Operating Instructions
Eastron SDM530Y User manual 2018 V1.2 Chapter Three. Operating instructions 3.1 Panel Instructions and Key Operation Instructions 3.1.1 Panel Instructions After the correct connection, it will enter the normal measurement state, and the screen is displayed as follows: 1st Screen... -
Page 8: Prepaid Function Description
Eastron SDM530Y User manual 2018 V1.2 Measurement mode, short press: invalid; Long press: enter the setting mode; Setting mode, short press: move the cursor (the cursor is flashing digital bit); Long press: menu item selection confirmation and parameter modification confirmation. -
Page 9: Measurement Parameters
Eastron SDM530Y User manual 2018 V1.2 automatically disconnected after the user has consumed the emergency amount. 3.3 Measurement Parameters It can be viewed by pressing the button: Balance Accumulated Used Amount Accumulated Used Electricity Total Active Power Recharge amount Communication Address ... -
Page 10: Basic Setting
Eastron SDM530Y User manual 2018 V1.2 Communication Baud Rate Example: 9600 Communication Parity Bit Example: None Explanation: Parity Bit “N”= none; “E” = even; “O” = odd Pulse Constant Example: 1000 Software Version Example: 12 01.00 Fault code Example: Err-01 3.4 Basic Setting... - Page 11 Eastron SDM530Y User manual 2018 V1.2 Setting failed, display: err Password Enter password into the settings screen Default password: 1000 Press select number, press to select shift. Long press to enter the setup system. Communication Address Default communication address: Communication address range:...
- Page 12 Eastron SDM530Y User manual 2018 V1.2 Long press to enter the parity bit setting interface, and the current character will flash. Then press to select the new parity bit. Long press to confirm settings. Pulse Constant Default: 1000imp/kWh Optional: 1000, 100,10,1.
- Page 13 Eastron SDM530Y User manual 2018 V1.2 Long press to enter auto- scrolling display time setting interface, and the current character will flash. Then press to select the new auto-scrolling display time. Finally, long press confirm settings. Backlight lighting time Default : 60 min Optional : off,on,5,10,20,30,60,120.
