- Page 1 Kondensationstrockner/Condensation dryer Serie/Series KT 20 KT 45 DE Betriebsanleitung EN instruction manual DA Betjeningsvejledning ES Manual de instrucciones FI Käyttöohje FR Mode d’emploi IT Istruzioni per l’uso NL Bedieningshandleiding NO Bruksanvisning PL Instrukcja eksploatacji PT Manual de instruções V 09-2023...
-
Page 2: Table Of Contents
EN - INSTRUCTION MANUAL 1 Device models ....................16 2 Product overview .................... 17 3 Control panel ....................18 4 About this operating manual ................. 19 5 Product description ..................19 6 Safety ....................... 20 7 Transport and installation ................22 8 Device operation and control................. -
Page 3: Product Overview
Model Main features KT 20 Extendable handle, carrier handle, 2 castors KT 45 Fixed handle, 2 large transport wheels 2 Product overview Illustration 1: Front view Handle Recess for stacking dryers Transport wheel Base Inlet air grille with filter holder Carrier handle (KT 20 only) Illustration 2: Rear view Knurled screw for handle ad-... -
Page 4: Control Panel
Cable winder Control panel Power meter (KT 20 only) Port for optional hygrostat (KT 20 only) 3 Control panel Illustration 3: Control panel Operating hours counter Port for optional hygrostat (KT 45 only) Power meter (KT 45 only) Red fault indicator Yellow indicator Device switch Green indicator... -
Page 5: About This Operating Manual
4 About this operating Contacting DANTHERM GmbH manual See Technische Daten/Technical Data. This instruction manual (hereinafter referred to as the manual) enables 5 Product description the company operating the device to work safely with the condensation The device dehumidifies the air in the dryer (hereafter referred to as the room. -
Page 6: Safety
Type plate with limited physical, sensory or men- tal faculties. Before operating the device, users must have read and understood this operating manual. Reasonably foreseeable misuse The device must not be used: ■ In rooms/spaces that are not enclosed, or outdoors ■... - Page 7 explosion, fire, poisoning or other the collecting vessel or in the con- injury. The refrigerant is pressurised. densate drain hose for a longer period of time. Only operate the device in rooms larger than 4 m Operating conditions Never drill holes into the device, The device is intended for mobile or and do not use welding equipment stationary use indoors, on construc-...
-
Page 8: Transport And Installation
NOTICE! Ensure that the air can Connecting hygrostat circulate freely around and through the device. Do not cover the air 1. Connect the hygrostat (HEYLO prod. no. 1110552) to the port at inlet and outlet openings. The dis- the rear of the device. -
Page 9: Device Operation And Control
8 Device operation and in continuous mode until the tar- get humidity is reached. control Stacking devices Prior to switching on For operation or storage, it is permis- 1. Make sure that the device is not sible to combine maximum two devic- standing on a wet ground and en- es in a stack. -
Page 10: Maintenance And Care
9 Maintenance and care 1. Set the device switch to position [II]. WARNING! Risk of injury from The condensate pump starts inhaling harmful substances to pump the condensate Depending on the location of op- through the drain hose into eration, the components of the de- the drain or the on-site drain / vice may become contaminated... - Page 11 4. Remove the filter holder by the a special cleaner recessed grip. To remove encrustations, use the cooling coil cleaner from HEYLO. Strictly follow the use instructions for the product. 1. Let the cleaned components dry. 2. Mount the covers in the same way as they were installed at the facto- 5.
-
Page 12: Troubleshooting
3. Disconnect the condensate hose from the condensate pump. 4. Loosen the two securing screws of the condensate pump and pull the pump from the device (for KT 20: to the side; for KT 45: toward the front). The connection remains attached to the device, as it is sufficiently long. - Page 13 Before starting work, allow hot com- WARNING! Risk of poisoning by re- ponents to cool down. frigerant, injury from burns, crushing or electric shock during troubleshoot- Faults and malfunctions during operation All work in connection with trouble- shooting and repairs must be carried In the event of a fault or malfunction, out by authorised personnel or the refer to the table below.
-
Page 14: Repair
Fault/malfunction Possible cause Remedy Device heats up, Insufficient air circulation; Ensure that the air can circu- makes a lot of function only available late freely; clean evaporator noise and dehu- when housing is closed and filter midifies poorly Water escaping Leak in condensate sys- Run condensate pump test from device... -
Page 15: Ec Declaration Of Conformity
EC Declaration of Conformity EC Declaration of Conformity in accordance with Machinery Directive 2006/42/EC Annex II 1.A Manufacturer: HEYLO GmbH Im Finigen 9 28832 Achim, Germany Product: Condensation dryer Type: KT 20 / KT 45 We herewith declare that the machine conforms to all relevant requirements of the following EU Directives: ■...
