Summary of Contents for iTechworld PS2000
-
Page 3: Table Of Contents
CONTENTS Product Overview Overview Package Contents XT90 Port AC Input Overload Protection LCD Features UPS Mode UPS Connections Charging Solar Panel Charging AC Charger Charging Car/Vehicle Charging Fault Resolution Specifications Safety Precautions Contact Us Back Page... -
Page 4: Product Overview
PRODUCT OVERVIEW Package Contents XT90 to 50A Anderson AC Charger Car Charger User Guide Cable Storage Bag MAIN POWER CONTROL AIR INTAKE/OUTLET LIGHT CONTROL AC 240V OUTPUT CONTROL USB CONTROL XT90 INPUT PORT DC CONTROL AC 240V INPUT PORT LCD DISPLAY OVERLOAD PROTECTION... - Page 5 POWER CONTROL BUTTON This is the master power button, a long press to turn on and a long press to turn off the unit (hold the button until the screen turns on/off). When not in use, please turn the unit off. USB CONTROL BUTTON Make sure the power station is on before pressing the USB control button.
-
Page 6: Lcd Screen Display
AIR INTAKE/OUTLET (BUILT-IN COOLING FAN) The PS2000 utilises an internal cooling fan to ensure it operates within the appropriate temperature range. When the PS2000 experiences a high output/ input, it automatically turns on the fan. The fan may turn on intermittently to keep the internal temperatures within the operating range. -
Page 7: Xt90 Port
Use the included wall socket to get 1100W fast charging, which can fully charge the PS2000 from 0 to 100% in 2 hours. The PS2000 should be charged directly by the wall socket, please do not use extension cords. Do not use the same socket to connect other devices to when charging the PS2000. -
Page 8: Lcd Features
LCD FEATURES REMAINING DISCHARGE TIME AC OUTPUT STATUS FAN STATUS USB-C OUTPUT STATUS HIGH/LOW TEMPERATURE USB OUTPUT STATUS BATTERY LEVEL INDICATOR AC CHARGING STATUS TOTAL INPUT POWER XT90 INPUT STATUS TOTAL OUTPUT POWER DC OUTPUT STATUS LED LIGHT STATUS CIGARETTE PORT OUTPUT STATUS... -
Page 9: Ups Mode
UPS CONNECTIONS As shown in the figure below, connect the PS2000 between the wall socket and the electrical appliances, ensuring the power of the PS2000 is ON. When you turn on the electrical appliances, power will be taken directly from the grid. -
Page 10: Charging
CHARGING SOLAR PANEL CHARGING Do not charge the PS2000 via a solar panel that has a voltage exceeding 50V. Supports 500W max solar input (solar panels not included), the charging time depends on the solar panel input. To ensure proper operation, please verify that there is no regulator in the line. -
Page 11: Ac Charger Charging
AC CHARGER CHARGING Use the AC charger provided to charge this unit. It will only require 2 hours to fully charge the PS2000. AC Input XT90 CAR/VEHICLE CHARGING It' s important to use the car charger that was provided with the unit for charging. -
Page 12: Fault Resolution
3 - If the overload protector has not been and buzzes activated, proceed as follows: directly press the AC output button to restore the output function. The PS2000 has Remove all loads, disconnect the power surpassed the source from this product, and wait for the unit... -
Page 13: Specifications
SPECIFICATIONS General Specifications Model name PS2000 Dimensions 392 x 279 x 323mm Weight 22.3Kg MPPT input 11.5V-50V 500W Max 50/60Hz (frequency switch available), rated at AC output 2000W Pure Sine Wave. Built in overload and short circuit protection. USB output 2 x 5V/2.4A... -
Page 14: Safety Precautions
SAFETY PRECAUTIONS For safe operation and optimal performance, the PS2000 Portable Power Station must be operated correctly. Please carefully read, under stand, and follow all instructions and guidelines in this user guide. Failure to follow these instructions may result in damage to the unit, property, death, or serious injury. -
Page 15: Limitations Of Use
WARNING: Do not drop the power station. WARNING: When not using the power station, turn off the power and unplug the power cord. WARNING: Do not use the power station and its accessories to connect equipment if there is a defect. WARNING: Do not use the power station in an environment where it will get wet, the unit is not waterproof. -
Page 16: Contact Us
When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
