iTechworld PS1400 PRO User Manual

Portable power station
Hide thumbs

Advertisement

Quick Links

Download this manual
USER GUIDE
PS1400 PRO
PORTABLE POWER STATION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PS1400 PRO and is the answer not in the manual?

Questions and answers

Related Manuals for iTechworld PS1400 PRO

Summary of Contents for iTechworld PS1400 PRO

  • Page 1 USER GUIDE PS1400 PRO PORTABLE POWER STATION...

  • Page 2: Table Of Contents

    CONTENTS Product Overview Button Functions LCD Features Fault Resolution UPS Mode UPS Connections EB1536 Expansion Battery Connection Solar Panel Charging AC 240V/Wall Plug Charging Car/Vehicle Charging General Specifications Battery Specifications Safety Precautions Contact Us Back page...

  • Page 3: Product Overview

    PRODUCT OVERVIEW MAIN POWER CONTROL AC 240V OUTPUT PORTS USB CONTROL AC 240V OUTPUT CONTROL LIGHT CONTROL PARALLEL PORTS DC CONTROL AC 240V INPUT PORT LCD DISPLAY XT60 INPUT PORT AIR INTAKE/OUTLET OVERLOAD PROTECTION...

  • Page 4: Button Functions

    BUTTON FUNCTIONS POWER CONTROL BUTTON: This is the master power button, a long press to turn on and a long press to turn off the unit (hold the button until the screen turns on/off). When not in use, please turn the unit off. USB CONTROL BUTTON: Make sure the power station is on before pressing the USB control button.
  • Page 5 AIR INTAKE/OUTLET (BUILT-IN COOLING FAN): The PS1400 PRO utilises an internal cooling fan to ensure it operates within the appropriate temperature range. When the PS1400 PRO experiences a high output/ input load, it automatically turns on the fan. The fan may turn on intermittently to keep the internal temperatures within the operating range.

  • Page 6: Overload Protection

    Use the included wall socket to get 1500W fast charging, which can fully charge the PS1400 PRO from 0 to 100% in 1 hour. The PS1400 PRO should be charged directly by the wall socket, please do not use extension cords.

  • Page 7: Lcd Features

    LCD FEATURES: REMAINING DISCHARGE TIME BATTERY LEVEL INDICATOR EXPANSION BATTERY STATUS BATTERY PROGRESS BAR PARALLEL OPERATION STATUS AC OUTPUT STATUS TOTAL INPUT POWER USB OUTPUT STATUS AC CHARGING STATUS USB-C OUTPUT STATUS XT60 INPUT STATUS CIGARETTE LIGHTER OUTPUT STATUS HIGH/LOW TEMPERATURE LED LIGHT STATUS FAN STATUS TOTAL OUTPUT POWER...

  • Page 8: Fault Resolution

    FAULT RESOLUTION Status Explanation Resolution 1 - Begin by removing the output device. 2 - Next, check whether the overload protector is activated. If it’ s activated, follow these sub- The output exceeds steps: press the overload protection button, the standard and it’ s after that, press the AC output button.

  • Page 9: Ups Mode

    UPS MODE The PS1400 PRO has a bypass function, which means power will not pass through the battery; it will be taken directly from the AC output. In this mode, the power source is the power grid, when there is an emergency power outage, the power source will switch to the battery within 1Oms and protect the connected appliance.

  • Page 10: Eb1536 Expansion Battery Connection

    After successful parallel connection, the PS1400 PRO can commence charging or discharging. Keep in mind, the PS1400 PRO will charge at a slower rate when it' s almost full and will release power faster when used. If there' s no incoming charge, the unit with a higher state of charge will charge the unit with a lower state of charge.

  • Page 11: Solar Panel Charging

    To ensure proper operation, please verify that there is no regulator in the line. You will need to input unregulated solar power into the PS1400 PRO as it already contains a built-in regulator. THE AREA OF CHARGING...

  • Page 12: Ac 240V/Wall Plug Charging

    AC CHARGER CHARGING Use the AC charger provided to charge this unit. It will only require 1 hour to fully charge the PS1400 PRO. PS1400 PRO CAR/VEHICLE CHARGING it’ s important to use the car charger that was provided with the unit for charging.

  • Page 13: General Specifications

    GENERAL SPECIFICATIONS Model name PS1400 PRO Dimensions 218*403*295mm Weight 17.5Kg Capacity 1536Wh Max parallel capacity 4608Wh XT-60 Input 12-90V 1200W max AC output 50/60Hz (frequency switch available), rated at 1800W Pure Sine Wave. Built in overload and short circuit protection.

  • Page 14: Safety Precautions

    SAFETY PRECAUTIONS For safe operation and optimal performance, the PS1400 PRO Portable Power Station must be operated correctly. Please carefully read, under stand, and follow all instructions and guidelines in this user guide. Failure to follow these instructions may result in damage to the unit, property, death, or serious injury.

  • Page 15: Limitations Of Use

    WARNING: Do not drop the power station. WARNING: When not using the power station, turn off the power and unplug the power cord. WARNING: Do not use the power station and its accessories to connect equipment if there is a defect. DANGER: Never smoke or allow a spark or flame in the vicinity of the power station.

  • Page 16: Contact Us

    When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
