- Page 1 USER GUIDE PS300 PORTABLE POWER STATION...
-
Page 2: Table Of Contents
CONTENTS Product Overview Button Functions LCD Features Fault Resolution AC 240V/Wall Plug Charging Solar Panel Charging Car/Vehicle Charging General Specifications Battery Specifications Safety Precautions Contact Us Back page... -
Page 3: Product Overview
PRODUCT OVERVIEW AC Charger Car Charger User Manual Cable Storage LCD DISPLAY DC CONTROL DC CONTROL AC 240V OUTPUT BUTTON CIGARETTE LIGHTER OUTPUT AC 240V OUTPUT PORT DC OUTPUT PORT AIR OUTLET AIR INTAKE DC INPUT PORT... -
Page 4: Button Functions
The device will remain active and won' t enter sleep mode if it is either charging or discharging. AIR INTAKE/OUTLET (BUILT-IN COOLING FAN): The PS300 utilises an internal cooling fan to ensure it operates within the appropriate temperature range. When the PS300 experiences a high output/input... - Page 5 Use the included wall socket to get 60W fast charging, which can fully charge the PS300 from 0 to 100% in 5 hours. To charge your PS300 in 2 hours, simultaneously connect the 100W USB-C while the unit has 60W AC input.
-
Page 6: Lcd Features
If the overload protector has been triggered, and you need to restore the AC input, please follow these instructions: First, ensure that the PS300 is turned off, and unplug all connected devices and ports from it. Confirm that all connected ports are in their standard, normal state. -
Page 7: Fault Resolution
Use the AC charger provided to charge this unit. It will only require 5 hours to fully charge the PS300. SOLAR PANEL CHARGING: Do not charge the PS300 via a solar panel that has a voltage exceeding 30V. Supports 80W max solar input (solar panels not included), the charging time depends on the solar panel input. -
Page 8: Car/Vehicle Charging
THE AREA OF CHARGING DC 5521 PS300 50A Anderson to DC5521 Solar Panel (Not included) (Included) CAR/VEHICLE CHARGING It' s important to use the car charger that was provided with the unit for charging. Car chargers usually provide lower power outputs, typically around 90-120 watts. -
Page 9: General Specifications
GENERAL SPECIFICATIONS Model name PS300 Dimensions 248*164*169mm Weight 3.4Kg DC5521 input 13V-30V 80W Max AC output 50/60Hz (frequency switch available), rated at 300W Pure Sine Wave. Built in overload and short circuit protection. USB output 2 x 5V/2.4A USB QC3.0 output... -
Page 10: Safety Precautions
SAFETY PRECAUTIONS For safe operation and optimal performance, the PS300 Portable Power Station must be operated correctly. Please carefully read, under stand, and follow all instructions and guidelines in this user guide. Failure to follow these instructions may result in damage to the unit, property, death, or serious injury. - Page 11 WARNING: Do not drop the power station. WARNING: When not using the power station, turn off the power and unplug the power cord. WARNING: Do not use the power station and its accessories to connect equipment if there is a defect. DANGER: Never smoke or allow a spark or flame in the vicinity of the power station.
-
Page 12: Contact Us
When it comes to energy storage and creation at iTechworld, we take pride in being one of the biggest names in the industry. Based in Australia, we are a family-owned and operated business. With many more innovative products on the horizon we are committed to constantly raising the bar to provide bigger and better benefi ts to all our customers Australia-wide.
