Wave
Thank You!
Thank you for purchasing the PAR Wave
terminal. With technology specifically
designed for your environment, your
success is our passion.
For Product information and full user Guide visit:
1
Examine The Shipment
Please ensure all
equipment is
present.
PAR Wave Terminal
removing terminal from box
Remove the terminal from the box,
remove packaging. Fold bo�om of
pedestal out and �ghten two
bo�om.
Philips screws on stand
8383 Seneca Turnpike New Har�ord, NY 13413 | 770509201B
Report any missing
or damaged equip-
ment to your PAR
Salesperson or PAR
Channel Partner.
Power Cord
Adapter
Power Indicator
PAR WAVE Quick Reference Guide
h�ps://support.partech.com/
2
Inventory Components
Ensure you have the items
listed below in your order.
included with every order)
Power Bu�on
Addi�onal I/O Ports
VESA Adapter Plate
(op�onal - may not be
I/O Ports Cover
Cable Well Cover
h�ps://support.partech.com/
