EXPLORE HOME UNIVERSAL AVALINE U428652 Instruction Sheet

U428652
U428A652
Thank you for purchasing this quality product. Be sure to check all packing material carefully
for small parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not
damaged during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and
water solution applied on a damp cloth. The cloth should not be excessively wet. Polish finish with a
soft cloth and an industry recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of
furniture for stain residue and rough surfaces and also check for staples or nails left after removing
the packaging material. The manufacturer will not be held responsible if preventative steps are not
taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any
assembly parts or hardware. Read the instruction sheet and parts list carefully. Remove all staples
and screws used for packaging carefully using pliers (or) screwdrivers to prevent injury and
scratching or damaging flooring.
(4) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up.
They should be periodically inspected and re-tightened to prevent damage to the furniture (or)
personal property or cause injury. Always check to be sure all hardware on this list and the above
mentioned components is attached to the furniture properly and kept tightened at all times.
PARTS LIST:
# Description
A
Table Top
C Leaf Bags
Assembly Procedure
Unpack, inspect, and read assembly instruction carefully. Lay out the parts and hardware. Make sure
the quantity of each is correct.
Step 1: Turn the Table top (A) upside down and put it on a soft and smooth surface to avoid damage
or being scratched. Then attach Legs (B) to Table top (A) following the below sketch with Hex head
bolt (1), Spring washer (2) and Flat washer (3). Tighten all bolts securely with Wrench (4).
Step 2: Turn the table upright. Unlock the Table top (A), take off the table leaves (D) and put them in
Leaf bags (C) when Leaves are not in use. Then lock the table top.
Note: If mismanaged, installing and removing table leaf may damage the table. Please use caution
and delicate handling when installing and removing table leaf to prevent damaging the table top
surface and edges. It is best two persons are involved when installing or removing table leaf.
Assembly is now complete.
INSTRUCTION SHEET
Qty. #
B
1pc
2pcs D
: (Please follow the sketches below.)
AVALINE DINING TABLE
VOLPI DINING TABLE
Description
Legs
Table Leaves
Qty.
2pcs
2pcs
