EXPLORE HOME Universal 833960 Instruction Sheet

833960/921/964/965
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material.
The manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for
packaging carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up. They should be
periodically inspected and re-tightened to prevent damage to the furniture and (or) personal property or cause
injury. Always check to be sure all hardware on this list and the above mentioned components is attached to
the furniture properly and kept tightened at all times.

PARTS LIST:

# Description
A Console
C Lower Back Panel
E Left Pier Panel
G Console shelf
I Left Pier Bookcase
K Hardware Pack

Assembly Procedure

Step 1: Unpack, inspect, and read assembly instruction carefully. Lay out the parts and hardware.
Make sure the quantity of each is correct.
Step 2: Connect the upper back panel (B) to the lower back panel (C) with allen head bolts (2) using
allen wrench (1) from hardware pack (K).
Step 3: Attach the hutch top (D) to the upper back panel (B) with allen head bolts (2) using allen
wrench (1) from hardware pack (K).
Step 4: Connect lower back panel (C), upper back panel (B) and hutch top (D) to left pier panel (E)
and right pier panel (F) with allen head bolts (2) using allen wrench (1).
Step 5: Assemble the shelves (G) to console (A) with shelf pin (3) and wood screws (4) using
screwdriver (not provided).
Step 6: Disregard this step when hutch is not in use. Put the hutch onto console (A) with mending
plates (6), wood screws (5) by screw driver (Not provided). Adjust the levelers if nessesary.
Step 7: Assemble the shelves (H) to bookcase (I & J) with shelf pin (3) and wood screws (4) using
screwdriver (not provided). Move the bookcase close to the console. Adjust the levelers to
make them aligned.
Note: It is best for two or more persons are involved.
Assembly is now complete.
INSTRUCTION SHEET
Qty. #
1pc B
1pc D
1pc F
4pcs H
1pc J
1bag
: (Please follow the sketches below.)
Wall Console/Hutch/Bookcase
Description
Upper Back Panel
Hutch Top
Right Pier Panel
Bookcase shelf
Right Pier Bookcase
Qty.
1pc
1pc
1pc
4pcs
1pc
