AG Neovo IFP6504E-AE User Manual

4k uhd interactive display
Hide thumbs Also See for IFP6504E-AE:
Table of Contents

Advertisement

Quick Links

Download this manual
IFP6504E-AE 4K UHD Interactive Display
User Manual
www.agneovo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IFP6504E-AE and is the answer not in the manual?

Questions and answers

Related Manuals for AG Neovo IFP6504E-AE

Summary of Contents for AG Neovo IFP6504E-AE

  • Page 1 IFP6504E-AE 4K UHD Interactive Display User Manual www.agneovo.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ................1 Federal Communications Commission (FCC) Notice (U.S. Only) ............1 Polish Center for Testing and Certification Notice ..................1 Electric, Magnetic and Electromagnetic Fields ("EMF") ................2 Information for U.K. only ........................... 3 North Europe (Nordic Countries) Information ................... 4 End-of-Life Disposal ..........................
  • Page 3 TABLE OF CONTENTS 2.3.2 Connecting a Microphone ....................... 28 2.3.3 Connecting Audio Equipment ....................29 2.4 Connecting a Display Device ......................30 2.5 Connecting to a Wired Network ......................31 2.6 Connecting USB Interface Devices ....................31 2.7 Connecting a MicroSD Card ....................... 32 2.8 Attaching Touch Pens .........................
  • Page 4 TABLE OF CONTENTS CHAPTER 7: SPECIFICATIONS ..............74 7.1 Display Specifications ........................74 7.2 Display Dimensions ..........................75...

  • Page 5: Safety Information

    SAFETY INFORMATION Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Wymagania Polskiego Centrum Badañ I Certyfikacji

    SAFETY INFORMATION Wymagania Polskiego Centrum Badañ i Certyfikacji Urz¹dzenie powinno byæ zasilane z gniazda z przy³¹czonym obwodem ochronnym (gniazdo z ko³kiem). Wspó³pracuj¹ce ze sob¹ urz¹dzenia (komputer, monitor, drukarka) powinny byæ zasilane z tego samego Ÿród³a. Instalacja elektryczna pomieszczenia powinna zawieraæ w przewodzie fazowym rezerwow¹ ochronê przed zwarciami, w postaci bezpiecznika o wartoœci znamionowej nie wiêkszej ni¿...

  • Page 7: Information For U.k. Only

    SAFETY INFORMATION Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fit new fuse which should be a BS 1362 5A,A.S.T.A.

  • Page 8: North Europe (Nordic Countries) Information

    SAFETY INFORMATION How to connect a plug The wires in the mains lead are colored in accordance with the following code: BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN & YELLOW - “EARTH” (“E”) • The GREEN & YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E”...

  • Page 9: End-Of-Life Disposal

    SAFETY INFORMATION End-of-Life Disposal Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old display from your local dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.

  • Page 10: Turkey Rohs

    SAFETY INFORMATION Batteries For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in accordance with legislation. Please contact your local authority for details on the collection and recycling schemes.

  • Page 11: Precautions

    PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence of a potential hazard that could result in personal injury or damage to the product. This icon indicates important operating and servicing information. Notice y Read this User Manual carefully before using the interactive display and keep it for future reference.

  • Page 12: Cautions When Using

    PRECAUTIONS Cautions When Using y Use only the power cord supplied with the interactive display. y The power outlet should be installed near the interactive display Warning: and be easily accessible. y If an extension cord is used with the interactive display, ensure Unplug the power cord from the power outlet and that the total current consumption plugged into the power outlet...

  • Page 13: Notice For The Interactive Display

    PRECAUTIONS Notice for the Interactive Display y In order to maintain the stable luminous performance, it is recommended to use low brightness setting. y Due to the lifespan of the lamp, it is normal that the brightness quality of the interactive display may decrease with time.

  • Page 14: Chapter 1: Product Description

    (Type H05W-F, 2G or IFP6504E-AE Quick Start Guide 3G, 0.75 or 1 mm should be IFP6504E-AE 4K UHD Interactive Display used). ♦ You might like to save the package box and packing HDMI Cable (1.8M) USB Cable material for shipping the display.

  • Page 15: Preparing For The Installation

    PRODUCT DESCRIPTION Wall Mount Wall Mount Screw Package 1.3 Preparing for the Installation • Due to the high power consumption, always use the plug Warning: exclusively designed for this product. If an extended line is required, please consult your service agent. ♦...

  • Page 16: Vesa Grid

    PRODUCT DESCRIPTION 1.4.1 VESA Grid Model Name VESA Grid Note: IFP6504E-AE 500(W) x 400(H)mm ♦ For the wall-mounting kit, use M6 mounting screws (having Caution: a length 10 mm longer than To prevent the display from falling: the thickness of the mounting bracket) and tighten them ♦...
  • Page 17 PRODUCT DESCRIPTION Keep the wall mount bracket level and mark the four wall mount screw hole locations on the wall. Drill four small holes on the mounting location with the length and width 50mm x 10mm for concrete wall or 50mm x 5.5mm for stud wall.

  • Page 18: Ventilation Requirements For Enclosure Locating

    PRODUCT DESCRIPTION Secure the dual wall mount with the four supplied bolts through Note: the washers on the wall interactive display. Dual Wall Mount x 2 ♦ Keep clearances around the interactive display according to the minimum dimensions as illustrated. ♦...

  • Page 19: Interactive Display Overview

    PRODUCT DESCRIPTION 1.5 Interactive Display Overview 1.5.1 Control Panel Motion sensor VOL+ button Increases volume. Detects a person approaching. MENU Remote control sensor and LED Opens the Shortcuts menu. indicator Receives command signals from the HOME remote control. Returns to the Home screen. LED indicator: Return - Green: The system is turned on.

  • Page 20: Input/Output Terminals

    PRODUCT DESCRIPTION 1.5.2 Input/Output Terminals 900mA) 900mA) FRONT FRONT USB 3.0 USB 3.0 TOUCH 2 Type-C HDMI (A/PC) (A/PC) (for Android only) Type-C OUT USB 3.0(A) 900mA) MIC IN LINE OUT OPTICAL RS232 HDMI OUT LAN IN LAN OUT...
  • Page 21 PRODUCT DESCRIPTION USB 3.0 LAN OUT Connects to a USB interface device For internet connection with an Ethernet and charges the device (5V/900mA). cable. TOUCH 2 (USB Type-B) LAN IN Connects USB for touch screen control. For internet connection with an Ethernet cable.

  • Page 22: Remote Control

    PRODUCT DESCRIPTION 1.6 Remote Control Power button: Turns the system on or shuts down. 1.6.1 General Functions Mute button: Turns the mute function on or off. Home button: Returns to the Home screen. Slide menu button: Opens the Slide menu. [ ] [ ][ ][ ] Navigation buttons: Navigates through the Settings menu and adjusts...

  • Page 23: Inserting The Batteries In The Remote Control

    PRODUCT DESCRIPTION 1.6.2 Inserting the Batteries in the Remote Control Caution: The remote control is powered by two 1.5V AAA batteries. The incorrect use of batteries can To install or replace batteries: result in leaks or bursting. Be sure to follow these instructions: Slide off the battery compartment cover.

  • Page 24: Operating Range Of The Remote Control

    PRODUCT DESCRIPTION 1.6.4 Operating Range of the Remote Control Point the top of the remote control toward the display’s remote control sensor (on the left or right side) when pressing a button. When using the remote control, the distance from the remote control to the sensor on the display should be less than 6m/19ft, and the horizontal and vertical angles should be less than 30˚.

  • Page 25: Motion Sensor

    PRODUCT DESCRIPTION 1.6.5 Motion Sensor To trigger the motion sensor, the distance between the person and the display sensor should be less than 1.6 meters/5 feet, and the horizontal and vertical angles should be less than 35˚. Note: To enable the motion sensor function, please follow these steps in the Settings > Display > Other ♦...

  • Page 26: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Note: ♦ To operate the interactive display, ensure to use the correct power cord that matches the power outlet in your region. Connect one end of the power cord to the AC IN connector on the interactive display. Connect the other end of the power cord to a power outlet or a power supply.

  • Page 27: Connecting A Computer Or Portable Device

    MAKING CONNECTIONS 2.2 Connecting a Computer or Portable Device 2.2.1 Using RS232 Input Connect one end of a RS232 serial cable to the RS232 connector of the interactive display and the other end of an RS232 serial cable to the RS232 connector of the computer. RS232 Computer RS232...

  • Page 28: Using The Touch Module

    MAKING CONNECTIONS 2.2.3 Using the Touch Module Interactive display has touch screen functionality which allows you to connect a computer to the display and control the computer’s interface via touch gestures on the display. To use this touch screen function, connect the USB cable to the TOUCH 1 or TOUCH 2 port of the display and a computer or USB cable to the USB 3.0 port of the display and a computer.
  • Page 29 MAKING CONNECTIONS TOUCH 2 FRONT TOUCH 2 HDMI Computer FRONT HDMI TOUCH 2 HDMI OUT USB Type-C Computer Type-C...
  • Page 30 MAKING CONNECTIONS FRONT Type-C Computer FRONT Type-C Note: ♦ The touch driver will be installed automatically for the following operating systems: - One-touch point for Windows 2000/XP/Vista/CE 6.0 and macOS. - Multi-touch point Windows 7/8/10/11, Android/Linux (kernel version 3.5+) and Chrome OS (39 or above). ♦...

  • Page 31: Using Displayport Input

    MAKING CONNECTIONS 2.2.4 Using DisplayPort Input Connect one end of the DisplayPort cable to the DP connector of the interactive display and the other end of the cable to the DP connector of the computer. Computer 2.3 Connecting External Equipment 2.3.1 Connecting a Video Player Connect one end of an HDMI cable to the HDMI 1, HDMI 2, or HDMI 3 connector of the interactive display and...

  • Page 32: Connecting A Microphone

    MAKING CONNECTIONS 2.3.2 Connecting a Microphone Connect the microphone to the MIC IN connector of the interactive display. MIC IN Microphone MIC IN...

  • Page 33: Connecting Audio Equipment

    MAKING CONNECTIONS 2.3.3 Connecting Audio Equipment Connect one end of an audio cable to the LINE OUT connector of the interactive display and the other end of an audio cable to the AUDIO IN connector of the audio device. For digital audio output, connect one end of an audio cable to the OPTICAL connector of the interactive display and the other end of an audio cable to the SPDIF IN connector of the audio device.

  • Page 34: Connecting A Display Device

    MAKING CONNECTIONS 2.4 Connecting a Display Device Connect one end of an HDMI cable to the HDMI OUT connector of the interactive display and the other end of an HDMI cable to the HDMI IN connector of the display device. HDMI OUT Display Device HDMI OUT...

  • Page 35: Connecting To A Wired Network

    MAKING CONNECTIONS 2.5 Connecting to a Wired Network Connect one end of a network cable (RJ45) to the LAN IN connector of the interactive display and the other end of a network cable to a network hub, switch, or router. LAN IN LAN IN Network Hub / Switch / Router...

  • Page 36: Connecting A Microsd Card

    MAKING CONNECTIONS 2.7 Connecting a MicroSD Card Connect a microSD card to the SD slot of the interactive display. microSD Card 2.8 Attaching Touch Pens Attach the touch pen to the magnetic areas of the interactive display’s front panel.

  • Page 37: Attaching An Ops

    MAKING CONNECTIONS 2.9 Attaching an OPS Insert the OPS to the OPS slot on the side of the interactive display. Note: ♦ Ensure that the OPS module size is 180 x 119 x 30 mm and the power rating is 18V; 5A. 180mm 119mm 30mm...

  • Page 38: Chapter 3: Using The Interactive Display

    CHAPTER 3: USING THE INTERACTIVE DISPLAY 3.1 Turning on the Power POWER button Plug the power cord to a power Note: outlet or power supply. ♦ The interactive display still Press the button to turn the consumes power as long as the LCD display on.

  • Page 39: Powering Off

    USING THE INTERACTIVE DISPLAY Please follow the instructions to turn on the Slide menu and switch to the Standard home page. 3.1.2 Powering Off Long press the button. Touch OK at the prompt to turn the interactive display off immediately or wait for 10 seconds until it turns off automatically.

  • Page 40: Muting The Sound

    USING THE INTERACTIVE DISPLAY Note: After pressing the Source button, the Source menu will be ♦ displayed on the screen. In the Source menu, you can also select the picture mode, color temperature, and aspect ratio. 3.3 Muting the Sound Note: ♦...

  • Page 41: Adjusting The Volume

    USING THE INTERACTIVE DISPLAY 3.4 Adjusting the Volume Note: ♦ After pressing the button, you will see the volume adjustment menu. to enable or disable sound when a notification arrives, tap and slide it up buttons or down to manually adjust the volume, tap to configure more sound settings, or tap...

  • Page 42: Android Functions

    USING THE INTERACTIVE DISPLAY 3.5 Android Functions 3.5.1 Accessing the Home Screen Home button Press the button to access the Home screen of the system. For more information on the Home screen, refer to the “About the Home Screen” section. 3.5.2 Accessing the Slide Menu Slide menu button Press the...

  • Page 43: Returning To The Previous Screen

    USING THE INTERACTIVE DISPLAY 3.5.3 Returning to the Previous Screen Back button Press the button to return to the previous screen or close the menu or app. 3.5.4 Accessing the File Manager File Manager button button to launch File Manager. For more information on the File Manager, refer to the Press the “File Manager”...

  • Page 44: Accessing The Settings Menu

    USING THE INTERACTIVE DISPLAY 3.5.5 Accessing the Settings Menu Setting menu button Press the button to open the Settings menu. For more information on the Settings menu, refer to the “Configuring System Settings” section. 3.5.6 Accessing the Whiteboard Whiteboard button Press the button to open Whiteboard.

  • Page 45: Adding A Bluetooth Device

    USING THE INTERACTIVE DISPLAY 3.5.7 Adding a Bluetooth Device Adding a Bluetooth device button Press the button to add a Bluetooth device. Tap on the device you want to add. Verify the codes in both devices and if they match, tap Pair. Interactive Display Smartphone...

  • Page 46: Using The Touchscreen

    USING THE INTERACTIVE DISPLAY 3.6 Using the Touchscreen In addition to the remote control, you can also operate your interactive display using the touch gestures as described in the tables below. For Android Action Touch Gesture Function Touch Touch to open clickable items on the screen, such as apps, Slide menu options, and more.
  • Page 47 USING THE INTERACTIVE DISPLAY For Windows Note: ♦ Make sure you have connected properly the Windows-based device to the interactive display. ♦ Multi-touch functions are only supported on Windows 11, Windows 10, Windows 8, Windows 7 Home Premium /Professional / Enterprise / Ultimate operating systems and not supported on Windows XP, Windows Vista, and Windows 7 Starter / Home Basic.
  • Page 48 USING THE INTERACTIVE DISPLAY Function Touch Gesture Action Pan up / Touch the screen and quickly drag your Pan down finger to the desired direction. / Back / Forward Note: ♦ For Windows 8 Learn Touch and hold the screen to display more information.
  • Page 49 USING THE INTERACTIVE DISPLAY Function Touch Gesture Action Wake the Touch and hold the screen for around 4 computer seconds. up from the standby mode (S3) Multi-touch gestures: Note: ♦ For Windows 7 Home Premium / Professional / Enterprise / Ultimate version Right-tap Touch and hold on the target and quickly touch the screen once with another...

  • Page 50: Using The On-Screen Keyboard

    USING THE INTERACTIVE DISPLAY 3.7 Using the On-Screen Keyboard Whenever you need to input text, an on-screen keyboard opens automatically. Touch the keys on the screen as you would press the keys on a connected keyboard. To customize the keyboard layout, tap , to enable or disable clipboard, tap , to extend the keyboard, tap...

  • Page 51: Chapter 4: Using The System

    CHAPTER 4: USING THE SYSTEM 4.1 About the Home Screen After you power on the system, you will see the Home screen. On the Home screen, you can view the current date and time, access the Slide menu and various apps. Item Description 1 Slide menu...

  • Page 52: Using The Slide Menu

    USING THE SYSTEM 4.2 Using the Slide Menu The Slide menu can be accessed on either sides of the interactive display by touching / or by pressing on the remote control. For more convenient access, you can touch and hold on the Slide menu icon to slide it up or down.
  • Page 53 USING THE SYSTEM Touch Float Ball to display the Float Ball menu on the screen. • To open the Float Ball menu, touch Touch to return to the Home screen, to return to the previous menu or close app, to enter the writing mode and annotate the screen, to capture the screen, or to minimize the Float Ball menu.
  • Page 54 USING THE SYSTEM • Recent Tasks menu displays the latest four apps that you have opened on the interactive display and are currently running in the background. To access the app, simply touch the app icon. To view and manage all apps that are currently opened, touch .

  • Page 55: Configuring System Settings

    USING THE SYSTEM 4.3 Configuring System Settings In Settings menu, you can configure various system settings. To access the Settings menu, do the following: On the Home screen, swipe the screen to the left/touch > or press on the remote control. The Settings menu opens.
  • Page 56 USING THE SYSTEM Connected devices: - Other devices > USB: Configures USB connection preferences. - Other devices > Pair new device: Connects to other Bluetooth devices. Advanced Features: - Automatic sleep: Enables or disables automatic sleep. When there is no source signal, there is no operation within the specified time.
  • Page 57 USING THE SYSTEM Note: If you have set the google home page as the Home screen mode, then swipe down from the ♦ upper edge of the screen to view notifications, adjust brightness, access quick settings, and more. If you have set the google home page as the Home screen mode, then swipe up from the ♦...
  • Page 58 USING THE SYSTEM - Erase all data (factory reset): Erases all data from your interactive display’s internal storage, including your Google account, system and app data and settings, downloaded apps, music, photos, and other settings to the factory defaults. - Password Setting: If password is created in Security Management, you can change the password setting here.
  • Page 59 USING THE SYSTEM - Privacy > Device & app notifications: Controls which apps and devices can read notifications. - Privacy > Notifications on lock screen: Configures what type of notifications are displayed on the lock screen. - General > Do Not Disturb: Enables or disables Do Not Disturb function. If enabled, then notifications are displayed only from selected people and apps.
  • Page 60 USING THE SYSTEM - Appearance > Dark theme: Enables or disables dark theme. - Display size and text: Configures the display and font sizes. - Colors > Colors: Sets the color theme. - Other display controls: Sets the screen saver, enables or disables motion sensor and temperature display.
  • Page 61 USING THE SYSTEM - General > Accessibility shortcuts: Configures the accessibility shortcuts. - General > Text-to-speech output: Configures the text-to-speech output settings. Security: - Security status: Displays Google Play Protect app scan time and status, enables or disables Find My Device feature, displays the latest security update and Google Play system update date and available updates.
  • Page 62 USING THE SYSTEM Passwords & accounts: - Passwords: Manages passwords. - Autofill service: Configures autofill options. - Accounts: Adds and manages accounts. - Automatically sync app data: Enables or disables synchronizing app data automatically. Digital Wellbeing & parental control: Configures screen time, app timers, bedtime schedules, and more.

  • Page 63: Chapter 5: Using The Apps

    CHAPTER 5: USING THE APPS 5.1 Accessing Apps Some apps, such as Whiteboard, Montage, and File Manager are accessible directly from the Home screen. Other apps that are installed on the interactive panel, can be accessed through the Apps screen. To access the Apps screen, do the following: On the Home screen, swipe the screen to the left or touch The Apps screen opens.
  • Page 64 USING THE APPS Write or draw directly on the whiteboard with the default settings for pen tip type (bottom & top tip), thickness, font color, and background color or touch any of the following icons to modify the default settings: Note: ♦...
  • Page 65 USING THE APPS and binding of data. The number of rows and columns are not fixed, you can edit them later. Mind: Add a diagram. Current page note: Add a note. Web browser: Add a fully functional web browser. Timer: Add a timer. RecordScreen: Start recording the screen.
  • Page 66 USING THE APPS Menu > Share by QR Touch to share the session to other people who are connected to the same LAN or WAN with the interactive display. For enhanced security, enable the encrypt option (if necessary). Menu > Email Touch to send the session by email.

  • Page 67: Montage

    USING THE APPS 5.3 Montage Montage app enables to mirror the display’s screen on your portable device for hands-on annotation, mirror the screen of your device on the display, or use your device as a remote control for the display. Montage is accessible by downloading the DisplayNote app to your portable device or using the DisplayNote web app over a Chromium web browser.
  • Page 68 USING THE APPS Home: Return to the launcher screen from any other screen. Settings: Edit the room name, select the interface language, and view the device info. Launch DisplayNote on your portable device or open the web browser and enter “displaynote.com/ join”...
  • Page 69 USING THE APPS - View presentation: View the presentation on the main display, annotate the presentation screen, and capture a screenshot. - Present: Share your portable device’s screen or present a video from the gallery. - Shared items: View and share items. Touch +Add to upload items for sharing or touch on the item to open it.

  • Page 70: File Manager

    USING THE APPS 5.4 File Manager File Manager enables you to manage files that are saved to the internal memory and to the connected external storages. To access and manage your files, do the following: to open File Manager. On the Home screen, touch Do any of the following based on your needs: - In the Storage section, touch the storage device where you want to manage files.

  • Page 71: Annotation

    USING THE APPS 5.5 Annotation Choose from a range of various tools with which to annotate the screen. To open Annotation, touch Slide menu / > Annotation, or lift the pen from the device on any screen except for the Home screen. Write or draw on the screen directly with your finger or with the touch pen.

  • Page 72: Screenshot

    USING THE APPS • Saves, shares, or sends the screen image by email. You can also temporary stop or exit the writing mode. 5.6 ScreenShot Captures the screen image. To open ScreenShot, touch Slide menu / > ScreenShot. Select an area on the screen or the full screen. •...

  • Page 73: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics card. is set too high. The interactive display cannot •...
  • Page 74 APPENDIX Audio Format Audio Codec AAC LC(Advanced Audio Coding Low Complexity) AMR NB(Narrow band) AMR WB(Wide band) MIDI MP2(MPEG Audio layer2) MP3(MPEG Audio layer3) FLAC PCM S8VX PCM S16 LE PCM S16 BE PCM S24 LE PCM S32 LE LPCM(PCM A-Law G.711) LPCM(PCM μ-Law G.711) IMA ADPCM MS ADPCM...

  • Page 75: Supported Resolution

    APPENDIX 6.3 Supported Resolution TypeC Pixel Freq HDMI2/3 Timing fh (kHZ) fv (hz) HDMI1 (Mhz) FR HDMI FR TypeC VESA 640 x 480 31.469 59.94 25.175 SVGA 800 x 600 37.879 60.317 1024 x 768 48.363 QXGA 1280 x 960 1920 x 1080 37.5 148.5...

  • Page 76: Troubleshooting

    APPENDIX 6.4 Troubleshooting Symptom Possible Cause Remedy No picture is displayed • The power cord has been 1 Plug in the power cord. disconnected. 2 Make sure the power switch is • The main power switch on the switched on. bottom of the display is not 3 Connect a signal connection to switched on.

  • Page 77: Transporting The Interactive Display

    APPENDIX Symptom Possible Cause Remedy The response of the system is • Too many apps are running in Disconnect your interactive display slow or the system crashes the background. from the power outlet and wait for 1-2 minutes. Then reconnect the power •...

  • Page 78: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications IFP6504E-AE Panel Panel Type LED-Backlit TFT LCD (VA Technology) Panel Size 64.5” Max. Resolution UHD 3840 x 2160 Pixel Pitch 0.372 mm Brightness 400 cd/m Contrast Ratio 4000:1 Viewing Angle (H/V) 178°/178° Display Colour 1.07G...

  • Page 79: Display Dimensions

    All specifications are subject to change without prior notice. 7.2 Display Dimensions 52.7 15.4 15.4 24.2 492.5 WALL MOUNTING SCREW:4-M8X20 1430.5(ACTIVE AREA) 1485(OUTLINE) 88.1 AG Neovo Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2024 AG Neovo. All rights reserved. I654A0_UM_V010...
