S&C Series 2000 Circuit-Switchers
Outdoor Transmission (68 kV through 230 kV)

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
August 5, 2024
© S&C Electric Company 1987-2024 , all rights reserved
Installation and Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Model 2040 - With Horizontal
Interrupters and Without Disconnect
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
2
2
2
3
3
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
4
4
5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
8
8
8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
Instruction Sheet 716-502
10
10
11
14
16
18
19
20
20
20
26
26
26
27
28
28
29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for S&C 2000 Series

Summary of Contents for S&C 2000 Series

  • Page 1: Table Of Contents

    S&C Series 2000 Circuit-Switchers Model 2040 — With Horizontal Outdoor Transmission (68 kV through 230 kV) Interrupters and Without Disconnect Installation and Operation Table of Contents Introduction Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

  • Page 2: Introduction

    Introduction Qualified Persons WARNING The equipment covered by this publication must be installed, operated, and maintained by qualified persons knowledgeable in the installation, operation, and maintenance of substation and overhead electric power transmission and distribution equipment along with the associated hazards . A qualified person is someone trained and competent in: ●...

  • Page 3: Usual Operating Conditions

    Introduction Usual Operating Series 2000 Circuit‑Switchers will perform as intended at temperatures within the range of −40°C (−40°F) to +40°C (104°F); −35°C (−31°F) to +40°C (104°F) for 161‑kV and 230‑kV Conditions models, at altitudes of up to 5000 feet (1524m), and at wind loadings of up to 90 miles per hour (145 kmph).

  • Page 4: Safety Information

    Safety Information Safety Information Understanding Several types of safety‑alert messages may appear throughout this instruction sheet as well as on labels and tags attached to the S&C Series 2000 Circuit‑Switcher, Model 2040. Safety-Alert Become familiar with these types of messages and the importance of these signal words: Messages DANGER “DANGER”...

  • Page 5: Location Of Safety Labels

    Safety Information Location of Safety Labels S&C Instruction Sheet 716-502...
  • Page 6 Safety Information Reorder Information for Safety Labels Location Safety Alert Message Description Part Number WARNING Do not remove steel outer wrapper . . . G-5993 ● WARNING Do not remove steel over wrapper until installation is complete . . . G-5699 ■...

  • Page 7: Safety Precautions

    Safety Precautions DANGER Series 2000 Circuit-Switchers operate at high voltage . Failure to observe the precautions below will result in serious personal injury or death . Some of these precautions may differ from your company’s operating procedures and rules . Where a discrepancy exists, follow your company’s operating procedures and rules .

  • Page 8: Shipping And Handling

    Shipping and Handling Inspection Examine the shipment for damage as soon after receipt as possible, preferably before removal from the carrier’s conveyance. Check the bill of lading to make sure all listed shipping skids, crates, and containers are present. If there is visible loss and/or damage: Notify the delivering carrier immediately.
  • Page 9 Shipping and Handling The shipment contains: ● Three pole‑units each consisting of an interrupter, an insulating support column, a support insulator, and a base, all factory‑assembled and adjusted ● A single high‑speed base enclosing the high‑speed power train that drives the interrupters ●...

  • Page 10: Installation

    Installation Installation Before Starting WARNING Do not remove the containers from the interrupters or the plastic bubble-wrap from the insulating support columns until the installation is complete . Equipment damage or personal injury may result . NOTICE Bolted and Pinned Connections: A typical bolted connection requires a flat washer underneath the cap screw and one under the nut .

  • Page 11: Installing The Mounting Pedestals And High-Speed Base

    Installation Installing the Mounting Pedestals and High-Speed Base Complete the following steps to install a Model 2040 Series 2000 Circuit‑Switcher: Cut the steel straps binding the mounting STEP 1 . pedestals to the high‑speed base. Cut the straps binding the container of operating mechanism components and hardware and the straps binding the pole‑units.
  • Page 12 Installation Install each pedestal as follows: STEP 2 . (a) Install the lower set of anchor‑bolt nuts Anchor bolts Pedestal and flat washers onto the pre‑installed anchor bolts. Level all anchor bolts at Concrete pad the same height, leaving space below and Two nuts and two flat above for leveling.
  • Page 13 Installation Attach four suitable lifting slings to the high‑ STEP 4 . speed base. See Figure 5. Unbolt the high‑speed base from the shipping skid and lift the base Eye bolts on top of the support arms, as shown on the catalog drawing. Verify the SWITCH POSITION indicator on the base is visible on the desired side.

  • Page 14: Installing The Switch Operator

    Installation Installing the Switch Operator Bottom plate Complete the following steps to install the switch operator: Loosen the 1/2–13 × 11/4‑inch galvanized steel STEP 1 . cap screws, flat washers, and nuts attaching the bottom plates to the underside of the high‑ speed base.
  • Page 15 Installation Lift and install the operator as follows: STEP 3 . NOTICE Do not to damage the uni-ball coupling on the operator connecting link during Uni-ball hoisting and attachment of the operator . coupling Holes for The uni-ball coupling cannot be replaced ½...

  • Page 16: Installing The Pole-Units

    Installation Installing the Pole-Units NOTICE The pole-units are numbered “Pole 1,” “Pole 2,” and “Pole 3 . ” Make sure to install the pole-units in the order marked on the catalog drawing . The pole numbers do not have to correspond with the system’s phase designations .
  • Page 17 Installation shipping bracket protects the insulated operating rod. Discard the shipping bracket and associated hardware. See Figure 10 on page 16. CAUTION The insulated operating rod is under pressure . Removal of the shipping bracket may result in the operating rod quickly moving down approximately 3/8-inch (9 .5 mm) .

  • Page 18: Connecting The Pole-Units To The High-Speed Power Train

    Installation Connecting the Pole-Units to the High-Speed Power Train —18 x ¾ Transition hex-head stainless Complete the following steps to connect the pole‑units to lever steel cap screws the high‑speed power train: for access cover (removed) Prepare the insulated operating rod of each STEP 1 .

  • Page 19: Connecting The Operator To The High-Speed Power Train

    Installation (d) Attach the insulated operating rod end links to the interphase drive linkage lever Insulated operating rod end links in the high‑speed base using the ½‑inch silicon‑bronze pin and cotter pin retained from Step 1(d) on page 17. See Figure 13. The insulated operating rod may be moved up or down, as required, to make the connection.

  • Page 20: Connecting Conductors

    Installation Connecting Conductors (c) Pry the container halves apart with a flat‑head screwdriver or other sturdy pry DANGER tool. The upper container half can now be removed and discarded. Slotted holes are Conductors must be de-energized and grounded in provided so a rope or lifting sling can be accordance with standard system operating practice .
  • Page 21 Installation (b) Mark the conduit‑entrance location for the control‑circuit wiring on the conduit‑en‑ trance plate in the bottom of the operator Shield enclosure. See Figure 16. Remove the plate and cut out the necessary opening. (c) Apply sealant and replace the plate. Make up and connect the entrance fittings.
  • Page 22 Installation (d) Connect the external control‑circuit wiring (including the space‑heater source leads) to the terminal blocks at the bottom of the enclosure. Refer to the wiring diagram. Observe correct polarity on the dc‑control‑voltage models. Trip‑circuit conductors and motor‑closing circuit conductors must be adequately sized for the ampacities indicated on the wiring diagram.
  • Page 23 Installation At each interrupter, make sure: STEP 3 . NOTICE ● Both shipping‑container halves and all associated packing and hardware have Check the following . Failure to do so been removed can result in damage to the circuit- ● switcher when operated . The pressure relief shield has been removed from the target‑end of the inter‑...
  • Page 24 Installation In the switch operator, make sure: STEP 5 . ● Correct polarity has been observed on Insulated dc‑control‑voltage models (See Figure 22) operating rod ● The motor contactor and surge suppressor are fully seated in their mounts (See Figure 23 on page 25) ●...
  • Page 25 Installation The closing latch will release, discharging the closing spring. This action closes the inter‑ rupters. The SWITCH POSITION indicator on the high‑speed base will move to the Closed position. See Figure 25 on page 26. If the POSITION INDICATING lamp option has been specified, the red lamp will light.

  • Page 26: Operation

    Operation Understanding Trip-Free Operation The stored‑energy mechanism has an instantaneous trip‑free capability. If the Series 2000 Circuit‑Switcher is closed into a fault sensed by the user‑furnished relaying, the mechanism will immediately trip. To accomplish trip‑free operation, the stored‑energy mechanism uses two spring assemblies: one for closing and one for opening.

  • Page 27: Manual Operation

    Operation The circuit‑switcher may also be electrically operated via remotely located control switches. No instructions are included for remote control because control schemes vary with the installation and specific application of the switch. Manual Operation To trip the interrupters, push the manual TRIP lever counterclockwise as indicated by the TRIP lever label.

  • Page 28: Understanding The Gas Pressure Indicator And Safety Relief Device

    Operation Understanding the GAS PRESSURE Indicator and Safety Relief Device GAS PRESSURE Safety relief indicator device Series 2000 Circuit‑Switchers have sealed interrupters containing gas under pressure. Loss of gas pressure may result in improper interrupting action. Low gas pressure is signaled by a red target in the GAS PRESSURE indi‑ cator at the upper terminal end of the interrupter.

  • Page 29: Inspection Recommendations

    Operation Inspection Recommendations To ensure the Series 2000 Circuit‑Switcher’s continued proper performance, the circuit‑switcher should be inspected in accordance with S&C‑recommended schedule and procedures contained in S&C Instruction Sheet 716‑590. S&C Instruction Sheet 716-502...
