- Page 1 ENGLISH MAXIMUS MLX Flameproof illuminator English - Instruction manual Italiano - Manuale di istruzioni Русский - Руководство по эксплуатации Français - Manuel d’instructions Português - Manual de instruções 한국어 - 지침 설명서 Deutsch - Bedienungsanleitung...
- Page 3 ENGLISH MAXIMUS MLX Flameproof illuminator English - Instruction manual...
-
Page 5: Table Of Contents
Contents E N G L I S H 1 About this manual ........................5 1.1 Typographical conventions ..............................5 2 Notes on copyright and information on trademarks ............5 3 Safety rules ..........................5 4 Product description and type designation ................8 4.1 Product overview ................................... - Page 6 8.2 Extraordinary maintenance .............................22 8.2.1 Fuse replacement ....................................22 8.2.2 Replacing the gasket ...................................23 9 Cleaning ..........................23 9.1 Cleaning the glass window ...............................23 9.2 Cleaning the product................................23 10 Information on disposal and recycling ................23 11 Troubleshooting ........................24 12 Technical data ........................24 12.1 General ....................................24 12.2 Mechanical ...................................24 12.3 Electrical ....................................24...
-
Page 7: About This Manual
1 About this manual 2 Notes on copyright and information on trademarks Read all the documentation supplied carefully before installing and using this product. Keep the The mentioned names of products or companies are manual in a convenient place for future reference. trademarks or registered trademarks. - Page 8 • Make sure that all the equipment are certified for DANGER! the application and for the environment in which Emission of visible light or infrared. they will be installed. Can be harmful for eyes. Pay attention to • Any change that is not expressly approved by the the provided indications.
- Page 9 The manufacturer, however, cannot take any liability • Only use original VIDEOTEC spare parts. Strictly for its use. The same thing can be said for any adhere to the maintenance instructions attached person or company involved in the creation and to each replacement kit.
-
Page 10: Product Description And Type Designation
4.1 Product overview • For all maintenance interventions, we recommend you return the product to the laboratory that will The main parts of the product are illustrated below. perform all required operations. 01. Fastening support. • To comply with the main supply voltage dips and short interruption requirements, use a suitable 02. -
Page 11: Range Of Use
4.2 Range of use 4.4 Gas Group, Dust Group and Temperatures Use of the unit is defined in a fixed station to light zones with a potentially explosive atmosphere The device is certified for group IIB (Gas) and group classified 1-21 or 2-22. IIIC (Dust). -
Page 12: Product Marking Label
4.6 Product marking label Fig. 2 The number of the accredited body that ATEX marking. The Class temperature depends provides the quality assessment. on the electronics installed inside and the ambient temperature. Manufacturer’s name and address. IECEx marking. The Class temperature depends Model. -
Page 13: For Ul/Csa Standard Reference Only
4.7 For UL/CSA standard reference only. The flameproof joints are not intended to be repaired. In the USA, the National Electrical Code (NEC) and in Canada the Canadian Electrical Code (CEC) apply to electrical equipment used on hazardous industrial premises. These Codes contain the installation regulations for electrical facilities in all areas and refer to a number of further standards of other institutions with specifications for the construction and installation of suitable equipment. -
Page 14: Connections
Connections The choice of connection must comply with local legislation in force. Cable glands: select a cable gland in compliance with UL2225 with the following protection AEx d IIC and C22.2 with the following protection Ex d IIC in compliance with the marking of the product. Conduit: it is necessary to install a sealing device within 50mm of the product input when the conduit is used. -
Page 15: Model Identification
24Vdc/ 850nm 70° Without cable, without 24Vac, PoE+ cable gland white light Tab. 2 MAXIMUS MLX - CERTIFICATIONS AND MARKINGS Certification Marking Ambient temperature Cable input tempe- rature ATEX II 2 G Ex db IIB T6...T5 Gb -40°C ≤ Ta ≤ +55°C or +82.3°C with Ta ≤... -
Page 16: Preparing The Product For Use
5 Preparing the product for 6 Installation Before carrying out any type of intervention, read the "Safety rules" Before carrying out any type of chapter of this manual. intervention, read the "Safety rules" We strongly recommend using only approved chapter of this manual. brackets and accessories during installation. -
Page 17: Parapet Mounting
Fig. 6 Example of ceiling installation. Fig. 8 Railing fastening with cable input upwards. Fig. 7 Example of wall or ceiling installation. 6.1.1 Parapet mounting The product can be installed on a railing. Fasten the fastening support (01) to its final installation surface. -
Page 18: Wall Or Ceiling Fastening
6.1.2 Wall or ceiling fastening The product can be installed on a railing or ceiling. Fasten the fastening support (01) to its final installation surface. Attach the housing support (03) to the fastening support (01) using the M8 screw (05), washers and nut. -
Page 19: Product Opening
6.2 Product opening 6.3 Slide removal Unscrew the 3 M4 screws to remove the slide. Before carrying out any type of Before removing the slide, check that cables are not intervention, read the "Safety rules" fastened with a clip. chapter of this manual. Unscrew the fastening screws and remove the front cover from the housing body. -
Page 20: Connector Board Description
6.4 Connector board description 6.5 Connecting the power supply 6.5.1 Connecting the power supply BOARD DESCRIPTION (24Vac/24Vdc) Connec- Function Terminals - Nominal tor/ section of the cables Terminal used Check that the power supply socket and cable are adequately dimensioned. Power supply line (24Va from 1.0mm²... -
Page 21: Connecting The Power Supply (Poe+)
6.6 Earthing equipotential 6.5.2 Connecting the power supply (PoE+) connection The Ethernet cable shield must always be The equipotential connection must be carried out earthed via the connector. Always use a using an external cable with a minimum 4mm² shielded RJ45 connector. section (11AWG). -
Page 22: Led Groups Enabling And Fault Connection
6.7 LED groups enabling and • Enabling group B only: install the connections as in the diagram below. Fault connection LED GROUPS ENABLING AND FAULT CONNECTION Connectors Terminals Description 1 (RL1A), 2 (RL1B) Clean output contact enabled by Fault 3 (A), 4 (B), 5 (COM) LED groups enabling Tab. -
Page 23: Fault
6.7.2 Fault Re-insert the slide and fasten the 3 previously removed screws. The Fault can occur in high temperatures or in the Verify that there is no dirt or debris. event of a LED fault. In the event of a malfunction, the illuminator closes the normally open clean Arrange the cables so that they do not hinder closing contact between RL1A and RL1B on terminals 1... -
Page 24: Switching On
"Safety rules" same characteristics. chapter of this manual. 8.1 Routine maintenance When contacting VIDEOTEC for assistance please provide the serial number and the identification code of the model. 8.1.1 Inspecting the cables The cables should not show signs of damage or wear, which could generate hazardous situations. -
Page 25: Replacing The Gasket
9.2 Cleaning the product 8.2.2 Replacing the gasket Replace the O-ring gasket of the product with the The outside surface of the product must one supplied. never be covered in more than 5 mm of Open and close the cover as described in the dust. -
Page 26: Troubleshooting
• LED: 11 correct. Check continuity of the • Viewing distance: up to 125m (410ft) with fuse and, if faulty, replace it with VIDEOTEC cameras with DELUX technology the indicated model. Illuminator with white light LED • Light color temperature: 6500K... -
Page 27: Environment
12.5 Environment 12.7 Certifications - Explosion- proof applications For indoors and outdoors installation Operating temperature: from -40°C (-40°F) up to ATEX (EN IEC 60079-0, EN 60079-1, EN 60079-31) +65°C (149°F) IECEx (IEC 60079-0, IEC 60079-1, IEC 60079-31) Certification temperature: from -40°C (-40°F) up to EAC EX (TR CU 012/2011) +70°C (158°F) INMETRO (ABNT NBR IEC 60079-0, ABNT NBR IEC... -
Page 28: Technical Drawings
The indicated measurements are expressed in millimetres. WALL OR CEILING FASTENING PARAPET MOUNTING Fig. 28 MAXIMUS MLX. Headquarters Italy VIDEOTEC s.r.l. Via Friuli, 6 - I-36015 Schio (VI) - Italy Tel. +39 0445 697411 - Fax +39 0445 697414 Email: info@videotec.com www.videotec.com... - Page 29 Headquarters Italy VIDEOTEC s.r.l. ÌMNVCMLX_Ç66xÎ Via Friuli, 6 - I-36015 Schio (VI) - Italy Tel. +39 0445 697411 - Fax +39 0445 697414 Email: info@videotec.com www.videotec.com MNVCMLX_2222...
