Adlin Rectangle Dining Table
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Stock # BH1425004710006
# BH1425004710014
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2024-03-14
1-866-942-5362
www.whalenstyle.com
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Better Homes and Gardens Adlin BH1425004710006
Summary of Contents for Better Homes and Gardens Adlin BH1425004710006
- Page 1 LOT NUMBER: DATE PURCHASED: Adlin Rectangle Dining Table Stock # BH1425004710006 # BH1425004710014 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S 1. Maximum load weight on table is 400 pounds (181.4 kg). WARNING THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM WEIGHTS INDICATED. - Page 3 Parts and Hardware List Please read through the instructions completely and verify that all listed parts and hardware are present before beginning assembly. A - Table Top B - Side Frame (Qty. 1) (Qty. 2) C - Middle Stretcher D - Support Rail (Qty.
- Page 4 Assembly Instructions The wood dowel holes face inward. ① x 2 ③ x 2 ④ x 2 DO NOT fully tighten the bolts until all the bolts are ready to assemble. To avoid causing damage to the threads, DO NOT over-tighten the bolts. 1.
- Page 5 Assembly Instructions ② x 2 4. Align and attach the Middle Stretcher (C) to the Side Frame (B) with the end dowels fully inserted. 5. Insert one 65 mm Bolt (2) through the mounting hole on the bottom rail of the Side Frame (B) and securely screw into the Middle Stretcher (C).
- Page 6 Assembly Instructions ① x 2 ③ x 2 ④ x 2 7. Insert two 45 mm Bolts (1) with the Washers (3 and 4) through the mounting holes of the Side Frame (B) and securely screw into the Table Top (A).
- Page 7 Assembly Instructions ③ x 3 ④ x 3 ② x 3 8. Align and fit the Support Rail (D) between the Side Frames (B) and fasten it to the Table Top (A) with three 65 mm Bolts (2), three Lock Washers (3) and three Flat Washers (4). 9.
- Page 8 Assembly Instructions Floor Leveler DO NOT lean the DO NOT hold the Hold by the table top table by the legs table by the legs Table top Turn over table like this 10. Ask for assistance to lift the assembled unit upright and position it on your desired location. 11.
-
Page 9: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. ... - Page 11 NÚMERO de LOTE:__________ FECHA de COMPRA: Mesa rectangular Adlin Serie # BH1425004710006 # BH1425004710014 ENSAMBLE REQUERIDO POR ADULTO Si tienen alguna pregunta acerca del ensamble o si alguna parte está faltante, no retorne esté producto a la tienda donde lo compro. Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el número de fábrica: 1-866-942-5362 Hora estándar del Pacífico: 8:30 a.m.
- Page 12 M Á X I M O P E S O R E C O M E N D A D O 1. La carga máxima en la mesa es de 400 libras (181.4 kg). ADVERTENCIA ESTA UNIDAD DEBE UTILIZARSE CON LOS PESOS MÁXIMOS INDICADOS.
- Page 13 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes y partes de ferretería antes de iniciar el ensamblado. A – Tapa de la mesa B – Marco lateral (Cant. 1) (Cant.
- Page 14 Instructivo de ensamble Los agujeros de las clavijas de madera apuntan hacia adentro ① x 2 ③ x 2 ④ x 2 ADVERTENCIA NO apretar completamente los pernos inicialmente hasta que los pernos estén listos para ensamblar. Para evitar daños a la rosca, NO sobre apretar los pernos. 1.
- Page 15 Instructivo de ensamble ② x 2 4. Alinear y adjuntar el soporte medio (C) al marco lateral (B) con las clavijas extremas insertadas completamente. 5. Insertar un perno de 65 mm (2) a través del agujero de montaje en el riel inferior del marco lateral (B) y atornillar en el soporte medio (C).
- Page 16 Instructivo de ensamble ① x 2 ③ x 2 ④ x 2 7. Insertar 2 pernos de 45 mm (1) con las arandelas (3 y 4) a través de los agujeros de montaje en el marco lateral (B) y atornillar en la tapa de la mesa (A).
- Page 17 Instructivo de ensamble ③ x 3 ④ x 3 ② x 3 8. Alinear y meter el riel soporte (D) entre los marcos laterales (B) y sujetar a la tapa de la mesa (A) con 3 pernos de 65 mm (2), 3 arandelas de presión (3) y 3 arandelas planas (4). 9.
- Page 18 Instructivo de ensamble Nivelador de piso Mantener por la tapa NO incliner por las patas NO mantener por las patas de la mesa Tapa Voltear de esta forma 10. Pedir asistencia para poner la unidad ensamblada en posición vertical y cerca de su lugar deseado. 11.
-
Page 19: Cuidado Y Mantenimiento
Cuidado y mantenimiento Use una toalla suave y limpia para evitar daños y rayaduras. Uso de cera para pulir muebles no es necesario. Si desea usar cera, pruébela en un área que no sea visible para revisar su funcionamiento. ...
