Wyatt Geo End Table
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Stock # BH1425004710002
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2024-01-26
1-866-942-5362
www.whalenstyle.com
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Better Homes and Gardens Wyatt Geo BH1425004710002
Summary of Contents for Better Homes and Gardens Wyatt Geo BH1425004710002
- Page 1 LOT NUMBER: DATE PURCHASED: Wyatt Geo End Table Stock # BH1425004710002 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
-
Page 2: Special Note
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Wyatt Geo End Table STOCK # BH1425004710002 MAXIMUM LOAD 22.7 kg / 50 lb MAXIMUM LOAD 9.1 kg / 20 lb MAXIMUM LOAD 22.7 kg / 50 lb... - Page 3 Parts and Hardware List Please read through the instructions completely and verify that all listed parts and hardware are present before beginning assembly. A - Table Top B - Bottom Panel (Qty. 1) (Qty. 1) C - Support Leg (1) 1/4” x 15 mm Bolt (Qty.
- Page 4 Assembly Instructions ② x 2 ③ x 2 ④ x 2 DO NOT fully tighten the bolts or screws until all the bolts or screws are ready to assemble. To avoid causing damage to the threads, DO NOT over-tighten the bolts or screws. 1.
- Page 5 Assembly Instructions ① x 2 ③ x 2 ④ x 2 3. Align and attach the Bottom Panel (B) to the Support Leg (C) by inserting two 15 mm Bolts (1) with Lock Washers (3) and Flat Washers (4) through the metal tabs of the Support Leg (C) and securely screw into place.
- Page 6 Assembly Instructions ② x 2 ④ x 2 ③ x 2 4. Align and attach the Support Leg (C) to the Table Top (A) by inserting two 27 mm Bolts (2) with the Lock Washers (3) and Flat Washers (4) through the mounting holes on the Table Top (A) and securely screw into place.
- Page 7 Assembly Instructions ① x 2 ③ x 2 ④ x 2 5. Insert two 15 mm Bolts (1) with the Washers (3 and 4) through the metal tabs of the Support Leg (C) and securely screw into place. Now, fully tighten all bolts with the hex wrench provided.
- Page 8 Assembly Instructions Floor Leveler 6. Stand the assembled unit upright on a flat surface. 7. If necessary, adjust the pre-attached floor levelers at the bottom of the Support Legs (C) to level the unit.
-
Page 9: Drawer Removal
Assembly Instructions DRAWER REMOVAL Release LEVER Ball bearing cart FRONT FRONT Ball bearing cart DRAWER INSTALLATION 8. If you need to remove the drawer, please pull the drawer all the way out, then simultaneously push the plastic release lever of the ball bearing slide up on one side and down on the other side, and then pull the drawer out completely. -
Page 10: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. ...
