- Page 1 EF100 Series TECHNICAL MANUAL STEIEL Elettronica S.r.l. – Viale Europa, 24 – 35020 Ponte San Nicolò – PADOVA - ITALY Tel. +39 049.8961488 – Fax +39 049.8960184 – www.steiel.it – info@steiel.it Certified Company, according to UNI EN ISO 9001 standards...
- Page 2 The manufacturer can modify the instrument or the technical manual without advanced notice. Warranty All STEIEL products are warranted for a period of 12 months from the delivery date. Warranty is not valid if all instructions of installation, maintenance and use, are not strictly followed by the user.
-
Page 3: Table Of Contents
TABLE OF CONTENTS PACKING LIST ......................... page 4 GENERAL SAFETY TIPS ......................... 4 INTRODUCTION AND OPERATING PRINCIPLE ................5 INSTALLATION ..........................5 TECHNICAL DATA ........................... 6 HYDRAULIC CONNECTIONS ......................7 ELECTRICAL CONNECTIONS ......................8 MAINTENANCE AND STORAGE ..................... 9 MECHANICAL DIMENSIONS ......................10 EXPLODED VIEW OF THE PUMP .................... -
Page 4: Packing List
PACKING LIST The EF100 series pumps are supplied complete with technical manual. An optional kit is available (code 9600.0100), including: • Suction tube, PVC Crystal (2 m) • Injection tube, PE (2 m) • Foot filter • Injection valve with ½” connection... -
Page 5: Introduction And Operating Principle
INTRODUCTION AND OPERATING PRINCIPLE The EF100 are a series of peristaltic pumps with fixed flow rate, of small size and easy installation and maintenance, designed with open case for panel-mounting. These pumps are suitable for many applications, such as the chemical industry, food processing, disinfection systems and pools. -
Page 6: Technical Data
TECHNICAL DATA Materials Case: PP 30% reinforced with talc Front panel: Polycarbonate Roller-holder: PBT Rollers: Delrin (self-lubricant) Internal tube: Santoprene, Tygon or silicone Fittings: External Tubes 4x6 mm Power Supply 230 Vac (115 Vac or 24 Vdc upon request) Ambient temperature max 40°... -
Page 7: Hydraulic Connections
HYDRAULIC CONNECTIONS Warning! Avoid restricting or sharp bends in the suction and injection pipes, as they may affect the performance and durability of the pump itself. Suction line: Connect the suction tube (b) to the suction connection (a) and tighten the threaded nut (c). Injection line: Connect the injection tube (e) to the injection connection (d) and tighten the threaded nut (f). -
Page 8: Electrical Connections
ELECTRICAL CONNECTIONS Warning! Connection to the mains must be carried out in strict compliance with all the pertinent rules and regulations. Warning! Before powering the pump verify that all electrical and plumbing connections have been properly made. Power the pump following the values of voltage and power consumption indicated on the pump label. Power supply 230 Vac, 50 Hz: connect the power supply to the 2 blue wires, shown in the figure. -
Page 9: Maintenance And Storage
MAINTENANCE AND STORAGE The periodic maintenance operations are essential for the proper functioning of the pump and its duration. These operations must be performed in a systematic and thorough way, following the information below: Periodically check the level of the liquid to be dosed, to prevent the pump from running empty Check that the suction and injection tubes do not contain impurities, as they may cause damage to the pipe and anomalies in the flow rate Schedule a general check of the pump functioning, especially when dosing aggressive liquids... -
Page 10: Mechanical Dimensions
Storage of the pump after use: Before storing the pump, dose clean water to rinse the tube. Place the roller-holder as shown in the figure, turning it clockwise. MECHANICAL DIMENSIONS All dimensions in the figure are in mm. 70,4 47,6 25,5 12,75 EF100_r00 –... -
Page 11: Exploded View Of The Pump
EXPLODED VIEW OF THE PUMP Ref. Description Motor Peristaltic head Roller-holder Peristaltic tube Protection cover Screw M3x8 (2 pc.) Threaded nut (2 pc.) Screw M3x16 (2 pc.) EF100_r00 – 05/2012 page...
