Membrane Electromagnetic
Dosing Pumps
PROXIMA PSP164
with inbuilt Conductivity meter
TECHNICAL MANUAL
(v.1120)
DosingPump.ir
STEIEL Elettronica S.r.l. – Viale Europa, 24 – 35020 Ponte San Nicolò – PADOVA ITALIA
Tel. +39-049-8961488 – www.steiel.it – info@steiel.it
Certified Company, according to UNI EN ISO 9001 standards
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Steiel PROXIMA PSP164
Summary of Contents for Steiel PROXIMA PSP164
- Page 1 PROXIMA PSP164 with inbuilt Conductivity meter TECHNICAL MANUAL (v.1120) DosingPump.ir STEIEL Elettronica S.r.l. – Viale Europa, 24 – 35020 Ponte San Nicolò – PADOVA ITALIA Tel. +39-049-8961488 – www.steiel.it – info@steiel.it Certified Company, according to UNI EN ISO 9001 standards...
- Page 2 The manufacturer can modify the instrument or the technical manual without advanced notice. Warranty All STEIEL products are warranted for a period of 12 months from the delivery date. Warranty is not valid if all instructions of installation, maintenance, and use, are not strictly followed by the user.
-
Page 3: Table Of Contents
TABLE OF CONTENTS HEALTH AND SAFETY ..........................4 PACKING LIST ............................6 INTRODUCTION AND PRINCIPLE OF OPERATION ................6 TECHNICAL DATA ........................... 7 INSTALLATION ............................9 HYDRAULIC CONNECTIONS ....................... 10 ELECTRICAL CONNECTIONS ......................11 DESCRIPTION OF THE FRONT PANEL ....................15 .............................. -
Page 4: Health And Safety
HEALTH AND SAFETY The pump must be operated ONLY by authorized and trained technical personnel. All instructions and prescriptions in the technical manual must be strictly followed. Failure to follow these instructions can result in serious damages to the equipment and, in extreme cases, to people. - Page 5 Risk of electric shock! If the pump housing is damaged, immediately unplug the pump and power it again only after a proper repair by an authorized technician. Attention to dosed chemicals! Before any operation on the pump, discharge the liquid from the pump head and pipes.
-
Page 6: Packing List
PACKING LIST 1) Dosing pump 2) Pack of PVDF ring nuts, fittings and gaskets for suction and delivery valves 3) Standard accessories for pump: PVC Crystal hose for suction line (2 m, diameter depending on pump flow rate), PVC Crystal hose for bleed line (2 m, 4x6 mm), semi-rigid PE hose for injection line (5 m, diameter depending on pump flow rate), foot filter and injection valve 4) Cable with M8 female connector (corresponding in number to the options provided) 5) Technical manual... -
Page 7: Technical Data
TECHNICAL DATA Power Supply 100 … 240 V~, 50/60 Hz, 60 VA max. (standard version: cable with Schuko plug; without plug upon request) Electrical Protection Fuse 5x20 F1.6A Display 2-row (x 12 characters) alphanumeric LCD, with backlight , , Keys 5 membrane-keys (CAL, ESC, ON-OFF) 2 LEDs: “POWER”... - Page 8 Digital Inputs General Technical Data • vacuum voltage: typical 10 V, max 18 V • current with contact closed: max 3.8 mA • power supply voltage for micro-magnetic: 18 V ±5%, max 10 mA • frequency: max 10 Hz (minimum pulse duration 50 msec) EXT.CONS.
-
Page 9: Installation
INSTALLATION Warning! Failure to follow instructions can cause damage to the equipment and, in extreme cases, to people. Warning! When working on the pump wear the adequate systems of personal protection (gloves, apron, goggles). • Install the pump away from sources of heat, humidity and chemical fumes. Also prevent that the pump is exposed to direct sunlight to avoid overheating. -
Page 10: Hydraulic Connections
HYDRAULIC CONNECTIONS Suction and Delivery Lines Hose Threaded ring Locking ring Pipe-holder nozzle Gasket Valve Cut the hose to be connected to the pump (PVC Crystal for suction line or PE for delivery line). Insert the threaded ring (2) and the locking ring (3) on the tube. ... -
Page 11: Electrical Connections
ELECTRICAL CONNECTIONS The pump is supplied with prewired power cable and connectors for the available inputs / outputs, depending on the desired configuration. Below is an indicative diagram of the arrangement of the connectors and pin-out of the M8 axial connector, used for pump wiring. - Page 12 FLW Connector – Input for Injection Flow Control (optional) Optional input, available on axial M8 connector, for the control of injected liquid, not to be confused with the control of water flow to the sensor. It allows monitoring the actual injection (passage of liquid) at each magnet pulse.
- Page 13 ELECTRONIC BOARDS (for technical personnel only) The information given in this section is intended for skilled technicians, authorized for maintenance and / or repair of dosing pumps. Prior to open the pump, it is recommended to place the stroke knob at a known position (e.g.
- Page 14 View of the power board Protection fuse 5x20 F1.6A Power supply terminal block S1 always ON Configuration Faston for magnet grounding Status and magnet pulse LED Magnet connector Power supply Flat to the input board Allowed operations: Fuse replacement on the power line: use a fuse of the same size and dimensions. Before replacing the fuse, verify the blowing cause (for example, overvoltage, wrong connection, atmospheric discharge);...
-
Page 15: Description Of The Front Panel
DESCRIPTION OF THE FRONT PANEL ON/OFF Key Enables / disables the magnet without shutting down the pump MENU/OK Key Allows the access to a circular menu, in which the options may be scrolled using the arrow keys ; in menu modes, confirms the modification and/or the entered value. -
Page 16: Start-Up
Litre-Counter (for service / maintenance request) Error of injection flow control Status of the output relay Pump internal temperature These are the same info provided in the “Additional Visualizations” menu, but in short form. For further details, please refer to the relevant section. -
Page 17: Autoset
AUTOSET This function allows to load / restore the factory settings related to the selected configuration. Enter the “Autoset” menu and select the desired configuration by scrolling the various available options with the arrow keys , A u t o s e t C o n f i r m then press the MENU/OK to confirm the function activation. -
Page 18: Configuration
CONFIGURATION The PROXIMA PSP pumps feature two configuration levels: standard and advanced. The standard configuration is normally accessed by the end user, for editing a few parameters, as the adjustment thresholds, dosing frequency and display language. The advanced configuration instead allows to change all parameters and is normally protected by a password to prevent incorrect settings by unauthorized personnel. -
Page 19: List Of Parameters
List of Parameters In this section you can find the full list of configuration parameters, divided per pump version. The parameter P01 sets the operation mode and determines the parameters P04, P06…P11, while all the remaining parameters are common for all models. It is recommended to fill the last column with the values set for your specific application. -
Page 20: Meaning Of Parameters
FACTORY PAR. DESCRIPTION VALUE VALUE SETTING VALUE A 9600, A 9200, A 38400, Serial Line Type (BPS) A 9600 MB 9600, MB 9200, (A=Ascii; MB = Modbus) MB 38400 Serial Address Options Meaning of Parameters PARAMETER 01 PUMP TYPE The following operation modes are available: Steady = the pump (if enabled) works at the constant frequency set in P05 Conductivity range = the pump is equipped with an input for two-electrode conductivity cell;... - Page 21 PARAMETER 04 EXTERNAL CONSENT / FLOW INPUT If the pump operates in steady mode or in case of model with analogic input, this contact input can be set as NO (Normally Open when enabled) or NC (Normally Closed for activating the pump). The standard factory configuration is NO contact.
- Page 22 PARAMETER 12 DISPLAY TYPE This parameter allows to choose the information to be displayed during normal operations. The available options depend on pump configuration, as shown in the following tables. Pump in STEADY mode Display row 1 Display row 2 Frequency [pulses/min] “Constant”...
- Page 23 unsuccessfully, the alarm remains active and, therefore, a user intervention is required to evaluate and solve the problem. Warning! The self-priming function is potentially hazardous! For example, in case of breakage or simply disconnection of the flow control while the pump works perfectly, the volume of 100 injections will be dosed in the system in less than one minute.
- Page 24 has been successfully completed. If, instead, the threshold is not reached within the set time, the pump stops dosing and displays the error message “Max dosing”. This condition may be caused, for example, by an under-sizing of the pump with respect to the system needs, by the dosage of a too diluted product, by empty injections due to loss of priming, etc.
- Page 25 PARAMETER 42 SERIAL LINE TYPE If the pump is provided with the “serial output” option, this parameter (and the next one) allows to set the operating mode and rate of the serial line. You can choose between Ascii communication (no protocol) and Modbus RTU protocol.
-
Page 26: Set Time (Date / Time Adjustment)
SET TIME (DATE / TIME ADJUSTMENT) To adjust the time and day of the week, access the circular menu S e t t i m e by pressing the MENU/OK key, scroll the available options with C o n f i r m the arrow keys and select the “Set time”... -
Page 27: Calibration Of The Analogic Input
CALIBRATION OF THE CONDUCTIVITY INPUT Note that the ZERO (offset) error is normally very low (dry cell in air) and that the GAIN error is generally within ±10% (max mechanical tolerance of the cell). It is recommended not to calibrate if these values are not too far from the theoretical ones. -
Page 28: Calibration Of The Injection Volume
CALIBRATION OF THE INJECTION VOLUME To get correct visualizations and calculation of flow rate and litre-counters, you need to correctly set the volume corresponding to a pump injection. Access the circular menu by pressing the MENU/OK key, scroll the available options with the arrow keys and select the “Injection Calibration”... -
Page 29: Errors And Alarms
ERRORS AND ALARMS When an error or alarm occurs, the POWER LED blinks fast, and the display shows on the bottom line the related error message. If several errors are active, a sequence of all related messages is displayed. List of the possible messages: Start mm:ss Pump just started. -
Page 30: Serial Line (Optional)
SERIAL LINE (optional) The pump may feature an RS485 serial line for communication with terminals, PC or advanced PLC. For an easier understanding, the supervisor will be called “Master”. If the pump is connected to a PC on which an “HYPERTERMINAL” (or similar) program is running, on the “Master” display appears exactly the response of the pump to the received command. - Page 31 MODBUS RTU In this case, the communication takes place through the standard protocol by Modicon (http://www.modbus.org/). Data exchange is performed via “holding registers”, allocated as follows: Register No. of Command Action Result registers Read 0x03 1…56 1..16 Read registers Value of related parameter Write 0x06 1…56 Write the single register...
- Page 32 #1: Encoding of the status of the inputs (HR121): Bit 0 (weight 1) = Level Bit 1 (weight 2) = External consent (or pulse) Bit 2 (weight 4) = Injection flow #2: Encoding of the status of the outputs (HR122): Bit 0 (weight 1) = The pump is dosing (cannot be used in case of proportional control) #3: Encoding of the alarms (HR123):...
-
Page 33: Additional Visualizations
ADDITIONAL VISUALIZATIONS This menu allows to display some specific parameters, whose list can be scrolled by using the arrow keys . SW Version / Time Version of the pump software, P S P 1 6 4 0 6 . 2 1 current day and time. -
Page 34: Service" Menu
“SERVICE” MENU This menu is intended for skilled technicians and is protected by a fix password (communicated to the authorized technicians only), and allows the visualization of some special and important parameters, whose list you can scroll by using the arrow keys . Stop Time When the pump stops operating for S t o p... -
Page 35: Maintenance
MAINTENANCE The periodic maintenance is of fundamental importance for the good functioning of the pump and its duration over time. Should be performed in a systematic and precise way, following all the indications given here below. The pump maintenance must be carried out ONLY by qualified technicians and using ONLY original spare parts! Pump Decommissioning Thoroughly clean the pump housing, dosing head and the whole dosing line (see next... - Page 36 Cleaning Service and Replacement of Wearing Parts Attention to dosed chemicals! Before any operation on the pump, discharge the liquid from the pump head and pipes. Take all necessary personal protective measures (i.e. gloves and goggles), as indicated in the SDS of the chemical, which must be always available and updated.
- Page 37 o Hold the pump housing (6) with one hand and using the other one grab the membrane (3), located between the dosing head (2) and the dosing disc (4). o Loosen the membrane (3) from the motor shaft, by slightly twisting counterclockwise the dosing head (2) and the head disc (4).
- Page 38 o While the pump is working, slowly turn the membrane (3) clockwise until the four holes on the membrane match those on the pump housing (6). o Hold tightly the membrane (3) in this position, adjust the stroke length at 0% and stop the pump.
-
Page 39: Exploded View Of Dosing Heads
EXPLODED VIEW OF DOSING HEADS PKT pump head (PVDF parts with ceramic ball valves and PTFE seals) Connection kit, including threaded ring, locking ring and hose-holder nozzle Spring (special accessory, valves for dosing viscous liquids up to 500 mPa•s) Ceramic ball Purge valve Complete delivery valve Dosing membrane... - Page 40 MKV pump head (methacrylate body, PVC valves with ceramic ball, FPM seals) Connection kit, including threaded ring, locking ring and hose-holder nozzle Ceramic ball Purge (and vent) valve, with adjustment screw (*) Complete delivery valve Dosing membrane Complete suction valve (*) If necessary, adjust this screw properly.
-
Page 41: Accessories And Spare Parts
ACCESSORIES AND SPARE PARTS Item, Description Part No. Accessory kit for full maintenance of pump head, 0216 PKT 97003000/PKT Accessory kit for full maintenance of pump head, 0510 PKT 97003001/PKT Accessory kit for full maintenance of pump head, 1304 PKT 97003002/PKT Accessory kit for full maintenance of pump head, 2002 PKT 97003003/PKT... -
Page 42: Coding System
CODING SYSTEM This diagram allows to build the code of the pump with the desired characteristics. Pump Model PSP164 – Pump with inbuilt conductivity meter Power Supply 0 100-240 V~ - cable with Schuko plug 1 100-240 V~ - open cable (no plug) 2 100-240 V~ - cable with type B plug Optional Outputs 0 No output...
