LS ELECTRIC LSLV-S300 Series User Manual

Ac variable speed drive
Hide thumbs Also See for LSLV-S300 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
The right choice for the ultimate yield!
LS ELECTRIC strives to maximize your profits in gratitude for choosing us as your partner.
AC Variable Speed Drive
LSLV-S300 Series
Safety Instructions
• Read this manual carefully before installing,
wiring, operating, servicing or inspecting
this equipment
• Keep this manual within easy reach for
quick reference.
0.4~75 kW[200V] 0.4~220 kW[400V]
User's Manual
