Summary of Contents for LS ELECTRIC LSLV-S300 Series
Page 1
The right choice for the ultimate yield! LS ELECTRIC strives to maximize your profits in gratitude for choosing us as your partner. LD-Encoder Option Card LSLV-S300 Series User’s Manual Safety Insturctions • Read this manual carefully before using this card.
Page 3
Before using the product Thank you for using the pulse line encoder option card.
Page 4
Safety Information Safety Information Read and follow all safety instructions in this manual precisely to avoid unsafe operating conditions, property damage, personal injury, or even death. Safety symbols in this manual Danger Indicates an imminently hazardous situation that, if not avoided, will result in severe injury or even death.
Overview 1 Overview The pulse line drive encoder card is an option available for the S300 series only. The position/speed of the rotor can be measured through the position/speed sensor, enabling vector control of the motor.
Names of Parts 3 Names of Parts Screw hole Switch (S1) Terminal block Screw hole Dip switch configuration Switch labels Description Output power switch for 5 V/12 V settings (top: 5 V, bottom: 12V) Caution Do not change switch settings during inverter operation. It may cause a trip and have an impact on the system.
Installing the Inverter 4 Installing the Inverter Option Card Installation Install the product on the board inside the inverter in the following order: Note Depending on the product family, the number of bolts on the front cover and the position and shape of the board may vary.
Page 11
Installing the Inverter 3 Press both ends of the Smart Operator mounting bracket inward and lift upward. • Remove the RJ45 connector if Smart Operator is installed. 4 Assemble the grounding plate in the grounding plate bracket in the center of the inverter and fasten the two screws (M4) at the proper torque to fix it.
Page 12
Installing the Inverter 5 Fasten the two screws (M4) at the proper torque to fix the pulse line drive encoder on the inverter. Torque: 13.0 kgf·cm Torque: 18.0 kgf·cm 6 Reassemble the inverter in the reverse order of the disassembly.
Installing the Inverter Terminal Block Wiring 4.2.1 Terminal Block Composition Terminal Category Name Description Labels This is the power for +5 V/+ 12 V encoder Encoder power line drive. Output This is a grounding terminal for encoder Ground Power power. This is a terminal that connects the Shield shielding wire of the encoder signal line.
Installing the Inverter 4.2.2 Example of Terminal Block Wiring Refer to the following example and connect the RA+, RA-, RB+, RB-, RZ+, and RZ- outputs of the pulse line drive encoder to the peripheral control devices: Pulse Line Drive Encoder Peripheral Control Device A+ phase input A- phase input...
Page 15
Installing the Inverter Caution • Make sure to use shield type twisted pair cables. • Make sure to install the encoder so that it rotates at the same speed as the motor shaft. e.g. the half-loaded side shaft of the motor and the opposite side shaft of the motor of the traction machine •...
Troubleshooting 5 Troubleshooting Refer to the following when a trip occurs while using the encoder: Items Cause Remedy A trip occurs when you set the Set the ENC-16 (Wire Check ENC-16 (Wire Check Trip En) Trip En) code to 0 (No) and Encoder No Connect code to 1 (Yes) and wiring check the wiring between the...
Table of Encoder Group (ENC) Functions 6 Table of Encoder Group (ENC) Functions The following table shows all functions of the encoder group (ENC) that can be set in the inverter: For more details on each parameter code, refer to 3.3 Encoder Settings in the S300 Inverter User Manual.
Technical Specifications 7 Technical Specifications Output Standard Terminal Voltage Maximum Items Remark Labels Range (V) Current (A) Select the switch (S1) as 5.3~5.7 5 V output power Output Power Select the switch (S1) as 11.5~12.5 0.07 12 V output power RA+/RA- ±3.5~±4.5 0.01...
Technical Specifications Operating Environment Items Standard Operating -10~40 ℃ Temperature Ambient Relative humidity less than 90% RH (to avoid condensation forming) humidity Storage -20~65 ℃ temperature Environmental Prevent contact with corrosive gases, inflammable gases, oil stains, dust, Factors and other pollutants (Pollution Degree 2 Environment Pollution level that involves non-conductive pollution, but is expected to occasionally cause temporary conductivity due to condensation.
Page 20
• power supply problems or from other appliances being connected to the product • acts of nature (fire, flood, earthquake, gas accidents etc.) • modifications or repair by unauthorized persons • If the LS ELECTRIC nameplate is not attached to the product. • expired warranty period Visit Our Website Visit us at LS ELECTRIC website (https://www.ls-electric.com) for detailed service and...
Page 21
제품을 사용하기 전에 먼저 저희 펄스 라인 드라이브 엔코더 옵션 카드를 사용하여 주셔서 감사합니다.
Page 22
안전을 위한 주의 사항 안전을 위한 주의 사항 제품을 사용하기 전에 안전을 위한 주의 사항을 반드시 읽고 제품을 올바르게 사용하십시오. 사용 설명서에 표기된 안전 기호 위험 주의하여 대처하지 않으면 사용자가 사망하거나 중상을 입을 수 있는 긴급한 위험 상황입니다. 경고 주의하여 대처하지 않으면 사용자가 사망하거나 중상을 입을 수 있는 잠재적인 위험 상황입니다.
Page 23
목차 목차 1 소개 ........................1 2 제품 구성품 ....................... 2 3 각부 명칭 확인 ....................3 4 제품 설치하기 ....................4 옵션 카드 설치 ..................4 단자대 결선 ..................... 7 4.2.1 단자대 구성 ................... 7 4.2.2 단자대 결선 예시 ................8 5 문제...
Page 25
소개 1 소개 펄스 라인 드라이브 엔코더 카드는 S300 시리즈 전용 옵션입니다. 위치/속도 센서를 통해 회전자의 위치/속도를 측정하여 전동기 벡터 제어를 수행할 수 있습니다.
각부 명칭 확인 3 각부 명칭 확인 나사 홀 스위치(S1) 단자대 나사 홀 딥 스위치 구성 스위치 기호 설명 출력 전원 5V/12V 설정 스위치(상: 5V, 하: 12V) 주의 인버터 운전 중에 스위치 설정을 변경하지 마십시오. 트립이 발생해 시스템에 영향을 미칠 수...
제품 설치하기 4 제품 설치하기 옵션 카드 설치 다음 순서에 따라 제품을 인버터 내부의 기판에 설치하십시오. 참고 제품군에 따라 전면 커버의 볼트 개수 및 기판의 위치와 형상이 다를 수 있습니다. 자세한 내용은 S300 인버터 사용 설명서 1.2 각부 명칭 확인을 참조하십시오. 1 인버터의...
Page 29
제품 설치하기 3 Smart Operator 거치 브래킷의 좌우 끝을 안쪽으로 누른 상태에서 위로 들어올리십시오. • Smart Operator가 장착되어 있는 경우, RJ45 커넥터를 제거하십시오. 4 접지판을 인버터 중앙의 접지판 고정대에 조립한 후, 나사 두 개(M4)를 각 체결 토크에 맞게 조여 접지판을 인버터에 고정하십시오. 체결...
Page 30
제품 설치하기 5 나사 두 개(M4)를 각 체결 토크에 맞게 조여 펄스 라인 드라이브 엔코더를 인버터에 고정하십시오. 체결 토크: 13.0kgf·cm 체결 토크: 18.0kgf·cm 6 분해의 역 순으로 인버터를 조립하십시오.
제품 설치하기 단자대 결선 4.2.1 단자대 구성 분류 단자 기호 명칭 설명 +5V/+12V 엔코더 라인 드라이브 전원입니다. 엔코더 전원 접지 엔코더 전원 접지 단자입니다. 출력 전원 엔코더 신호선의 실드선을 연결하는 실드 단자입니다. 엔코더의 A+/A-상 출력 신호선을 연결하는 A+/A- 엔코더 A상 신호 단자입니다.
제품 설치하기 4.2.2 단자대 결선 예시 아래 예시를 참고해 펄스 라인 드라이브 엔코더의 RA+, RA-, RB+, RB-, RZ+, RZ- 출력을 주변 제어 기기에 연결하십시오. 펄스 라인 드라이브 엔코더 주변 제어 기기 A+ 상 입력 A- 상 입력 B+ 상 입력 B- 상...
Page 33
제품 설치하기 주의 • 반드시 실드 타입 트위스트 페어 케이블(Shield type twisted pair cable) 사용하십시오. • 반드시 전동기의 축과 같은 속도로 돌고 있는 곳에 엔코더를 설치하십시오. 예) 전동기의 반 부하측 축, 권상기(Traction Machine)의 전동기 반대편 축 • 전동기 축과 엔코더 축 간에 슬립이 있을 경우, 전동기가 작동하지 않거나 심한 진동이 발생할...
문제 해결하기 5 문제 해결하기 엔코더 사용 시 트립이 발생한 경우 다음 내용을 참조하십시오. 항목 진단 조치 사항 ENC-16(Wire Check Trip En) ENC-16(Wire Check Trip En) 코드를 1(Yes)로 설정 시 코드를 0(No)으로 설정한 후 Encoder No Connect 엔코더와 엔코더 옵션 사이의 엔코더와...
엔코더 그룹(ENC) 기능 일람표 6 엔코더 그룹(ENC) 기능 일람표 아래 표는 인버터에서 설정할 수 있는 엔코더 그룹(ENC)의 모든 기능을 보여줍니다. 각 파라미터 코드에 대한 자세한 설명은 S300 인버터 사용 설명서 3.3 엔코더 설정을 참조하십시오. 통신 주소 LCD 표시 코드 설정 범위 초깃값...
기술 사양 7 기술 사양 출력 규격 항목 단자 기호 전압 범위(V) 최대 전류(A) 비고 스위치(S1)를 5V 출력 5.3~5.7 전원으로 선택 출력 전원 스위치(S1)를 12V 출력 11.5~12.5 0.07 전원으로 선택 RA+/RA- 0.01 ±3.5~±4.5 RB+/RB- 0.01 출력 펄스 ±3.5~±4.5 RZ+/RZ- 0.01 ±3.5~±4.5 입력...
기술 사양 사용 환경 항목 규격 -10~40 ℃ 사용 온도 상대 습도 90% RH 이하(이슬 맺힘 현상 없을 것) 주위 습도 -20~65 ℃ 보관 온도 실내에 부식성 가스, 인화성 가스, 기름 찌꺼기, 먼지 등이 없을 것(Pollution 주위 환경 Degree 2 Environment 비도전성의...
Page 38
• 천재지변에 의해 고장이 발생한 경우(화재, 수해, 가스 사고, 지진 등) • 당사 특약점이나 서비스 센터가 아닌 곳에서 제품을 임의로 개조 또는 수리한 경우 • 제품에 LS ELECTRIC 명판이 부착되어 있지 않은 경우 • 무상 보증 기간이 지난 경우 홈페이지 안내...
Page 40
E-Mail: italia @ls-electric.com Tel: 90-212-806-1225 Tel: 39-030-8081-833 ⓒ 2024. 02 LS ELECTRIC Co., Ltd. AII Rights Reserved. / (01) 2024. 02 Human Power 2024. 02 ※ 본 제품의 규격은 품질개선을 위하여 예고없이 변경될 수 있으므로 제품구입시 문의 바랍니다. ⓒ 2023. 09 LS ELECTRIC Co.,Ltd. All rights reserved. / (01) 2023. 09 Human Power...
