WaveForm QuadMini Duo Manual page 13

Low profile 8x8 mimo antenna

Advertisement

If you're mounting your antennas indoors...
Your QuadMini Duo offers two indoor mounting options: window or desktop mounting. For
better performance, we strongly recommend mounting your QuadMini Duo outdoors instead.
Regardless of the mounting option you choose, remember to mount the antennas near the
window you identified in section 4.
We're Here to Help!
We know that every use case is different and the steps for mounting your antennas may differ
for your unique location. Don't worry! If you're running into issues, or have any questions, just
reach out.
Option 3: Window Mount
If you can't mount your QuadMini antennas outdoors, follow the
steps below to mount each QuadMini against your window using the
included suction cups:
1
Thread each suction cup
into the back of each
QuadMini.
Option 4: Desktop Mount (Limited Performance)
If you can't mount both QuadMinis directly against your window, but
have an available window sill, table, desk or other flat surface nearby,
follow the steps below to position each QuadMini near your window:
1
(Optional) Feed the
cables through the
desktop bracket.
2
Press each QuadMini
firmly against the window.
2
Align the desktop
bracket with the back
of each QuadMini.
3
Secure the desktop
bracket into each
QuadMini with the
thumb screws.
13
