1. About This Guide
This document provides information and use instructions about the Anker SOLIX X1 Power Module X1-H(5~12)K-T series or hybrid three-phase power
modules.
2. Product Introduction
2.1 Product Overview
Function
The Anker SOLIX X1 Power Module X1-H(5~12)K-T series (power module for short) is a hybrid three-phase power module that offers a comprehensive
solution for home energy storage.
The power module can integrate with solar panels to convert excess energy into electricity, charge the batteries to store the energy in the batteries,
and control the batteries to supply power to the loads. Without solar, the power module can control multiple battery modules to charge during low-
cost electricity hours and discharge during high-cost electricity hours.
Model
https://salesforce-knowledge.s3.us-west-2.amazonaws.com/A5103%20HTML%20EN/A5103_V02_EN_EU_UG_20240819.html
2024/8/23 11:12
第1/15⻚

Advertisement

loading
Need help?

Need help?

Do you have a question about the SOLIX X1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Anker SOLIX X1

  • Page 1 2.1 Product Overview Function The Anker SOLIX X1 Power Module X1-H(5~12)K-T series (power module for short) is a hybrid three-phase power module that offers a comprehensive solution for home energy storage. The power module can integrate with solar panels to convert excess energy into electricity, charge the batteries to store the energy in the batteries, and control the batteries to supply power to the loads.
  • Page 2: System Layout

    2.2 System Layout The Anker SOLIX X1 Power Module applies to energy storage systems with partial home backup. The system stores energy from the grid or solar power and powers selected loads during a grid outage.
  • Page 3: Product Appearance

    A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 2.3 Product Appearance Figure: Appearance of Anker SOLIX X1 Power Module X1-H(5~12)K-T. PV power ports (PV1+ / PV1–, PV2+ / PV2–) PV switch • Toggle ON to power on the connected PV system. • Toggle OFF to power off the connected PV system.
  • Page 4 A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 Screw hole for locking modules DC power ports (BAT+ / BAT–) LED screen Status light WLAN/4G port Communication ports / terminals * AC grid port AC backup port Breather valve External ground point Screw hole for locking modules Heat sink Wall-mount cleats 3.
  • Page 5: Status Light Indication

    4.1 Access Anker App (User) ① Download the Anker app from the App Store (iOS devices) or Google Play (Android devices), or by scanning the QR code. ②Log into the app. If you have not previously created an account, check the email to get your account name and initial password.
  • Page 6 Off-Grid *The Anker SOLIX X1's off-grid mode is incompatible with the Sunlight Backup mode of the Enphase microinverter. It is necessary to disable the Sunlight Backup mode of the Enphase microinverter before using the Anker SOLIX X1's off-grid mode.
  • Page 7: Firmware Upgrade

    A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 4.4 Set Advanced Options There are three advanced options that impact how the energy storage system exports and imports power to and from the grid. 1. Tap the settings icon in the top right corner of the home screen. 2.
  • Page 8: Maintenance

    A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 immediately to ensure your software is always up to date. > 2. If you want to check for firmware upgrade, go to Settings Firmware Upgrade. If there's a new version, simply follow the on-screen instructions to complete the upgrade. You may choose Update Now Select Update Time.
  • Page 9: Routine Maintenance

    • Brief description of the issue For instance, if a ground fault is detected, the Anker app will send a notification, the light bar will turn red, and the power module screen will show 'EE.' which meets the Earth Fault alarm requirements of AS/NZS 5033.
  • Page 10: Customer Service

    • If there is an obvious odor, smoke, or fire, keep away from the equipment immediately and contact professional personnel. • Do not use the battery module if it has been dropped or hit. Please contact your installer. In all cases, once the situation is stable, contact the Anker Customer Service. 7. Customer Service support@anker.com...
  • Page 11: Specifications

    A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 8.2 Specifications Specifications are subject to change without notice. Product Name Anker SOLIX X1 Power Module Model Name X1-H5K-T X1-H8K-T X1-H10K-T X1-H12K-T PV INPUT MPPT Voltage Range 140 - 950 Vd.c. 140 - 950 Vd.c. 140 - 950 Vd.c.
  • Page 12: Safety Information

    A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 Max. Output Active 5 kW 8 kW 10 kW 12 kW Power Max. Output Current 8.4 Aa.c. 13.3 Aa.c. 16.7 Aa.c. 20 Aa.c. Max. Input Power / 10 kVA / 15.2 Aa.c. 16 kVA / 24.3 Aa.c. 20 kVA / 30.3 Aa.c.
  • Page 13 A5103_V02_EN_EU_UG_20240819 2024/8/23 11:12 Caution, hot surface Indicates that equipment surfaces may be hot and pose a burn risk. PE conductor terminal Indicates a terminal that allows the electrical connection of conductors for earthing or grounding purposes. General Information SAVE THESE INSTRUCTIONS - This document contains important instructions that must be followed during installation, use, and maintenance. Read instructions carefully before performing any operation on the equipment.
  • Page 14 • The equipment can be powered on only after all faults are rectified. Failing to do so may escalate faults or damage the equipment. 9.2 Notice Declaration of Conformity Hereby, Anker Innovations Limited declares that this equipment is in compliance with Directives 2014/30/EU & 2011/65/EU. The full text of the EU declaration of conformity is available at the following internet address: https://support.anker.com/s/articleRecommend? otherType=Anker_EN_Extemal_Manual_and_Download&secondType=doc.
  • Page 15 60°C (140°F), sunshine or like, expose to extremely low air pressure or dispose of in fire or water. Replace only with specified batteries. Anker Innovations Limited I Unit 56, 8th Floor, Tower 2, Admiralty Centre, 18 Harcourt Road, Hong Kong https://salesforce-knowledge.s3.us-west-2.amazonaws.com/A5103%20HTML%20EN/A5103_V02_EN_EU_UG_20240819.html...
