Anker SOLIX Solarbank 2 E1600 Pro Manual

Anker SOLIX Solarbank 2 E1600 Pro Manual

Hide thumbs Also See for SOLIX Solarbank 2 E1600 Pro:

Advertisement

Table of Contents

Warning Signs
About This Guide
Unboxing
Check Before Installation
What's in the Anker SOLIX Solarbank 2 E1600 Pro Box
Optional Accessories
Overview
Product Overview
Button Controls
LED Guide
Installing Your Solarbank
Select an Installation Site
What You Need
Installation
Electrical Connections
Connecting Cables
*Connecting with FS20 Flexible Solar Panel (225W)
Turn On the Solarbank
Using the App
Download the App
Account Registration
Initialization Setting
Network Configuration
Add Home Devices (Optional)
Firmware Update
Power Mode Setting Initialization
Energy Plan Setting
FAQ
Specifications
Warning Signs
This sign signifies the presence of high voltage danger and risk of electric shock.
To prevent electric shock or personal injury, refrain from touching or using the inverter until 3
minutes have lapsed since its shutdown or disconnection.
Refer to the operation instructions.
About This Guide
This guide shows the primary system for the whole-home photovoltaic energy cycle, with Anker SOLIX Solarbank 2 E1600 Pro installed as the main service
equipment. This guide describes Anker SOLIX Solarbank 2 E1600 Pro in terms of unboxing, product overview, installation, electrical connections, button and
light explanation, customer service, and safety guidelines.
· One Anker SOLIX Solarbank 2 E1600 Pro can support up to five Anker SOLIX BP1600 Expansion Battery modules.
· Anker SOLIX Solarbank 2 E1600 Pro can be used with Anker SOLIX Smart Meter.
Unboxing
Check Before Installation
Check the Outer Packaging
Before unpacking the equipment, check the outer packaging for damage, such as holes and cracks, and review the equipment model number. If any damage
is found or the model is not what you requested, do not unpack the equipment and contact Anker customer service as soon as possible.
Check Deliverables
After unpacking the equipment, check that the deliverables are intact and complete, and free from any obvious damage. If any item is missing or damaged,
contact Anker customer service.
What's in the Anker SOLIX Solarbank 2 E1600 Pro Box
Model: A17C1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLIX Solarbank 2 E1600 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Anker SOLIX Solarbank 2 E1600 Pro

Summary of Contents for Anker SOLIX Solarbank 2 E1600 Pro

  • Page 1 About This Guide This guide shows the primary system for the whole-home photovoltaic energy cycle, with Anker SOLIX Solarbank 2 E1600 Pro installed as the main service equipment. This guide describes Anker SOLIX Solarbank 2 E1600 Pro in terms of unboxing, product overview, installation, electrical connections, button and light explanation, customer service, and safety guidelines.

  • Page 2: Optional Accessories

    Optional Accessories The following accessories must be ordered separately. Anker SOLIX BP1600 Expansion Battery (Optional) Model: A17C13Z1-85 Anker SOLIX Smart Meter (Optional) Model: A17X7 Overview Product Overview...

  • Page 3: Button Controls

    Power Button IoT Button Power Status LED IoT Status LED Working Status LED PV Connector Ports for PV Input 1 PV Connector Ports for PV Input 2 PV Connector Ports for PV Input 3 PV Connector Ports for PV Input 4 Grid-Tied Terminal Backup Terminal Ground Screw Hole (Protective earthing conductor wire should be at least 4mm²)
  • Page 4 Anker SOLIX Solarbank 2 E1600 Pro Expansion Battery Module ×1 ×2 ×3 ×4 ×5 Energy 1600Wh 3200Wh 4800Wh 6400Wh 8000Wh 9600Wh 2. Equipment Dimensions Figure: Figure: Anker SOLIX Solarbank 2 E1600 Pro Figure: Anker SOLIX BP1600 Expansion Battery What You Need...

  • Page 5: Installation

    Note: The following components are not included in this package. Please make sure they are ready before installation and electrical connection. Installation The steps below describe the installation of one Solarbank 2 E1600 Pro and two Expansion Batteries as an example. 1.
  • Page 6 4. Pre-fasten the L-Shape Wall Mount Fitting to both sides of the first expanion battery under Solarbank using M5×10 combined Phillips screws. Note: The L-Shape Wall Mount Fitting can be mounted on the front or the back. 5. Mark the position of drilling holes on both sides and use a drill with a φ8 drill bit and a depth of 60mm. 6.
  • Page 7 7. Use a Phillips screwdriver to fasten the M5×10 combination Phillips screws against the L-Shape Wall Mount Fitting; then secure the interlocking bracket to the expansion battery using the M5×10 combined Phillips screws to complete the installation. Note: · The grid connection must be connected to a socket with grounding, otherwise there is a risk of electric shock. Alternatively, the casing should be grounded. The grounding point is shown below.
  • Page 8 2. Find the PV connector ports of your solar panels. 3. Connect each set of PV modules to each set of PV input ports in Solarbank using the included Anker SOLIX Solar Panel Extension Cable (3m). Never connect two or more components in series because this causes the input voltage to exceed 60V and will damage the equipment.
  • Page 9 Turn On the Solarbank 1. The first use requires the connection of a solar panel and a home outlet. 2. When you use it at night, you can press and hold the power button on the solarbank for 4 seconds to turn it on, which will enable network pairing. Please complete the network paring with the app within 30 minutes.

  • Page 10: Account Registration

    Using the App Download the App Search "Anker" and download the App via App Store or Google Play. Or scan QR code below to go to the corresponding application store. Account Registration Region Selection When the app is launched, you will head to the login page.
  • Page 11 Step 4 The Anker App will automatically search for your Solarbank. Once the device is found, it will appear on the list. · Please make sure your phone's Bluetooth is on, and the Anker App is authorized to access Bluetooth and Wi-Fi.
  • Page 12 If you have purchased Anker SOLIX Smart Meter, please scan the QR code below for more details. Anker SOLIX Smart Meter can be added to the home system by following the process below. If you do not need to add any devices, you can skip the process by clicking [Skip].

  • Page 13: Firmware Update

    4. After paring the Smart Meter, return to the [Add Devices] interface. At this time, you can see the Smart Meter in the list. 5. Select the Smart Meter to add it to the system. Firmware Update Make sure all your devices have configured Wi-Fi and have a stable network connection. 1.
  • Page 14 · Self-Consumption: In this mode, the Smart Meter calculates the power needed for household loads and sends it to Solarbank for efficient use of solar energy. Excess power is stored in the battery. This mode is only possible with a Smart Meter. ·...

  • Page 15: Specifications

    1. Q: What precautions should I take before installing/adding expansion batteries? A: When installing/adding expansion batteries, it is necessary to power off and shut down the system to protect yourself and the machine. Performing this operation while powered on is not covered under warranty. Please follow the steps below for proper installation: a.
  • Page 16 Wet Location Classification Wet Location PD3 (External) Pollution Degree PD2 (Internal) Overvoltage Category OVCII (DC), OVCIII (AC) Protective Class Class I Warranty 10 Years Overvoltage Protection Overcurrent Protection Short Circuit Protection Protection Temperature Protection Overcharging Protection Over-Discharge Protection Dimensions 460 × 249 × 254mm Dimensions and Weight Net Weight...
