Manual
ASUS IoT
H610T-EM-A
Thin Mini-ITX, LGA1700 socket for the 12th /13th /14th Gen CPU, H610 chipset, 2*SO-DIMM,
3*DP, 1*eDP, 1*LVDS, 2*M.2 slot
The information contained in this document has been carefully researched and is, to the best of our
knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or
consequential, resulting from the use of the information provided herein. Our products are not intended for
use in systems in which failures of product could result in personal injury. All trademarks mentioned herein
are property of their respective owners. All specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H610T-EM-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus H610T-EM-A

Summary of Contents for Asus H610T-EM-A

  • Page 1 Manual ASUS IoT H610T-EM-A Thin Mini-ITX, LGA1700 socket for the 12th /13th /14th Gen CPU, H610 chipset, 2*SO-DIMM, 3*DP, 1*eDP, 1*LVDS, 2*M.2 slot The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate.
  • Page 2 H610T-EM-A...
  • Page 3 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 4: Table Of Contents

    Contents Chapter 1 Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Central Processing Unit (CPU) ........... 2-4 2.3.1 Installing the CPU ............2-5 2.3.2 CPU heatsink and fan assembly installation ....
  • Page 5 3.3.13 EZ-Flash ............... 3-10 3.3.14 Watchdog Timer ............3-10 Hardware Monitor menu ............3-10 Security menu ................3-11 Boot menu .................. 3-12 Exit menu ..................3-13 Appendix Notices .......................A-1 Service and Support .................A-5...

  • Page 6: Chapter 1 Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x ASUS H610T-EM-A Industrial Motherboard 1 x SATA 6.0 Gb/s cable 2 x M.2 screw packages 1 x ASUS I/O Shield NOTE: If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 7: Specifications

    1 x Chassis Intrusion header Internal I/O connectors 1 x Front Panel Audio header (AAFP) 1 x System Panel header 1 x Clear CMOS header 1 x Stereo Speaker header 1 x COM Debug header (continued on the next page) H610T-EM-A...
  • Page 8 1 x GPIO header (8-bit) 1 x LCD Panel Monitor Switch header 1 x Panel signal connector 1 x LVDS Panel VCC Power Selection jumper Internal I/O 1 x LVDS Panel Backlight Enable Signal Selection jumper connectors 1 x LVDS Backlight Panel header 1 x Power in Connector 1 x Amplifier 1 x Buzzer...
  • Page 9 H610T-EM-A...

  • Page 10: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component.

  • Page 11: Motherboard Layout

    ® H610 DDR4 So-DIMM_A1 (64bit, 204-pin module) 2280 Place this side LAN2 PANEL_SW towards the rear 8111H of the chassis 2260 LAN1 Intel ® I219V MIC_IN 2242 LINE_OUT AAFP M.2(WIFI) DIGI+ DC_PWR1 DC_PWR2 M.2(SOCKET3) CPU_FAN USB_78 USB_56 SPK_OUT VR_PROG H610T-EM-A...
  • Page 12 Connectors/Jumpers/Slots Page CPU and Chassis Fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 2-16 COM Debug header (5-1 pin COM_DEBUG) 2-24 General Purpose Input/Output header (10-pin GPIO_CON) 2-21 SATA 6.0 Gb/s ports (7-pin SATA6G_1-3) 2-21 COM RING/+5V/+12V Selection jumpers (6-pin COM1/2/3/4_SEL) 2-12 COM Port headers (10-1pin COM1 - COM4) 2-22 Chassis Intrusion header (4-1 pin CHASSIS)

  • Page 13: Central Processing Unit (Cpu)

    ASUS will shoulder the cost of repair only if the damage is shipment/transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1700 socket.

  • Page 14: Installing The Cpu

    DO NOT install a CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket. • ASUS will not cover damages resulting from incorrect CPU installation/ removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.
  • Page 15 H610T-EM-A...

  • Page 16: Cpu Heatsink And Fan Assembly Installation

    2.3.2 CPU heatsink and fan assembly installation CAUTION! Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 17 • We recommend using a LGA1700 compatible cooling system on an Intel 600 series ® motherboard. • Push-pin type LGA1200 compatible cooling systems cannot be installed to this motherboard. LGA1700 To uninstall the CPU heatsink and fan assembly H610T-EM-A...

  • Page 18: System Memory

    (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • According to Intel CPU spec, DIMM voltage below 1.35V is recommended ® to protect the CPU. NOTE: Visit the ASUS website at www.asus.com for the latest QVL. Chapter 2: Motherboard information...
  • Page 19 To install a SO-DIMM To remove a SO-DIMM H610T-EM-A 2-10...

  • Page 20: Jumpers

    Jumpers Clear CMOS jumper (2-pin CLRTC) The Clear CMOS jumper allows you to clear the Real Time Clock (RTC) RAM in the CMOS, which contains the date, time, system passwords, and system setup parameters. CLRTC +3V_BAT PIN 1 Connector type HEADER 1x2p, 2.54mm pitch, S/T To erase the RTC RAM: Turn OFF the computer and unplug the power cord.
  • Page 21 COM Ring/+5V/+12V Selection jumper (6-pin COM1/2/3/4_SEL) COM4_SEL COM3_SEL COM2_SEL COM1_SEL +12V (Default) Setting Pins +12V Ring (Default) AT/ATX mode Selection jumper (3-pin AT_ATX_SEL) AT_ATX_SEL ATX mode AT mode (Default) Pins 1-2 (Default) ATX mode AT mode Connector type HEADER 1x3p, 2.54mm pitch, S/T H610T-EM-A 2-12...
  • Page 22 LVDS Panel Backlight Enable Signal Selection jumper (BKLTEN_SEL) BKLTEN_SEL High Active Low Active (Default) BKLTEN_SEL Pins HIGH active LOW active Connector type HEADER 1x3p, 2.54mm pitch, S/T LVDS Panel VCC Power Selection jumper (6-pin VCC_PWR_SEL) VCC_PWR_SEL (Default) Setting Pins 3V (Default) Connector type HEADER 1 x 3p, 2.54mm pitch, S/T Chapter 2: Motherboard information...

  • Page 23: Connectors

    Audio 2, 4, 5.1 or 7.1-channel configuration Headset Port 4-channel 5.1-channel 7.1-channel 2-channel Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center Lime (Front panel) Side Speaker Out H610T-EM-A 2-14...
  • Page 24 To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. DC power connector. Insert the power adapter into this port. CAUTION! To avoid potential damage or system instability, do not connect both the DC power connector and the ATX Power connector simultaneously.

  • Page 25: Internal Connectors

    WAFER HD 4p, 2.54mm pitch, S/T CAUTION! Do not forget to connect the fan cables to the fan headers. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan headers! H610T-EM-A 2-16...
  • Page 26 USB 2.0 headers (10-1 pin USB_56, USB_78) These headers are for USB 2.0 ports. Connect a USB cable to the header. The USB headers comply with USB 2.0 specification that supports up to 480 Mbps connection speed. PIN 2 PIN 10 USB_78 PIN 1 PIN 2...
  • Page 27 This slot support M Key and 2242/2260/2280 storage devices. • We recommend using a PH1 screwdriver with a torque of 2.0+/-0.2 kgf·cm when tightening the screw. M.2 Wi-Fi slot This slot connects to an M.2 Wi-Fi device. M.2(WIFI) PIN 76 PIN 2 PIN 75 PIN 1 H610T-EM-A 2-18...
  • Page 28 NOTES: • The M.2 Wi-Fi module is purchased separately. • We recommend using a PH1 screwdriver with a torque of 2.0+/-0.2 kgf·cm when tightening the screw. System Panel header (10-1 pin F_PANEL) This header supports several chassis-mounted functions. F_PANEL PIN 9 O_RSTCON#_PR PWRBTN#_PANEL PLED-...
  • Page 29 The chassis intrusion sensor or switch sends a low-level signal to this connector when a chassis component is installed. The signal is then generated as a chassis intrusion event. CHASSIS PIN 1 Connector type HEADER 4p, K2, 2.54mm pitch H610T-EM-A 2-20...
  • Page 30 10. SATA 6.0Gb/s ports (7-pin SATA6G_1-3) These ports connect to SATA 6.0 Gb/s hard disk drives or an optical drive via SATA 6.0 Gb/s signal cables. SATA6G_3 SATA6G_1 SATA6G_2 RSATA_RXP RSATA_RXN RSATA_TXN RSATA_TXP Connector type SATA CON 7P S/T 11. General Purpose Input/Output header (GPIO_CON) This header is for a general purpose input/output module which allows you to customize the digital signal input/output.
  • Page 31 PIN 9 PIN 1 PIN 9 Connector type HEADER 2x5p, K10, 2.00mm pitch NOTE: The serial port cable is purchased separately. 13. RTC Battery header (2-pin BATTERY) This header is for the lithium CMOS battery. BATTERY PIN 1 H610T-EM-A 2-22...
  • Page 32 14. Front Panel Audio header (10-1 pin AAFP) This header is for a chassis-mounted front panel audio I/O module that supports HD Audio standard. Connect one end of the front panel audio I/O module cable to this header. PIN 2 PIN 10 AAFP PIN 1...
  • Page 33 HEADER 2x3p, K3, 2.54 mm pitch, S/T NOTE: The COM Debug Card is purchased separately. 16. LCD Panel Monitor Switch header (2-pin PANEL_SW) This 2-pin header is for connecting a monitor switch that can turn on/off the LCD panel display backlight. PANEL_SW PIN 1 H610T-EM-A 2-24...
  • Page 34 17. LVDS Backlight Panel header (5-pin LCD_BLKT_PANEL) This header is for the LCD panel brightness controls. LCD_BLKT_PANEL PIN1 Connector type WAFER 6p, 2.0mm pitch 18. LVDS/EDP header (40-pin LVDS_EDP) This header is for an internal LVDS or embedded DisplayPort connection. LVDS_EDP PIN 2 PIN 1...
  • Page 35 19. SPI header (10-1 pin SPI) This header connects to compatible Serial Peripheral Interface (SPI) devices. PIN 1 PIN 2 F_BIOS_WP# +3VSB_SPI S_SPI_CS1# S_SPI_CLK F_SPI_MISO S_SPI_MOSI F_SPI_HOLD# PIN 9 H610T-EM-A 2-26...

  • Page 36: Chapter 3 Bios Setup

    Always shut down the system properly from the operating system. IMPORTANT: • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. • The default BIOS settings for this motherboard apply to most working conditions and ensures optimal performance.

  • Page 37: Bios Menu Screen

    The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 3.2.1 System Date [Day MM/DD/YYYY] Allows you to set the system date. 3.2.2 System Time [HH:MM:SS] Allows you to set the system time. H610T-EM-A...

  • Page 38: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.3.1 PCH-FW Configuration TPM Device Selection This item allows you to select the TPM device.

  • Page 39: Cpu Configuration

    When enabled, CPPC v2 interface allows hardware controlled P-state. Configuration options: [Disabled] [Enabled] Turbo Mode This item allows you to enable or disable Turbo Mode for your processor. Configuration options: [Enabled] [Disabled] C states [Enabled] Enables the CPU C states. [Disabled] Disables the CPU C states. H610T-EM-A...

  • Page 40: Power Management

    Enhanced C-states [Disabled] Disables enhanced C1 state. [Enabled] Enables enhanced C1 state. Power Limit 1 Override [Disabled] Disables power limit 1. [Enabled] Enables power limit 1. Power Limit 2 Override [Disabled] Disables power limit 2. [Enabled] Enables power limit 2. Power Limit 2 This item allows you to input the value of power limit 2 in milliwatts.

  • Page 41: Serial Console Redirection

    Long or noisy lines may require lower speeds. Configuration options: [9600] [19200] [38400] [57600] [115200] Data Bits Configuration options: [7] [8] Parity A parity bit can be sent with the data bits to detect some transmission errors. Configuration options: [None] [Even] [Odd] [Mark] [Space] H610T-EM-A...

  • Page 42: Sata Configuration

    [None] Disables parity check. [Even] Parity bit is 0 if the num of 1’s in the data bits is even. [Odd] Parity bit is 0 if the num of 1’s in the data bits is odd. [Mark] Parity bit is always 1. [Space] Parity bit is always 0.

  • Page 43: Network Stack Configuration

    Allows you to enable or disable USB Mass Storage Driver Support. Configuration options: [Disabled] [Enabled] U32G1_1~4, USB_5~8 Allows you to enable or disable USB ports. Once set to [Disabled], any USB devices plugged into the connector will not be detected by BIOS or OS. Configuration options: [Disabled] [Enabled] H610T-EM-A...

  • Page 44: Nvme Configuration

    3.3.10 NVMe Configuration The NVMe Configuration menu displays the NVMe controller and drive information of the devices connected and allows you to configure NVMe device options settings. 3.3.11 Onboard Devices Configuration HD Audio [Enabled] Enables the HD Audio Device. [Disabled] Disables the HD Audio Device. LAN1 I219V [Enabled] Enables the Intel...

  • Page 45: Ez-Flash

    Smart Fan Mode Allows you to select the smart fan mode. Configuration options: [Disabled] [Normal] [Manual Mode] The following item appears only when you set Smart Fan Mode to [Manual Mode]. H610T-EM-A 3-10...

  • Page 46: Security Menu

    Smart Fan Function System Fan Setting Chassis Fan Temperature 1(~4) Allows you to set the value of temperature1(~4). Chassis Fan FD/RPM 1(~4) Allows you to set the value of Fan Duty/PRM 1(~4) when temperature is T1(~4). CPU Fan Setting CPU Fan Temperature 1(~4) Allows you to set the value of temperature1(~4).

  • Page 47: Boot Menu

    Allows you to set the number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting. Configuration options: [1] - [65535] Post Time Delay This item allows you to select the desired additional POST waiting time to easily H610T-EM-A 3-12...

  • Page 48: Exit Menu

    enter the BIOS setup. (Delay time = value * 500ms). Configuration options: [0] - [12] Boot up NumLock State [On] Set the power-on state of the NumLock to [On]. [Off] Set the power-on state of the NumLock to [Off]. Quiet Boot Allows you to enable or disable the Quiet Boot option.
  • Page 49 Restore/load default values for all the setup options. Save as User Defaults This option allows you to save the changes you have made so far as user defaults. Restore User Defaults Restore the user defaults with all the setup options. H610T-EM-A 3-14...

  • Page 50: Appendix

    Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 51 : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-003(B)/NMB-003(B) VCCI: Japan Compliance Statement Class B ITE KC: Korea Warning Statement H610T-EM-A...
  • Page 52 ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
  • Page 53 Français AsusTek Computer Inc. déclare par la présente que cet appareil est conforme aux critères essentiels et autres clauses pertinentes des directives concernées. La déclaration de conformité de l’UE peut être téléchargée à partir du site Internet suivant : www.asus.com/support.

  • Page 54: Service And Support

    Service and Support Visit our multi-language website at https://www.asus.com/support/ Manufacturer ASUSTek COMPUTER INC. Address, City 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112 Authorized ASUS COMPUTER GmbH Representative in Europe Address Harkortstrasse 21-23, 40880 Ratingen Country Germany Authorized...
  • Page 55 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Augsburger Str. 2b 82110 Germering Phone: +49 89 894450-0 E-Mail: info@fortecag.de Internet: www.fortecag.de Fortec Group Members Austria FORTEC Integrated GmbH Office Vienna...
