- Page 1 PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 1 E22166_PRIME_H610I-PLUS_UM.indd 1 2023/8/8 14:39:15 2023/8/8 14:39:15...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Safety information ...................... iv About this guide ......................v Package contents ....................... vi PRIME H610I-PLUS specifications summary............vi Chapter 1: Product Introduction Before you proceed ..................1-1 Motherboard layout ..................1-2 Central Processing Unit (CPU) ..............1-8 System memory ..................1-10 Wi-Fi card installation ................ -
Page 4: Safety Information
Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. -
Page 5: About This Guide
Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. -
Page 6: Package Contents
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max ® ® Technology 3.0** * Refer to www.asus.com for CPU support list. ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. ® Chipset Intel H610 Chipset ®... - Page 7 PRIME H610I-PLUS specifications summary Rear USB (Total 4 ports) 2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 4 ports) 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports...
- Page 8 Form Factor 6.7 inch x 6.7 inch (17.0 cm x 17.0 cm) • Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications. • For more information on downloading and installing drivers and utilities for your...
-
Page 9: Chapter 1: Product Introduction
The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. • For more information on installing your motherboard, please scan the code below: PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 1 E22166_PRIME_H610I-PLUS_UM.indd 1 2023/8/8 14:39:16... -
Page 10: Motherboard Layout
Motherboard layout 17.0cm(6.7in) CHA_FAN CPU_OPT CPU_FAN KBMS_USB56 ATX_12V HDMI LGA1700 CLRTC COM_DEBUG M.2(WIFI) PCIE SATA SPI TPM 3.0 X4 M.2(SOCKET3) Super LAN_U32G1_34 Intel ® 128Mb BIOS H610 2280 2260 MONO_OUT AUDIO AAFP SMBUS Audio PCIEX16(G4) Codec Unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components. - Page 11 The USB 2.0 headers provide data transfer speeds of up to 480 Mb/s. PIN 1 DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 3 E22166_PRIME_H610I-PLUS_UM.indd 3 2023/8/8 14:39:16 2023/8/8 14:39:16...
- Page 12 10. Battery connector BATT_CON This connector is for the lithium CMOS battery. PIN 1 11. Clear CMOS header This header allows you to clear the CMOS RTC RAM data of the system setup CLRTC information such as date, time, and system passwords. To erase the RTC RAM: Turn OFF the computer and unplug the power cord.
- Page 13 (depending on the operating system settings). • Reset button header (RESET) The 2-pin header allows you to connect the chassis-mounted reset button. Press the reset button to reboot the system PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 5 E22166_PRIME_H610I-PLUS_UM.indd 5 2023/8/8 14:39:16 2023/8/8 14:39:16...
- Page 14 1.2.2 Rear panel connectors PS/2 Keyboard/Mouse combo port. This port is for a PS/2 keyboard or mouse. Ethernet port. This port allows Gigabit connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the Ethernet port LED indications. Ethernet port LED indications Activity Link LED Speed LED...
- Page 15 Side Speaker Out (Front panel) Pink (Front panel) To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 7 E22166_PRIME_H610I-PLUS_UM.indd 7 2023/8/8 14:39:16 2023/8/8 14:39:16...
-
Page 16: Central Processing Unit (Cpu)
CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user. Installing the CPU... - Page 17 PRIME H610I-PLUS E22166_PRIME_H610I-PLUS_UM.indd 9 E22166_PRIME_H610I-PLUS_UM.indd 9 2023/8/8 14:39:17 2023/8/8 14:39:17...
-
Page 18: System Memory
Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/. Recommended memory configurations DIMM_A... - Page 19 Installing a DIMM To remove a DIMM PRIME H610I-PLUS 1-11 E22166_PRIME_H610I-PLUS_UM.indd 11 E22166_PRIME_H610I-PLUS_UM.indd 11 2023/8/8 14:39:17 2023/8/8 14:39:17...
-
Page 20: Wi-Fi Card Installation
Wi-Fi card installation To assemble the Wi-Fi card module connect the IPEX Ensure to connector of the RF cable to the Wi-Fi card tightly Align the flat side of the RF connector to that of the hole in the M.2 Key E bracket, as shown in the illustration, then firmly push the connector into the hole. - Page 21 Remove the thin metal plate in the Wi-Fi hole of the I/O shield. • Install the Wi-Fi card module before installing your motherboard to the chassis. • The Wi-Fi card, RF cable and antenna are purchased separately. PRIME H610I-PLUS 1-13 E22166_PRIME_H610I-PLUS_UM.indd 13 E22166_PRIME_H610I-PLUS_UM.indd 13 2023/8/8 14:39:17...
- Page 22 1-14 Chapter 1: Product Introduction E22166_PRIME_H610I-PLUS_UM.indd 14 E22166_PRIME_H610I-PLUS_UM.indd 14 2023/8/8 14:39:17 2023/8/8 14:39:17...
-
Page 23: Chapter 2: Bios Information
BIOS Information Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system. -
Page 24: Bios Setup Program
BIOS Setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST). -
Page 25: Asus Ez Flash 3
ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>. -
Page 26: Asus Crashfree Bios 3
ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file. -
Page 27: Appendix
Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 28 France sorting and recycling information À DÉPOSER À DÉPOSER EN MAGASIN EN DÉCHÈTERIE Cet appareil et ses accessoires se recyclent Points de collecte sur www.quefairedemesdechets.fr Privilégiez la répara�on ou le don de votre appareil ! Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s).
- Page 29 ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
- Page 30 Français AsusTek Computer Inc. déclare par la présente que cet appareil est conforme aux critères essentiels et autres clauses pertinentes des directives concernées. La déclaration de conformité de l’UE peut être téléchargée à partir du site Internet suivant : www.asus.com/support.
-
Page 31: Warranty
• ASUS offers a voluntary manufacturer’s Commercial Guarantee. • ASUS dragovoljno nudi komercijalno proizvođačko jamstvo. • ASUS reserves the right to interpret the provisions of the ASUS • ASUS zadržava prava na tumačenje odredbi ASUS komercijalnog Commercial Guarantee. jamstva. •... - Page 32 • ASUS tilbyr som produsent en frivillig kommersiell garanti. • Bảo hành thương mại này của ASUS được cung cấp độc lập và ngoài • ASUS forbeholder seg retten til å tolke bestemmelsene i ASUS sin Bảo đảm pháp lý theo luật định và không có cách nào ảnh hưởng đến kommersielle garanti.
-
Page 33: Asus Contact Information
Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112 ASUS COMPUTER INTERNATIONAL (America) Address: 48720 Kato Rd., Fremont, CA 94538, USA ASUS COMPUTER GmbH (Germany and Austria) Address: Harkortstrasse 21-23, 40880 Ratingen, Germany ASUSTeK (UK) LIMITED Address: 1st Floor, Sackville House, 143-149 Fenchurch Street, London, EC3M 6BL,...
