- Page 1 Manual 1/4-Sheet 240 W orbital Power Sandpaper finishing Applies for: sander Code Model 102746 LIOR-1/4A3 LIOR-1/4A3 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Manual before Parts using the tool. Preparation Keep this manual for future references. Start up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Authorized Service Centers Warranty policy LIOR-1/4A3 ENGLISH... -
Page 3: Technical Data
Technical data LIOR-1/4A3 Code 102746 Description 1/4-Sheet Orbital Finishing Sander Base 4.3” x 4” Voltage 127 V Frequency 60 Hz Current Speed 14 000 OPM Power 240 W Dust collection Duty cycle 30 minutes work per 15 minutes idle. Maximum 3 hours per day. -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Finishing Sanders
Safety warnings for finishing sanders WARNING Cautions with dust and residues • Children and pregnant women must not enter the work area. CAUTION WARNING • Observe the applicable regulations • Remove the dust bag before sanding when sanding painted surfaces. Use special care when the metal, sparks can ignite the dust or even the bag. -
Page 6: Preparation
Preparation Selecting the sandpaper Grain Type 60 or lower very coarse • Select the right sander sheet grain. 80 - 100 coarse • Grains available vary from very coarse to very fine. 120 - 150 medium • Coarse grain is used to sand rough surfaces, medium grain for 180 - 220 fine light work and fine, for finishing purposes. -
Page 7: Start Up
Preparation Dust extraction The sander is equipped with a dust collection container and a dust extraction port. Installation of dust collection container • Align the canister against the guide in the dust extraction port then push it all the way into the port so it is secure. •... -
Page 8: Maintenance
Start up Sander operation • Turn on the sander before setting it on the work piece. • Keep the sander base parallel to the work piece surface. • Press down onto the work piece making circular movements and verifying the entire sander base is supported on the work piece. -
Page 9: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 10: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
