Summary of Contents for Truper LIBA-4X24N3
- Page 1 Manual Belt sander 1200 W 4”x 24” Power Sanding belt Applies for: Model Code LIBA-4X24N3 100370 LIBA-4X24N3 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Manual before Parts using the tool. Start up Keep this manual for future references. Maintenance The illustrations in this manual are for reference Authorized Service Centers only. They might be different from the real tool. Warranty policy LIBA-4X24N3 ENGLISH... -
Page 3: Technical Data
Technical data LIBA-4X24N3 Code 100370 Description Belt sander Belt 4” x 24” Voltage 127 V Frequency 60 Hz Current 9,4 A Power 1 200 W Speed 500 m/min Duty cycle 50 minutes work per 20 minutes idle. Maximum 6 hours per day. -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Belt Sander
Safety warnings for belt sanders Cautions with dust and residues Wear adequate clothing CAUTION WARNING • Observe the applicable regulations • Wear adequate clothes. Lose when sanding painted surfaces. Use special care when the clothes, jewelry or long hair could get caught in the paint is lead-based. -
Page 6: Start Up
Start up Belt set up • Pull the belt tension lever until it stops. • Choose the abrasive belt with the required grain and set it straight and centered around the rollers. Double check the arrow in the belt inner side points onto the same direction that the sander in the belt sander. - Page 7 Start up Sanding Metal finish • To prevent striation of the piece start sanding with the • To work on ferrous metal, like steel, stainless steel, iron, sander running. etc., use rough or fine grain belts, regarding the desired • Keep the sander moving to get a smooth and even job. finish.
-
Page 8: Maintenance
Maintenance Cleaning and care • Keep the motor housing ventilation slots clean and uncovered. • Apply compressed air after each use. • In case of malfunctioning go only to a Authorized Service Center Carbon brush replacement • Replace worn (burnt, broken or smaller than 0.19” long) carbon brushes. -
Page 9: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free number 800 690-6990 or 800 0187-8737 to get information about the nearest Authorized Service Center. -
Page 10: Warranty Policy
. For questions or comments, call 800 0187-8737 Imported by: Truper, S.A. de C.V. , Parque Industrial #1, Jilotepec, Edo. de Méx., Méx. C.P. 54240, Made in China Stamp of the business: Delivery date: www.truper.com...
