Bien Air MCX Instructions For Use Manual
Hide thumbs Also See for MCX:

Advertisement

Quick Links

HOSES
MCX & MCX c.l.
MCX-400 & MCX-400 c.l.
B-MCX
Do not sterilize
ENG
ENG INSTRUCTIONS FOR USE.
Other languages available on
https://dental.bienair.com/IFU
RX Only
REF 2100230-0004/2024-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCX and is the answer not in the manual?

Questions and answers

Summary of Contents for Bien Air MCX

  • Page 1 HOSES MCX & MCX c.l. MCX-400 & MCX-400 c.l. B-MCX Do not sterilize ENG INSTRUCTIONS FOR USE. Other languages available on https://dental.bienair.com/IFU RX Only REF 2100230-0004/2024-06...
  • Page 2 REF 1600756-001 REF 1600920-001 HOSE B-MCX GREY HOSE MCX 400 GREY REF 1600824-001 REF 1601081-001 HOSE MCX GREY 400° Ø20.2x40 TY MCX 400° gf. REF 1601096-001 REF 1601141-001 REF 2100230-0004/2024-06 HOSE MCX & MCX-400 & B-MCX • © Bien-Air Dental SA...
  • Page 3 Quick connector for Ø 18 mm hole. Length 60 O-ring 4 x 0.6 REF 705.01.77-010 REF 1600753-001 Spraynet®, cleaning spray 500 ml, box of 6 cans (BOX OF 6 CANS) REF 1600036-006 REF 2100230-0004/2024-06 HOSE MCX & MCX-400 & B-MCX • © Bien-Air Dental SA...
  • Page 4: Table Of Contents

    Table of content S S ymbols ymbols ............5 5 1.
  • Page 5: Ymbols

    ENG INSTRUCTIONS FOR USE 1 Symbols 1.1 Description of symbols used Description of symbols used S S ymbol ymbol Description Description S S ymbol ymbol Description Description Manufacturer. Catalogue number. Consult instructions for use or consult CE Marking with number of the electronic notified body.
  • Page 6: Ation & Intended Use

    Product intended for professional use only. Used by dentists and dental professionals. With rotating connector 2.5 Use En Use Envir vironment onment HOSE MCX GREY 400 Professional healthcare facility environment. With rotating connector, long cap 2.6 Intended medic Intended medical al B-MCX c c onditions...
  • Page 7: Electrical Safety

    3 User and Patient To prevent any risk of explosion, the warnings below Safety: Warnings and must be observed: Precautions for use WARNING According to IEC 60601-1:2005 +A1 2012 / This medical device must used AnnexG, electrified devices (motors, control units, professionals in compliance with the legal couplers and attachments), can be safely used provisions in force regarding occupational safety,...
  • Page 8: Description

    FIG. 1 . 1 4 Description 4.1 Ov Overview erview FIG. 1 (1) Motor connector (2) Sheath Note : Note : The original language of those instructions for use is English. For any further information, please contact Bien-Air Dental SA at the address given on the back cover.
  • Page 9: Assembly And Preparation

    FIG. 2 . 2 FIG. 3 . 3 4.2 Assembl Assembly and pr y and prepar eparation ation Pictogr Pictogram used am used Move fully to the stop, in the Move in the direction indicated. direction indicated. 1. 1. Connect the hose to the motor and fully screw the hose sleeve to the rear motor connection. FIG.
  • Page 10: Assembly

    FIG. 4 . 4 4.3 Assembl Assembly y FIG. 4 Preserve the initial alignment of the wires and tubes. Place the sheath (10) in the chucking zone FIG. The securing cord must be attached to the chassis of the unit or table-top device to avoid any traction on the wires and tubes FIG.
  • Page 11: Installing The Socket In The Unit

    4.4 Instal Installing the sock ling the socket in the unit et in the unit FIG. 5-6 • Drilling for the wall Ø 18 mm ± 0.2 • Machine a countersink for the catch FIG. • Tighten nut (150 Ncm maximum) •...
  • Page 12: Accessories

    4.5 A A c c c c essories essories For rotating connectors (± 200°), FIG. 7 & 8: O-ring connections REF 705.02.62-010 and 705.01.77-010. FIG. 8 . 8 FIG. 7 . 7 For bayonet connectors, FIG.9: O-ring connections REF 705.02.31-010 and 705.02.62-010. FIG.
  • Page 13: Technical Data

    Class IIa in accordance with the European Medical Regulation (EU) 2017/745. 4.8 P P erf erformanc ormances es No performances related to the hose alone. Refer to the IFU of the compatible micromotor MOT MCX (REF 1600751-001). 4.9 Oper Operating c...
  • Page 14: Maintenance And Servicing

    5 Maintenance and servicing 5.1 Maintenanc Maintenance – Gener e – General inf al information ormation CAUTION • Non-sterilizable. • Never submerge the hose in disinfectant solutions (the connectors should never be completely submerged). • Do not use an ultrasonic cleaner. 5.2 Cleaning Cleaning Clean with a clean cloth moistened with either tap water, sterile demineralized (deionized) water or any...
  • Page 15: Servicing

    5.6 Servicing Servicing Bien-Air Dental SA recommends that the user change the hose every two years. CAUTION Never disassemble the device. For any inquiry, contact your regular supplier or Bien-Air Dental service centre. 6 Transport & disposal 6.1 T T r r ansport ansport T T r r ansport conditions ansport conditions...
  • Page 16: Ormation

    Legend 1600756-001 MCX hose, grey silicone 1600854-001 MCX c.l. hose, long cap, grey silicone 1600824-001 B-MCX hose, grey silicone, bayonet connection to unit 1601081-001 MCX-400 hose, rotating, grey silicone 1601096-001 MCX-400 c.l. hose, rotating, long cap, grey silicone Quick connector on unit side only for Ø 18 mm hole, with rotation prevention notch. Standard...
  • Page 17 REF 2100230-0004/2024-06 HOSE MCX & MCX-400 & B-MCX • © Bien-Air Dental SA...
