Trotec BB20 Instructions Manual

Coating thickness meter
Hide thumbs Also See for BB20:

Advertisement

Quick Links

BB20
EN
INSTRUCTIONS
LAYER THICKNESS
MEASURING DEVICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BB20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trotec BB20

  • Page 1 BB20 INSTRUCTIONS LAYER THICKNESS MEASURING DEVICE...
  • Page 2: Table Of Contents

    • Do not swallow batteries! If a battery is swallowed, it can cause severe internal burns within 2 hours! These burns can lead to death! • If you think batteries might have been swallowed or otherwise entered the body, seek medical attention immediately! layer thickness measuring device BB20...
  • Page 3: Personnel Qualification

    Keep a sufficient distance from heat sources. Notice To prevent damages to the device, do not expose it to extreme temperatures, extreme humidity or moisture. Notice Do not use abrasive cleaners or solvents to clean the device. layer thickness measuring device BB20...
  • Page 4: Information About The Device

    (for coatings on ferromagnetic surfaces) or the eddy- current principle (for coatings on non-ferromagnetic surfaces). The BB20 is a compact and versatile device suitable for quick, precise and non-destructive measurements of coating NO=3 MAX=63 thicknesses.
  • Page 5: Technical Data

    114 x 27 x 54 mm height) Weight 152 g Scope of delivery • 1 x Layer thickness measuring device BB20 (without batteries) • 1 x Transport case • 1 x Steel and aluminium base plate with different film thicknesses for calibration • 1 x USB cable •...
  • Page 6: Transport And Storage

    Insert the batteries before first use. 1. Loosen the screw and open the battery compartment (6). 2. Insert the new batteries in the battery compartment with correct polarity. 3. Place the cover back on the battery compartment and reinsert the screw. layer thickness measuring device BB20...
  • Page 7 Automatic switch-off Activate (Enable) (Auto poweroff) Deactivate (Disable) Limit values Limit value settings Upper limit value (Limit) (Limit settings) (High limit) Lower limit value (Low limit) Delete limit value (Delete limit) Delete Current data All data Group data layer thickness measuring device BB20...
  • Page 8: Direct Mode

    If the memory space is full in single measurement mode, FULL appears on the display. If the memory space is full in direct mode, old measurements are replaced by new ones and statistics will be updated. layer thickness measuring device BB20...
  • Page 9 Please proceed as follows to select the statistic: 1. Open the Options menu. 2. Open the submenu LCD Statistic. 3. Select the desired statistic. ð The selected statistical value is indicated in the Statistics display (17), e.g. MAX=63 for the maximum value. layer thickness measuring device BB20...
  • Page 10 1. Carry out a zero-point calibration. 2. Using the first film, carry out a one-point calibration. 3. Using the second film, carry out a one-point calibration. layer thickness measuring device BB20...
  • Page 11: Pc Software

    The average thickness can be measurement data can be called up and saved via USB cable. determined as follows: The software is available for download at www.trotec.de. Method A 1. Carry out the one-point and two-point calibration as Info described above.
  • Page 12: Errors And Faults

    Repair Do not modify the device or install any spare parts. For repairs or device testing, contact the manufacturer. layer thickness measuring device BB20...
  • Page 13 Trotec GmbH Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
