SEC/SH/06/24/FM1 PARIS 5 DRAWER CHEST ASSEMBLY INSTRUCTIONS DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING. ASSEMBLE ON A SOFT CLEAN SURFACE.
SEC/SH/06/24/FM1 PART LIST Part Number Part Code Carton Part Description Quantity S100-102-195-FM1-01 Side Panel (Le ) S100-102-195-FM1-02 Side Panel (Right) S100-102-195-FM1-03 Drawer Front Panel S100-102-195-FM1-04 Drawer Side Panel (Le ) Drawer Side Panel (Right) S100-102-195-FM1-05 Top Panel S100-102-195-FM1-06 Crossbar Panel S100-102-195-FM1-07 Bo om Crossbar S100-102-195-FM1-08...
SEC/SH/06/24/FM1 HARDWARE LIST Part Name Carton Wooden Dowel 8 x 25mm Plastic Foot Nail x10 Sets Mini Fix 15mm Plastic Support Screw M3.5mm x 14mm Screw M4 x 38mm FH Screw M5 x 40mm x5 Sets Drawer Metal Slide 350mm Wall Fittings TIPS FOR FITTINGS CAM-LOCKS WHEN FITTING CAM NUT.
Page 4
SEC/SH/06/24/FM1 STEP 1 PARTS REQUIRED TOP PANEL CROSSBAR PANEL BOTTOM CROSSBAR HARDWARE REQUIRED 8x25mm TOOLS REQUIRED To Assemble the Drawer Slide, Please Follow Step as Below STEP 2 4th to Last Hole First Hole PARTS REQUIRED BACK FRONT SIDE PANEL (LEFT) HARDWARE REQUIRED TOOLS REQUIRED Page 04...
SEC/SH/06/24/FM1 To Assemble the Drawer Slide, Please Follow Step as Below STEP 3 4th to Last Hole First Hole PARTS REQUIRED FRONT BACK SIDE PANEL (RIGHT) HARDWARE REQUIRED TOOLS REQUIRED STEP 4 PARTS REQUIRED SIDE PANEL (RIGHT) TOP PANEL CROSSBAR PANEL BOTTOM CROSSBAR HARDWARE REQUIRED TOOLS REQUIRED...
