Section 4 - Troubleshooting

APPLICATION RULES

Some applications require that specific ports in the Router's firewall be opened for access by the remote parties. Application rules dynamically open
up the Open Start/End ports when an application on the LAN initiates a TCP/UDP connection to a remote party using the Trigger Start/End ports.
The router allows the remote party from the WAN side to establish new connections back to the application on the LAN side using the Open
Start/End ports. A maximum of 32 entries can be configured.
To access the APPLICATION RULES setting window, click on the Application Rules button in the ADVANCED directory.
D-Link DSL-2641B User Manual 39
