(1) Align the screw holes in the base, and tighten the two cross-recessed
pan-head screws on the edge of the transparent dome housing to fix it,
as shown by  in the following figure.
(2) Align the grooves (non-tail cable grooves) of the transparent dome
housing to the buckle of the base, and push up the dome housing to fix
it, as shown by  in the following figure.
NOTE!
The preceding installation process is concealed installation, during which holes

are drilled in the ceiling and tail cable is led out from the top of the camera.
Cables are connected and frapped at the ceiling side to prevent messy cables
from affecting camera mounting. If open installation is adopted, tail cable is led
out from one side of the camera and can be routed from the side groove of the
camera.
After mounting the dome housing, check that the two cross-recessed pan-head

screws on the edge of the dome housing are tightened up to ensure that the
camera is properly sealed. For details, see Mount the transparent dome housing.
3 Connect the Kit
The following part shows an example. The actual device may vary.
1.
Connect the NVR to a monitor with a VGA or HDMI cable (not included in the kit).
2.
Plug a mouse into the USB interface on the NVR.
3.
Connect the NVR and the camera to power.
1
Base buckle
Groove
2
4
