- Page 1 Wi-Fi Kit Quick Guide V1.00...
-
Page 2: Install Device
Default IP, Username and Password IP address: 192.168.1.30 NOTE! For security, you are strongly recommended 192.168.1.13 to set a strong password of at least nine characters including all three elements: Username: admin digits, letters and special characters. Password: 123456 Install Device The illustrations are for reference only. -
Page 3: Install The Camera
2.2 (Optional) Install SD Card Insert a SD card into the slot to use the local storage function. For detailed specifications of recommended SD cards, contact your dealer or technical support. Hot plugging is not recommended. Micro SD card slot 2.3 Install the Camera You can adopt ceiling mount or wall mount and purchase hardware accessories by yourself. - Page 4 on the ceiling by using a screwdriver. 5. Adjust the monitoring direction of the lens (tighten screws after vertically adjusting the lens). The lens can horizontally turn by rotating the lens base, as shown by in the following figure. After loosening the fastening screws, you can vertically turn the lens, as shown by ...
- Page 5 (1) Align the screw holes in the base, and tighten the two cross-recessed pan-head screws on the edge of the transparent dome housing to fix it, as shown by in the following figure. (2) Align the grooves (non-tail cable grooves) of the transparent dome housing to the buckle of the base, and push up the dome housing to fix it, as shown by ...
-
Page 6: Startup And Shutdown
Figure 3-1 NVR Interfaces Monitor Monitor Antenna Antenna interface HDMI interface Audio Power Network output supply interface IP Network E.g.,loudspeaker Mouse Figure 3-2 IPC Interfaces Network interface Power interface Device Operation 4.1 Startup and Shutdown Make sure the cables are connected correctly and the device is grounded properly. Use a power supply that meets requirements. - Page 7 4.1.2 Shutdown Click > Shutdown on the screen toolbar in live view page. CAUTION! Do not disconnect power when the NVR is operating or shutting down. 4.2 Wi-Fi Configuration The camera will get online and start live view on the NVR once the NVR and camera are connected to power.
- Page 8 CAUTION! The NVR's wireless NIC IP must be in a different network segment with its LAN IP address. Click Apply. NOTE! After SSID or password are changed on the NVR, the new SSID or password will be synchronized to online cameras. For offline cameras, the changed settings cannot be synchronized, and you need to pair the camera with the NVR again.
- Page 9 NOTE! This function works within 3 minutes after the camera restores defaults. So, if the camera is not paired successfully within this time, please restart the camera or try other methods. Wait for the camera to get online. QR Code Pair Connect the camera to power.
-
Page 10: Add Devices
6.1 Sign Up an Account in the upper right corner and choose International service area. Tap Sign Up and follow the steps to complete sign up. 6.2 Add Devices After logging in to your account, tap > Devices > Add, then select a way to add devices. - Page 11 6.4 Share Devices > Devices, select the desired device and tap Share, then complete the sharing settings. You may also share the device by generating a QR code. 6.5 Pair Camera and NVR Connect the camera to power, and connect your mobile phone to NVR’s Wi-Fi network.
-
Page 12: Web Login
Web Login Before you begin, check that your PC is connected to your NVR through network. Open the browser on your PC, enter the IP address in the address bar, then press Enter. Install the plugin as required at first login. Close your browser during the installation. -
Page 13: Copyright Statement
The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form by any means. - Page 14 To the extent allowed by applicable law, in no event shall Uniview’s total liability to you for all damages for the product described in this manual (other than as may be required by applicable law in cases involving personal injury) exceed the amount of money that you have paid for the product.
- Page 15 Keep firmware up to date: It is recommended that your device is always upgraded to the latest version for the latest functions and better security. Visit Uniview's official website or contact your local dealer for the latest firmware.
- Page 16 Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
-
Page 17: Regulatory Compliance
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Visit http://en.uniview.com/Support/Download_Center/Product_Installation/Declaration/ for SDoC Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 18 —Consult the dealer or an experienced radio/TV technician for help. RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body.
