NuTiny-SDK-NUC029LAN User Manual
NuTiny-SDK-NUC029LAN User Manual
for NuMicro™ NUC029xAN Series
The information described in this document is the exclusive intellectual property of
Nuvoton Technology Corporation and shall not be reproduced without permission from Nuvoton.
™
Nuvoton is providing this document only for reference purposes of NuMicro
microcontroller based system design.
Nuvoton assumes no responsibility for errors or omissions.
All data and specifications are subject to change without notice.
For additional information or questions, please contact: Nuvoton Technology Corporation.
Dec. 24, 2014
Rev. 1.01
Advertisement
Related Manuals for Nuvoton NuTiny-SDK-NUC029LAN
Summary of Contents for Nuvoton NuTiny-SDK-NUC029LAN
- Page 1 NuMicro™ NUC029xAN Series The information described in this document is the exclusive intellectual property of Nuvoton Technology Corporation and shall not be reproduced without permission from Nuvoton. ™ Nuvoton is providing this document only for reference purposes of NuMicro microcontroller based system design.
-
Page 2: Table Of Contents
Downloading and Installing Nuvoton Nu-Link Driver ........7 Hardware Setup ..................7 Example Program ..................8 Starting to Use NuTiny-SDK-NUC029LAN on the IAR Embedded Workbench9 Downloading and Installing IAR Embedded Workbench Software ...... 9 Downloading and Installing Nuvoton Nu-Link Driver ........9 Hardware Setup .................. -
Page 3: Overview
(via Serial Wired Debug Port) and allows you to program and debug embedded programs on the target hardware. To use the Nu-Link-Me Debug adaptor with Keil or IAR, please refer to “Nuvoton NuMicro™ IAR ICE Driver User Manual” or Nuvoton NuMicro™ Keil ICE Driver User Manual” for details. -
Page 4: Nutiny-Sdk-Nuc029Lan Jumper Description
NuTiny-SDK-NUC029LAN User Manual NuTiny-SDK-NUC029LAN Jumper Description 2.1.1 Power Settings JP2: VDD Voltage connecter in NuTiny-EVB-NUC029LAN ICEJ2: USB port in Nu-Link-Me ICEJ2 USB Model JP2 VDD MCU Voltage port Select VCC33 Model 1 Connect to PC DC 3.3V output DC 3.3V... -
Page 5: Pin Assignment For Extended Connectors
NuTiny-SDK-NUC029LAN User Manual Pin Assignment for Extended Connectors The NuTiny-EVB-NUC029LAN provides the NUC029LAN target chip on board and the extended connectors (JP1, JP5, JP6 and JP7) for LQFP48-pin. The following table is the pin assignment for NUC029LAN. Pin No Pin Name... -
Page 6: Nutiny-Sdk-Nuc029Lan Pcb Placement
NuTiny-SDK-NUC029LAN User Manual NuTiny-SDK-NUC029LAN PCB Placement The following figure shows the NuTiny-SDK-NUC029LAN PCB placement. Figure 2-2 NuTiny-SDK-NUC029LAN PCB Placement Dec. 24, 2014 6 of 21 Rev. 1.01... -
Page 7: Starting To Use Nutiny-Sdk-Nuc029Lan On The Keil Μvision
NuTiny-SDK-NUC029LAN User Manual 3 Starting to Use NuTiny-SDK-NUC029LAN on the Keil μVision ® Downloading and Installing Keil μVision ® IDE Software Please connect to the Keil company website (http://www.keil.com) to download the ® Keil μVision IDE and install the RVMDK. -
Page 8: Example Program
NuTiny-SDK-NUC029LAN User Manual Example Program This example demonstrates how to download and debug an application on a NuTiny- SDK-NUC029LAN board. The example file can be found in the directory list shown in the following figure. Directory Figure 3-2 Example Directory To use this example: The I/O LED on the NuTiny-EVB-NUC029LAN board will turn on. -
Page 9: Starting To Use Nutiny-Sdk-Nuc029Lan On The Iar Embedded Workbench9
NuTiny-SDK-NUC029LAN User Manual 4 Starting to Use NuTiny-SDK-NUC029LAN on the IAR Embedded Workbench Downloading and Installing IAR Embedded Workbench Software Please connect to IAR company website (http://www.iar.com) to download the IAR Embedded Workbench and install the EWARM. Downloading and Installing Nuvoton Nu-Link Driver ™... -
Page 10: Example Program
NuTiny-SDK-NUC029LAN User Manual Example Program This example demonstrates how to download and debug an application on a NuTiny- SDK-NUC029LAN board. The example file can be found in the directory list shown in the following figure. Directory Figure 4-2 Example Directory To use this example: The I/O LED on the NuTiny-EVB-NUC029LAN board will turn on. -
Page 11: Nutiny-Sdk-Nuc029Lan Schematics
NuTiny-SDK-NUC029LAN User Manual 5 NuTiny-SDK-NUC029LAN Schematics NuTiny-EVB-NUC029LAN Schematic VCC5 0603R PUSH BOTTOM VCC5 DAVDD TICERST 10uF/10V TICEVCC TICEVCC TICEDAT TANT-A TICEDAT TICECLK 0.1u 0.1u TICECLK TICERST TICERST 0603C 0603C HEADER 6X2 HEADER6X2 Reset Circuit ADAVSS From ICE Bridge's USB Power... -
Page 12: Nu-Link-Me Schematic
NuTiny-SDK-NUC029LAN User Manual Nu-Link-Me Schematic VCC5 VCC5 VCC33 AVDD iceD4 SS24A iceL4 iNET1 iceD2 USBVBUS L0603 iceD3 RTIDA1 RICK1 SS24A RB060L 100K 100K SS24A RB060L HEADER 5 RB060L 0603R 0603R iceJP8 iNET7 TICEVCC iNET8 TICEVCC VCC33 RT9164A-3.3v 3-W JUMP ICE_DAT... -
Page 13: Downloading Numicro™ Keil Μvision ® Ide Driver
NuTiny-SDK-NUC029LAN User Manual Downloading NuMicro™ Related Files from Nuvoton Website Downloading NuMicro™ Keil μVision ® IDE Driver ™ Visit the Nuvoton NuMicro website: http://www.nuvoton.com/NuMicro. Step1 2-1. Move to “Support” 2-2. Click here to enter Tool & Software Step2 Dec. 24, 2014 13 of 21 Rev. - Page 14 NuTiny-SDK-NUC029LAN User Manual Click here to enter Software download page Step3 Dec. 24, 2014 14 of 21 Rev. 1.01...
- Page 15 NuTiny-SDK-NUC029LAN User Manual Click here to download the file. Step4 ™ ® Keil μVision Step5 Download the NuMicro IDE driver. Dec. 24, 2014 15 of 21 Rev. 1.01...
-
Page 16: Downloading Numicro™ Iar Ewarm Driver
NuTiny-SDK-NUC029LAN User Manual Downloading NuMicro™ IAR EWARM Driver ™ Visit the Nuvoton NuMicro website: http://www.nuvoton.com/NuMicro. Step1 2-1. Move to “Support” 2-2. Click here to enter Tool & Software Step2 Dec. 24, 2014 16 of 21 Rev. 1.01... - Page 17 NuTiny-SDK-NUC029LAN User Manual Click here to enter Software download page Step3 Dec. 24, 2014 17 of 21 Rev. 1.01...
- Page 18 NuTiny-SDK-NUC029LAN User Manual Click here to Step4 download the file. ™ Step5 Download the NuMicro IAR EWARM driver. Dec. 24, 2014 18 of 21 Rev. 1.01...
-
Page 19: Downloading Numicro™ Nuc029Xan Series Bsp Software Library
NuTiny-SDK-NUC029LAN User Manual Downloading NuMicro™ NUC029xAN Series BSP Software Library ™ Visit the Nuvoton NuMicro website: http://www.nuvoton.com/NuMicro. Step1 2-1. Move to “Support” 2-2. Click here to enter Tool & Software Step2 Dec. 24, 2014 19 of 21 Rev. 1.01... - Page 20 NuTiny-SDK-NUC029LAN User Manual Click here to enter Software download page Step3 ™ Step4 Download the NuMicro NUC029xAN Series CMSIS BSP. Dec. 24, 2014 20 of 21 Rev. 1.01...
-
Page 21: Revision History
Series BSP Software Library Step4. Important Notice Nuvoton Products are neither intended nor warranted for usage in systems or equipment, any malfunction or failure of which may cause loss of human life, bodily injury or severe property damage. Such applications are deemed, “Insecure Usage”.
