VIEWING IMAGES ON A COMPUTER
3.
Connect the USB cable that comes bundled
with the camera to the USB cradle and your
computer's USB port.
USB port
Connector A
• Take care when connecting the USB cable to the
USB cradle or your computer. USB ports and cable
plugs are shaped for proper positioning.
• Plug the USB cable plugs into the ports securely, as
far as they will go. Proper operation is not possible if
connections are not correct.
USB cable
Connector B
(bundled)
[USB]
4.
After making sure the camera is turned off,
place the camera onto the USB cradle.
• Do not place the camera onto the USB cradle while it
is turned on.
138
[USB] button
[USB] lamp
