Sena 30K Manual

Motorcycle bluetooth communication system with mesh intercom
Hide thumbs Also See for 30K:

Advertisement

Quick Links

Download this manual
30K
MOTORCYCLE BLUETOOTH
®
COMMUNICATION SYSTEM
WITH MESH INTERCOM™
3.2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the 30K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sena 30K

Summary of Contents for Sena 30K

  • Page 1 MOTORCYCLE BLUETOOTH ® COMMUNICATION SYSTEM WITH MESH INTERCOM™ 3.2.0...
  • Page 2 The 30K features Sena’s Mesh Intercom technology allowing your group to seamlessly communicate, even if a rider falls out of range. With more connections and Mesh Intercom™ technology, the 30K is the next generation of communication. Mesh Intercom™ up to 2 km Bluetooth ®...

  • Page 3: Getting Started

    Visit sena.com to see how to update your product. 3. Users can follow Sena on Facebook, YouTube, Twitter and Instagram to receive the most up to date information on products, helpful tips and all other announcements regarding Sena products.

  • Page 4: How To Use This Guide

    GETTING STARTED How to Use This Guide The legend and callouts are here to help you read the illustrations. New technology can be confusing, but we’ve created a simple way to perform actions using illustrations. HOLD Function Button(s) to Tap or Hold Buttons Mesh Intercom Button Phone Button...

  • Page 5: Icon Legend

    GETTING STARTED Icon Legend button/Jog Dial Press and Hold button/ HOLD the specifi ed number Jog Dial for the specifi ed of times amount of time Rotate Jog Dial clockwise (right) or ROTATE ROTATE ROTATE counterclockwise (left). Rotate while Pressing Jog Dial ROTATE ROTATE...

  • Page 6: Product Details

    QUICK START GUIDE Product Details Mesh Intercom Antenna Mesh Intercom Button Status LED Bluetooth Antenna Phone Button Jog Dial Ambient Mode Button DC Power Charging & Firmware Upgrade Port QUICK START GUIDE...

  • Page 7: Installation

    QUICK START GUIDE Installation Mesh Intercom Antenna Pull the Mesh Intercom Antenna outwards slightly to unfold it.

  • Page 8: Sena Device Manager

    Store Store. Sena Motorcycles • Device configuration setting Sena Device Manager The Sena Device Manager allows you to upgrade the firmware and configure its settings directly from your PC or Apple computer. Download the Sena Device Manager from sena.com. NOTICE •...

  • Page 9: Basic Operations

    QUICK START GUIDE Basic Operations Powering On Powering Off HOLD POWER POWER Volume Up Volume Down ROTATE ROTATE VOLUME VOLUME DOWN Checking the Battery Level Instruction is for when powering the headset on. Visual Method HOLD VISUAL METHOD HIGH...

  • Page 10: Phone Pairing

    QUICK START GUIDE Phone Pairing Blinking HOLD “Phone pairing” 2. Select 30K in the list of Bluetooth devices detected. Bluetooth Device B • The headset will enter the Phone Pairing mode automatically when you initially turn on the headset. • For more information on phone pairing, refer to the...

  • Page 11: Mobile Phone

    QUICK START GUIDE Mobile Phone Answer a Call Reject a call HOLD REJECT ANSWER End a Call Call a Voice Assistant stand-by mode HOLD Music Controls Play/Pause Track forward HOLD ROTATE Track backward “[Beep, Beep]” ROTATE...

  • Page 12: Mesh Intercom

    QUICK START GUIDE Mesh Intercom™ When Mesh Intercom is enabled, the 30K will automatically connect to nearby 30K users and allow them to talk to each other. Mesh Intercom On Mesh Intercom Off “Mesh intercom on” “Mesh intercom off” Note: Open Mesh and Group Mesh cannot communicate with the previous modes Public Mode and Private Mode.
  • Page 13 QUICK START GUIDE Open Mesh™ When Mesh Intercom is enabled, the headset will be in Open Mesh (default: channel 1) initially. Users can freely communicate with each other in the same Open Mesh channel. Channel Setting (Default: channel 1) If the Open Mesh communication experiences interference because other groups are also using channel 1 (default), change the channel.
  • Page 14 QUICK START GUIDE Enter into the Channel Setting “Channel setting, 1” Navigate between Channels ••• Exit •••) ROTATE ROTATE “#” Save the Channel “Channel is set, channel #” Note: To exit the Channel Setting, rotate the Jog Dial clockwise or counterclockwise until you hear a voice prompt, “Exit”, and tap the Jog Dial.
  • Page 15 QUICK START GUIDE Group Mesh™ Group Mesh is a closed group intercom function that allows users to join, leave, or rejoin a group intercom conversation without pairing each headset. Up to 24 users can all be connected in each private group. Creating a Group Mesh Creating a Group Mesh requires two or more Open Mesh users.
  • Page 16 QUICK START GUIDE 2. The headsets complete Mesh Grouping and automatically switch from Open Mesh to Group Mesh. “Group Mesh” Open Mesh Group Mesh Joining an Existing Group Mesh One of the members in an Existing Group Mesh can allow new members in Open Mesh to join the Existing Group Mesh.
  • Page 17 QUICK START GUIDE 1. One of the current members and a new member enter into Mesh Grouping to join the Existing Group Mesh. (NEW MEMBER) HOLD CURRENT MEMBER IN GROUP MESH “Mesh grouping” 2. The headsets complete Mesh Grouping. The new members will hear a voice prompt as their headsets automatically switch from Open Mesh to Group Mesh.
  • Page 18 Mesh Intercom to nearby friends who have it turned off. 1. If you want to send or receive a request massage, you need to enable Mesh Reach-Out on the Sena Motorcycles App. 2. While your headset’s Mesh Intercom is on, you (caller) send a request message using the headset’s Button or...

  • Page 19: Bluetooth Intercom

    There are two ways to pair the headset. Using the Smart Intercom Pairing (SIP) SIP allows you to quickly pair with your friends for intercom communication by scanning the QR code on the Sena Motorcycles App without remembering the button operation.
  • Page 20 (B) is paired with you (A) correctly. 5. Tap Scan ) and repeat steps 3-4 to pair with Intercom Friends (C) and (D). Note: The Smart Intercom Pairing (SIP) is not compatible with Sena products that use Bluetooth 3.0 or below.
  • Page 21 QUICK START GUIDE Using the Button 1. The users (You, B) enter into Intercom Pairing. Blinking HOLD “Intercom pairing” Turns blue 2. The users’ headsets will be automatically paired. 3. Repeat the steps above to pair with other headsets (C and D).

  • Page 22: Two-Way Intercom

    QUICK START GUIDE Two-Way Intercom Last-Come, First-Served Start/End with Intercom Friend 1 Intercom Friend 1 Start/End with Intercom Friend 2 Intercom Intercom Friend 1 Friend 2 Start/End with Intercom Intercom Intercom Intercom Friend 3 Friend 1 Friend 2 Friend 3...

  • Page 23: Ambient Mode

    QUICK START GUIDE Ambient Mode START AMBIENT MODE Configuration Menu Accessing the Navigating Between Confi guration Menu Menu Options HOLD ROTATE CONFIG. NAVIGATE MENU FORWARD “Confi guration menu” “[Menu prompt]” Enable or Execute Menu ROTATE Options NAVIGATE BACKWARD “[Menu prompt]” EXECUTE...

  • Page 24: Troubleshooting

    QUICK START GUIDE Troubleshooting Factory Reset Fault Reset HOLD “Factory reset” Note: Fault Reset will not restore the Bluetooth module to factory default Solid red settings. STATUS within EXECUTE...

  • Page 25: Quick Reference

    QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD Power on/ Power off Volume up/ ROTATE ROTATE Basic Volume down Operations Ambient Mode Answer phone call End phone call HOLD Reject phone call Call transfer while HOLD Mobile on the phone Phone Call a Voice Assistant Speed dial QUICK REFERENCE...
  • Page 26 QUICK REFERENCE TYPE OPERATION BUTTON COMMANDS HOLD Play/Pause music ROTATE Track forward Music ROTATE Track backward Mesh intercom on/off Channel setting HOLD Mesh Grouping Mesh HOLD Intercom™ Enable/Disable Mic Mesh Reach-Out Request HOLD Reset Mesh HOLD Intercom pairing Start/End intercom Intercom...
