- Page 1 Installation and Maintenance Manual STG 120-2 S1L 95 LME11.230C2E MB-DLE 403 Translation of the original instructions. Keep for future use. Read carefully before use. 178 036 25-8 CR00861 2024-05-07...
- Page 2 1~230V 1,0A 50Hz IP 20 Motor supply MADE IN SWEDEN BY 1. Manualer på övriga språk 1. Manuals in other languages 1. Manualer på andre sprog 2. www.bentone.com\nedladdning eller 2. www.bentone.com\download 2. www.bentone.com\download eller scanna QR-koden. or scan QR-code. scan QR-koden.
-
Page 3: Table Of Contents
BENTONE Table of contents General Information ............5 Settings ................21 Delivery inspection................ 5 Air setting ..................21 Safety ....................5 Nozzle assembly adjustment ............ 21 What to do if you smell gas ............6 Startup ................... 22 Control of combustion .............. 22 Technical data ...............7... -
Page 5: General Information
BENTONE General Information The burner may only be used for its intended purpose in accordance with the product’s technical data. We reserve the right to make design changes and cannot be held liable for any misprints or typographical errors. Modifying the design or using accessories or components that have not been approved by CTC in writing is strictly prohibited. -
Page 6: What To Do If You Smell Gas
BENTONE • Care must be taken by the installer to ensure that no electrical cables or fuel lines are pinched or otherwise damaged during installation or service. Sharp edges can occur on, for example: flame tube, fan wheel and air •... -
Page 7: Technical Data
BENTONE Technical data The burner is intended for: • Operation in installations according to EN 303 and EN 676. Fuels: • Natural gas H, E, L, LL. • LPG, Butane and Propane. Dimensions STG 120/2 ø B Flame tube Flame tube... -
Page 8: Capacity Range
BENTONE 2.1.1 Measurements for connection to the boiler Flange 1 Ø 90 Ø 125-150 Flange 2 Ø 90 Ø 125-150 Flange 1 Flange 2 Capacity range Max. connection Capacity Gas quantity Gas quantity Min. connection Gas valve at min. power at max. -
Page 9: Technical Specification
BENTONE Technical specification STG 120/2 Main supply 230V, 1~, 1.2A, 50/60Hz, IP20 Max fuse rating 6.3A -class Noise level 74dBA Max operating current, see data plate. Measurements according to EN 15036-1:2006 Alt.1 The noise level of the burner can be reduced by equipping the burner with silencer. -
Page 10: Components
BENTONE Components Reset button Flame tube Air settings Burner control Ignition electrode Nozzle assembly adjustment Transformer Air damper Motor Fixing flange Fan housing, front Electrical connection Connection, gas valve Fan housing, rear Gas valve (MultiBloc) Ionisation electrode Air pressure switch... -
Page 11: Skeleton Diagram
BENTONE Skeleton diagram Ball valve Filter Pressure regulator Pressure gauge with shut-off cock Gas pressure switch, min Gas pressure switch, max Main valve Safety valve Leakage control Air pressure switch Electrical connection Pos. 5b, 7: Components not required according to EN 676. -
Page 12: Electric Equipment
BENTONE Electric equipment Safety system The safety system (safety switch for hatches, doors, water level, pressure, temperature and other safety devices) must be installed in the safety circuit in accordance with current regulations for the system. The cables of the safety system must be separated so that the outgoing signal is not placed in the same cable as the incoming signal. -
Page 13: Function Lme
BENTONE 3.2.1 Components Burner control Air pressure switch Power control Gas pressure switch Ionization electrode Ignition transformer Operating fuse Connection terminal board Operating lamp Earth terminal Motor Solenoid valve 1 Control thermostat Function LME... Operating switch ON-Thermostat ON-Gas pressure switch ON... - Page 14 BENTONE 3.3.2 Control program at faults; fault mode indicator LME ..Colour codes Table colour codes for multi-coloured signal light (LED) Status Colour codes Colours ○………………… Waiting period «tw», other waiting periods ●○●○●○●○●○● Ignition phase, ignition controlled Blinking yellow □…………………...
- Page 15 BENTONE Alarm code table Red blinking code on Possible causes signal lamp (LED) Blinking 2 x No flame creation at End of “TSA” – defective or fouled flame monitoring. •• – defective or fouled fuel valves. – poor burner setting.
-
Page 16: Installation
BENTONE Installation General instructions Installation must be carried out in accordance with current regulations and instructions. The supplier/installer of the facility is obliged to familiarize himself with all regulations so that the installation meets the requirements of the local authorities. -
Page 17: Mounting
BENTONE Mounting The burner is mounted on the boiler with bolts according to the hole pattern on the fixing flange. Mount the fixing flange and the supplied gasket on the boiler. If new mounting holes must be drilled, use the fixing flange as a template and fasten with M8-M10 screws. -
Page 18: Gas Nozzle
BENTONE Gas nozzle Check that the ignition and ionization electrodes are correctly set before mounting on the boiler. Natural gas, LPG Natural gas... -
Page 19: Aerating
BENTONE De-aerating De-aerating the gas line by closing the tap to the gas connection and unscrewing the screw on the measuring nipple for the connection pressure. Connect a plastic hose, open the tap and drain the gas in a safe place. When the de-aerating is completed, be sure to refit the screw on the measuring nipple. -
Page 20: Calculation Of Gas Flow
BENTONE Calculation of gas flow Formula symbol Example values Description Standard gas volume [Nm3/h] Gas volume at normal condition 15 °C 1013 mbar Boiler output [kW] 35 kW Lower calorific value of gas [kWh/m 9.45 kWh/m Natural gas under normal conditions 15 °C 1013 mbar, EN 676 η... -
Page 21: Settings
BENTONE Settings Air setting Prior to commissioning, adjust the burner setting for air damper according to diagram, see Technical data. After the first start, the burner must be adjusted again for good function and combustion. Nozzle assembly adjustment The burner is equipped with a nozzle assembly adjustment that changes the position of the nozzle assembly in the burner head. -
Page 22: Startup
BENTONE Startup After the burner has been mounted on the boiler and the electrical connection, de-aeration and tightness control have been performed, the burner is ready to start-up. Read the sections dealing with settings of gas valve, damper motor and combustion device before start-up. -
Page 23: Setting The Air Pressure Switch
BENTONE Setting the air pressure switch The air pressure switch must block the burner if the amount of air for combustion becomes too low. The air pressure switch must be set so that in the event of a lack of air supply at the burner’s max. or min. capacity reacts before the monitored pressure drops so much that poor combustion occurs. -
Page 24: Setting The Gas Pressure Switch, Min
BENTONE Setting the gas pressure switch, min. The gas pressure switch must react to too low a connection pressure to the burner, prevent the burner from starting and stop the burner during operation. The burner may start again when the connection pressure has risen above the set pressure on the gas pressure switch. -
Page 25: Gas Valve Multibloc Dle 403
BENTONE Gas valve MultiBloc DLE 403 Max. inlet pressure: 200 mbar Adjustable governor pressure: 4-50 mbar. Solenoid valve: Slow opening valves with adjustable start load and max. flow. All gasline components shall be assembled and mounted without bending, torque and outher mechanical or thermal stress. - Page 26 BENTONE Flow adjustment Loosen the fixing screw (a), turn the hydraulic device (b): to the right = the gas flow is reduced • to the left = the gas flow is increased • Do not forget to tighten the fixing screw.
-
Page 27: Service
BENTONE Service Service and maintenance work may only be performed by qualified personnel. Perform operational check of all safety systems and components at each service. Only CTC original parts should be used when replacing components. Use caution when operating the burner, surfaces may be hot. -
Page 28: Combustion Device
BENTONE Combustion device Disconnect the main power and shut off the fuel supply. Before obtaining access to electrical and fuel line components all supply circuits must be disconnected. Remove gas line by loosening the electrical cabling and screws (G) to the gas valve and lift out. -
Page 29: Fan Motor And Fan Wheel
BENTONE Fan motor and fan wheel Disconnect the main power and shut off the fuel supply. Before obtaining access to electrical and fuel line components all supply circuits must be disconnected. Disconnect electrical connection to the motor. Loosen screws on the motor flange and lift out the motor. -
Page 30: Air Intake And Suction Cone
BENTONE Air intake and suction cone Disconnect the main power and shut off the fuel supply. Before obtaining access to electrical and fuel line components all supply circuits must be disconnected. Remove gas line by loosening the electrical cabling and screws to the gas valve and lift out. -
Page 31: Replacement Of Electrical Components
BENTONE Replacement of electrical components Disconnect the main power and switch off the fuel supply. Before obtaining access to terminals, all supply circuits must be disconnected. Note the connection of the existing component and disassemble. Fit new component with same connection or with specified alternative connection. -
Page 32: Vibrations
BENTONE Vibrations Maximum permitted vibration level is 5.0 mm/s. • Check tightness of fasteners. • Check fan wheel for damage and contamination (replace if necessary). • Check motor shaft and bearings. If they are worn, replace the motor. Use screw to attach the... -
Page 33: Control Of Flame Monitoring And Ionization Current
BENTONE Control of flame monitoring and ionization current The burner is monitored in the standard version according to the ionization principle. The ionization current must be checked at each service occasion. The ionization current is measured with a microampermeter (µA) which is connected in series with the flame electrode and the gas burner control. - Page 34 BENTONE 8.8.2 UV –detector (QRC) The UV sensor should not be exposed to temperatures higher than 60 °C. The current passing through the UV sensor when it is lighted must be at least 70 µA. The current can be measured using a rotary coil instrument. A check is necessary only if a malfunction is suspected.
-
Page 35: Handing Over Of The Installation
BENTONE Handing over of the installation • Make repeated start attempts to ensure that the adjustments function. • Close the ball valve during operation to check that the gas switch switches off at the set value. • Remove the hose for the air pressure switch to check that the burner locks out. -
Page 36: 10. Troubleshooting
BENTONE 10. Troubleshooting Conditions favourable to trouble-free operation of the system can only be guaranteed through the interaction between three factors: electricity, gas flow and combustion air. If any of these factors change, it may cause a malfunction. Before requesting servicing, check the following points: Are the system’s gas taps open? - Page 37 BENTONE Action Cause of fault Burner trips during pre-aeration: Air sensor faulty or incorrectly set. Increase/decrease air setting. Reduce air volume. Ignition load incorrectly set. Increase/decrease gas supply Reduce airflow. Gas pressure too low. Increase pressure. If necessary, contact gas supplier.
-
Page 38: 11. Service- And Inspection Protocol
11. Service- and inspection protocol Installation: Boiler: Name: Type: Efficiency kW: Address: Burner Type: Efficiency kW: Installed by: Date: Date Efficiency gas/h Governor Fluegas Ionisation Pressure temp current Fire room Chimney Measure- ment Before After °C µ A mbar mbar Small Flame Large Flame... -
Page 39: Eu Declaration Of Conformity
EU Declaration of conformity Bentone Gas Burners Certificate No. Certificate No. Type: Type: BFG 1 CE-0123CT1269 BG 550 CE-0123CT1326 STG 120 CE-0123CT1270 BG 650 CE-0123CT1348 STG 146 CE-0123CT1281 BG 700 CE-0123CT1359 BG 300 CE-0123CT1292 BG 800 CE-0123CT1360 BG 400 CE-0123CT1304... - Page 40 UK Declaration of conformity Bentone Gas Burners Type: BFG 1 BG 300 BG 550 BG 800 STG 120 BG 400 BG 650 BG 950 STG 146 BG 450 BG 700 This declaration of conformity is issued under the sole responsibility of the manufacturer.
