Configuring Field Properties
(Free Design Template)
Clicking the button and then Properties displays a dialog box that you can
use to change the properties of a field.
Note
The unit of measurement (millimeters, pixels, inches) used on the Field
Properties dialog box is the same as that selected with the ruler unit of
measurement button (page 46).

To reposition and resize a field

1.
Select the field you want to reposition. On the main window, click
Note
If multiple fields are selected, only the reference field (the one with the
gray selection boundary) can be repositioned.
2.
On the menu that appears, click Properties.
This displays the Field Properties dialog box.
56
.
Print Area Location
These values indicate the
relative location of the print
area from the upper left
corner of the work area.
Changing the values in the
box causes the print area
to move to the new
location.
3.
Input the values you want. The settings you configure are reflected in the
preview image on the main window.
4.
Click the Size tab.
Size and Zoom Factor
Inputting a value in one box automatically changes the value in the other
box.
Maintain aspect ratio
When this check box is selected, the field is resized while maintaining the
relative ratio between its vertical and horizontal dimensions.
When this checkbox is cleared, a field can be resized by changing the
horizontal or vertical dimension only.
Dimensions
These are the dimensions of the image when it was originally captured or
imported from a file.
5.
Input the values you want and then click OK. The settings you configure
are reflected in the preview image on the main window.
