INTRODUCING SOLTECH SATELIS:
roads and commercial applications. It features a high-efficiency 130Wp solar panel with
upgradable battery storage options. The kit includes all the necessary components for pole
mounting, and SOLTECH offers custom poles to meet wind load specifications.
• Adjustable panel angle for the fixture allows maximum solar
collection and self-cleaning of the solar panel surface.
• 10,000LM at 200LM/W highest efficiency in the industry with
smart power management.
• Remote control included with one-button mode setting.
• Grade A LifePO₄ Battery Pack, 2000+ full charging cycles.
• Features modular battery box with fast hooking design.
• Meets IES standards for road illumination, supporting solar
clean energy solutions that comply with street and area
light regulations.
• Equipped with a microwave motion sensor and photocell sensor.
• Built-in smart MPPT-IAP controller maximizes autonomy
and performance.
• Marine Grade aluminum & stainless steel fasteners for harsh
environments.
APPLICATIONS
This commercial-grade series is ideal for highways, city streets, large parking lots and area
lighting. It comes with a wide choice of configurations,lumen outputs, pole heights, and it's
optimized for high efficiency and long-term performance.
01
I
soltechlighting.com
SATELIS is a spec-grade LED solar lighting solution for major
I
hello@soltechlighting.com
I
(510) 891-1056
LED SOLAR AREA LIGHT
I
1460 Park Avenue, Emeryville, CA 94608
SATELIS 50W
I
Advertisement
Related Manuals for Soltech SATELIS 50W
Summary of Contents for Soltech SATELIS 50W
- Page 1 It features a high-efficiency 130Wp solar panel with upgradable battery storage options. The kit includes all the necessary components for pole mounting, and SOLTECH offers custom poles to meet wind load specifications. • Adjustable panel angle for the fixture allows maximum solar collection and self-cleaning of the solar panel surface.
- Page 2 SATELIS 50W LED SOLAR AREA LIGHT LIGHT FIXTURES LED Nominal Power Lumen Output@5000K 10,000 EPA@45° 12.4 Efficiency@5,000K 200 LM/W Lumileds 5050 (215lm-CRI>70) LED Chip BATTERY *Operating Temperature 0°C/32°C to 140°F 0°C/32°F to 140°F *Charging Temperature LiFePO₄ Battery 768WH 25.6V 30AH | 1,536WH 25.6V 60AH...
- Page 3 SATELIS 50W LED SOLAR AREA LIGHT IES/ BEAM SATELIS 50W TYPE III [ MOUNTING HEIGHT 20FT ] [ UNIT: FT ] PRODUCT SIZE—SATELIS 50W 26.5 inches 1.3 inches 9.5 inches 6.3 inches 25V 30AH SOLAR PANEL: 21.1 Lbs SOLAR LAMP: 13.5 Lbs BATTERY ASSEMBLY: 35.2 Lbs...
- Page 4 SATELIS 50W LED SOLAR AREA LIGHT INSTALLATION ACCESSORIES—50W SLIP FITTER SOLAR PANEL SUPPORT BASE-CUTAWAY 0.4 inches 3.0 inches Pole Pole Size For Slip Fitter 8.2 inches 5.3 inches 7.1 inches 1.8 inches 2 3/8 inches 2.2 inches 7.2 inches 3.0 inches...
- Page 5 Up to 15m/49' WARRANTY SATELIS products are covered by a 5 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 5 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
-
Page 6: Remote Controls
SATELIS 50W LED SOLAR AREA LIGHT REMOTE CONTROLS 1. On/Off 2. Connect/Test 3. 40%~100% Motion 4. 20%~80% Motion Sensor Mode Sensor Mode (Default) 5. Night Owl Mode 6. Early Bird Mode 7. 100% Constant Mode 10. Timer Mode Disabled 8. 70% Constant Mode 9. - Page 7 SATELIS 50W LED SOLAR AREA LIGHT REMOTE CONTROLS 3. 40%~100% Motion Sensor Mode 5. Night Owl Mode Constant 40% brightness (turns on at dusk, turns off at dawn); Changes as natural light decreases/increases (turns on at dusk); 70% 100% brightness turns on for 2 minutes when motion is detected.
- Page 8 Constant Mode. If the light turns on at 7pm at dusk, it will turn off at 11pm. It will repeat the same schedule hereafter until it is canceled by pressing Timer Mode Disabled. SOLTECH LLC reserves the right to update all product data sheets at any time. Consult Copyright©2018–2024 SOLTECH LLC, SOLTECH marketing specialists for publication All Rights Reserved.
- Page 9 SATELIS 50W LED SOLAR AREA LIGHT PANEL ANGLE GUIDE The solar charge in a battery pack won’t last forever. The off–grid system relies on stored solar energy for autonomy. Angling your solar panels properly can boost the power intake of your solar lighting system.
- Page 10 60° 45° 30° 15° 0° 15° 30° 45° SOLTECH LLC reserves the right to update all product data sheets at any time. Consult Copyright©2018–2024 SOLTECH LLC, SOLTECH marketing specialists for publication All Rights Reserved. updates at hello@soltechlighting.com soltechlighting.com hello@soltechlighting.com (510) 891-1056...
