- Page 1 CEGONIA Installation Manual SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
- Page 2 CEGONIA PRO 30W...
-
Page 3: Table Of Contents
Contents Introduction Battery Notes Installation and Wiring Compliance Mounting Accessories Installation Panel Angle Remote Control Guide... -
Page 4: 1 Introduction
01 Introduction Thank you for purchasing CEGONIA PRO solar-powered area light. Range of the light module on the lighting fixture is 20–26 feet (6–8 Introduction meters). The ideal installation spacing is >16 feet (5 meters). When CEGONIA PRO combine stylish design with hight efficiency. You can adjust installing two or more lighting fixtures on one pole, select desired both the tilt angle and the azimuth to make sure the panel is in the optimal operating mode before installation. - Page 5 CEGONIA PRO 30W SOLAR PANEL: 9.9 Lbs SOLAR LAMP: 13.6 Lbs BATTERY ASSEMBLY: 25.9 Lbs 8.5 inches 31.0 inches 30.4 inches 20.1 inches 11.0 inches 9.5 inches 1.2 inches CEGONIA PRO 30W Type III...
-
Page 6: Battery Notes
02 Battery Notes 1. Super Capacitor battery-powered CEGONIA PRO lights are visibly Battery Status is indicated by the red/green indicator on the light brighter than other outdoor solar lights, and their performance overall fixture as follows: is more reliable. > Slow red light flashing (Every 2.5s) = Working 2. - Page 7 (IAP) Intelligent Adaptive Program Battery Control Technology ATTENTION In order to extend the off-grid autonomy of the CEGONIA PRO 30W Battery cannot be replaced on your own. Please conntact SOLTECH for under shade trees, heavy rain, and thick clouds, our controllers any battery’s questions.
-
Page 8: Installation And Wiring Compliance
Electrical Codes. foundation are solid enough to support the light fixture(s). 2. The CEGONIA PRO 30W model is intended for outdoor use 5. Before installation, ensure that the battery is fully charged. Install during only and should not be installed in an unventilated area. It must be sunny days if possible. -
Page 9: Mounting Accessories
04 Mounting Accessories A. TRUNNION—Wall Mount 6.8 inches 0.5 inches 0.2 inches A-b. STLSTEPRO-30-WM (for CEGONIA PRO 30W) B. TRUNNION—Round 0.5 inches 5.1 inches Pole Size 2.4 inches 4.0 inches B-b. STLSTEPRO-30-TRR (for CEGONIA PRO 30W) works with 2.4 inches to 4.0 inches poles. - Page 10 05 Installation CEGONIA PRO 30W TRUNNION —Wall Mount TRUNNION —Round TRUNNION —Square...
- Page 11 Component Kit B Connect ±45° Component Kit A 270° Loose screws of component kit B to adjust the angle of solar panel. ±45° Connect Loose screws of component kit A to rotate solar panel. 270° ±45° Connect 270°...
- Page 12 70° N 69° N 68° N 67° N 66° N 65° N 64° N 63° N 62° N 60° Alaska 61° N 60° N 49° N 48° N Washington 47° N 46° N Montana 45° N North Dakota Oregon 44° N Minne Idaho 43°...
-
Page 13: Panel Angle 012
06 Panel Angle The solar charge in a battery pack won’t last forever. The off–grid system relies on stored solar energy for autonomy. Angling your solar panels properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude. You can increase the tilt 15°... -
Page 14: Remote Control Guide 014
07 Remote Control Guide 1. On/Off 2. Connect/Test 3. 40%~100% Motion 4. 20%~80% Motion Sensor Mode Sensor Mode (Default) 5. Night Owl Mode 6. Early Bird Mode 7. 100% Constant Mode 10. Timer Mode Disabled 8. 70% Constant Mode 9. 40% Constant Mode 12. - Page 15 3. 40%~100% Motion Sensor Mode 5. Night Owl Mode Constant 40% brightness (turns on at dusk, turns off at dawn); Changes as natural light decreases/increases (turns on at dusk); 70% 100% brightness turns on for 2 minutes when motion is detected. brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours (turns off at Dawn).
- Page 16 07 Remote Control Guide 7. 100% Constant Mode 8. 70% Constant Mode 100% brightness from dusk to dawn. 70% brightness from dusk to dawn. 9. 40% Constant Mode 40% brightness from dusk to dawn. 10. Timer Mode Disabled Press this button to turn off Timer Mode; settings revert back to before Timer Mode was last activated.
- Page 17 (IAP) Intelligent Adaptive Program Battery Control Technology Important In order to extend the off-grid autonomy of the CEGONIA PRO 30W Dusk and dawn time can vary for different locations and seasons. under shade trees, heavy rain, and thick clouds, our controllers...
- Page 18 CEGONIA PRO products are covered by a 5 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 5 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
- Page 20 SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
