- Page 1 SATELIS 50W 75W User Manual SOLTECH offers Advanced LED Technology That Is Eco-friendly And Utilizes Clean Energy.
-
Page 2: Table Of Contents
Contents Check List Introduction Specification Luminous Distribution Battery Notes Installation and Wiring Compliance Mounting Accessories Installation—50W 0 1 2 Installation—75W SATELIS 50W Panel Angle Remote Control Guide SATELIS 75W... -
Page 3: Check List
01 Check List SATELIS 50W SATELIS 75W Solar Panel Luminaire Battery Pack Solar Panel Luminaire Battery Pack Component Kit A Component Kit B Component Kit C Component Kit A Component Kit B Component Kit C Component Kit D Component Kit E Component F Component G Component H... -
Page 4: Introduction
02 Introduction 03 Specification Thank you for purchasing SATELIS Urban Lighting Products. Specification SATELIS 50W SATELIS 75W Please save these instructions. Read all of the instructions carefully Introduction before attempting to carry out any installation or wiring. Do not open or The high-performance SATELIS Series is a municipal-grade solar outdoor LED Nominal Power attempt to repair the product on your own, as it many cause serious... -
Page 5: Luminous Distribution
04 Luminous Distribution 05 Battery Notes SATELIS 50W Type III 1. The LiFePO -battery-powered SATELIS lights are visibly brighter Battery Status is indicated by the red/green indicator on the lighting than other outdoor solar lights, and their performance overall is fixture as follows: more reliable. -
Page 6: Installation And Wiring Compliance
06 Installation and Wiring Compliance 07 Mounting Accessories SLIP FITTER SOLAR PANEL SUPPORT BASE—CUTAWAY 1. Installation and wiring must comply with the State and National 4. Before installation, if applicable, please ensure the light pole and its Electrical Codes. foundation are solid enough to withstand the lighting fixture(s). 2. -
Page 7: Installation-50W
08 Installation—50W Satelis 50W Solar Panel Component Kit D Component F Component K Component Kit B Tenon Adapter Component Kit E Component Kit A The luminare wire comes inside the component H and comes out from the hole. Component H If your round pole size is over 3.1 inches, or you need a square pole, please contact the pole manufacturer... -
Page 8: Installation-75W
09 Installation—75W Satelis 75W Solar Panel Component Kit D Component F Component L Tenon Adapter Component Kit B Component Kit E Component Kit A The luminare wire comes inside the component H and comes out from the hole. Component H If your round pole size is over 3.1 inches, or you need a square pole, please contact the pole manufacturer... - Page 9 10 Panel Angle 70° N 69° N 68° N 67° N The Solar charge in a battery pack won’t last forever. The off–grid 66° N system relies on stored solar energy for autonomy. Angling your solar 65° N panels properly can boost the power intake of your solar lighting system.
- Page 10 1 1 Remote Control Guide 3. 40%~100% Motion Sensor Mode 5. Night Owl Mode Constant 40% brightness (turns on at dusk, turns off at dawn); Changes as natural light decreases/increases (turns on at dusk); 70% 100% brightness turns on for 2 minutes when motion is detected. brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% bright- ness for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 1.
- Page 11 1 1 Remote Control Guide 7. 100% Constant Mode 8. 70% Constant Mode 11. Timer Mode 4 Hours 12. Time Mode 8 Hours 100% brightness from dusk to dawn. 70% brightness from dusk to dawn. This is an additional mode which can work with any other modes. This is an additional mode which can work with any other modes.
- Page 12 1460 Park Avenue. Emeryville CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at hello@soltechlighting.com Copyright©2020–2021 SOLTECH LLC,...
- Page 13 SOLTECH offers advanced LED technology that is eco-friendly and utilizes clean energy.
